Compact Binoculars

Congratulations on selecting your new Carson Binocular! In order to achieve

optimum performance, please follow instructions for proper use and care.

CARSON

EYE ADJUSTMENTS: HOW TO ADJUST FOR DISTANCE BETWEEN THE EYES

The distance between the eyes, interpupillary distance,

varies from person to person. To achieve perfect alignment

of lens to eye:

1. Hold binoculars in normal viewing position.

2. Rotate barrels closer or farther apart until you see

a single circular field.

INDIVIDUALLY ESTABLISHING LEFT/RIGHT EYE FOCUS:

INDEPENDENT

RIGHT DIOPTER

CENTRAL

FOCUS KNOB

FOLD DOWN

EYECUPS

INDEPENDENT

RIGHT DIOPTER

TWIST-UP

EYECUPS

Single Circular Field

Most binoculars have a center focus knob and an independent right diopter eyepiece to account for small

differences in the strength of each eye. Please follow the steps below to focus properly:

1. Eyecups should be fully extended if you don’t wear glasses. If you wear glasses, twist/roll down

eyecups to bring your eyes closer to the binocular lens.

2. With right eye closed, rotate the central focusing knob until the image in the left eyepiece is sharp.

3. With left eye closed, rotate the independent right diopter eyepiece until the image is sharp.

4. Image should now be focused to your individual eye strength and will retain setting for future use.

Note: If you still cannot focus, rotate adjustable right diopter to reset by lining up symbols (triangle, line, circle,

etc.) on diopter eyepiece and barrel. Then repeat Focusing Steps 2 and 3.

FOCUSING YOUR BINOCULARS:

While viewing an image, adjust the center focus wheel for distance.

Produkspesifikasjoner

Merke:	Carson
Kategori:	Kikkert
Modell:	JD-025
Vekt:	281 g
Dimensjoner (B x D x H):	102 x 102 x 51 mm
Objektiv diameter:	25 mm
Produktfarge:	Black, Grey
Bæretaske:	Ja
Forstørring:	10 x
Prismetype:	BK-7
Øyehvile:	9.5 mm
