Side 1/12
Write Model & Serial Numbers here:
_______________________________
COMMERCIAL COUNTER-HEIGHT
BUILT-IN REFRIGERATORS
Model SeriesCSCR600BGL BI
SCR600BGLBIADA
405 CM411L
Instruction Manual
BEFORE USE, PLEASE READ AND FOLLOW
ALL SAFETY RULES AND OPERATING INSTRUCTIONS
FELIX STORCH, INC.
An ISO 9001:2015 registered company
770 Garrison Avenue
Bronx, NY10474
www.summitappliance.com
1
IMPORTANT SAFEGUARDS
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance.
Always read and obey all safety messages.
This is the Safety Alert Symbol. This symbol alerts you to potential
hazards that can kill or injure you and others. All safety messages will
follow the Safety Alert Symbol and either the words DANGER or
WARNING.
DANGER means that failure to heed this
safety statement may result in severe
personal injury or death.
WARNING means that failure to heed
this safety statement may result in
extensive product damage, serious
personal injury, or death.
Safety messages will alert you what the potential hazard is, tell you how to reduce the chance to
of injury, and let you know what can happen if the instructions are not followed.
Before the refrigerator is used, it must be properly positioned and installed
as described in this manual, so read the manual carefully. To reduce the
risk of re, electrical shock or injury when using the appliance, follow basic
precautions, including the following:
Plug into a grounded 3-prong outlet. Do not remove grounding prong, do not use an adapter,
and do not use an extension cord.
is recommended that a separate circuit, serving only your refrigerator, be provided. Use It
receptacles that cannot be turned o by a switch or pull chain.
Never clean appliance parts with ammable uids. These fumes can create a re hazard or
explosion. And do not store or use gasoline or other ammable vapors and liquids in the
vicinity of this or any other appliance. The fumes can create a re hazard or explosion.
Before proceeding with cleaning and maintenance operations, make sure the power line of the
unit is disconnected.
not connect or disconnect the electric plug when your hands are wet. Do
Unplug the appliance or disconnect the power before cleaning or servicing. Failure to do so
can result in electrical shock or death.
not attempt to repair or replace any part of your refrigerator unless it is specically Do
2
recommended in this ma al. All other servicing should be referred to a qualied technician. nu
This appliance is CFC- and HFC-free and contains small quantities of Isobutane (R600a)
which is environmentally friendly, but ammable. It does not damage the ozone layer, nor
does it increase the greenhouse eect. Care must be taken during transportation and setting
up of the appliance that no parts of the cooling system are damaged. Leaking coolant can
ignite and may damage the eyes.
In the event of any damage:
- Avoid open ames and anything that creates a spark,
- Disconnect from the electrical power line,
- Air the room in which the appliance is located for several minutes, and
- Contact the Service Department for advice.
The more coolant there is in an appliance, the larger the room it should be installed in. In the
event of a leakage, if the appliance is in a small room, there is the danger of combustible
gases building up. For every ounce of coolant at least 325 cubic feet of room space is
required. The amount of coolant in the appliance is stated on the data plate on the back of the
appliance It is hazardous for anyone other than an Authorized Service Person to carry out .
servicing or repairs to this appliance.
Take serious care when handling, moving, and using the appliance to avoid either damaging
the refrigerant tubing or increasing the risk of a leak.
Replacing component parts and servicing shall be done by factory authorized service
personnel so as to minimize the risk of possible ignition due to incorrect parts or improper
service.
Use two or more people to move and install the refrigerator. Failure to do so can result in back
or other injury.
To ensure proper ventilation for your appliance, the front of the unit must be completely
unobstructed. Choose a well-ventilated area with temperatures above 60
°
F (16
°
C) and below
90
°
F (32
°
C). This unit must be installed in an area protected from the elements, such as wind,
rain, water spray or drips.
The appliance should not be located next to ovens, radiators or other sources of high heat.
The appliance must be installed with all electrical connections in accordance with state and
local codes. A standard electrical supply ( 5 only, 60 Hz), properly grounded in 11 V AC
accordance with the National Electrical Code and local codes and ordinances, is required.
not kink or pinch the power supply cord of the appliance. Do
The fuse (or circuit breaker) size should be 15 amperes.
is important for the refrigerator to be leveled in order to work properly. You may need to It
make several adjustments to level it.
Never allow children to operate, play with or crawl inside the refrigerator.
not use solvent-based cleaning agents o abrasives on the interior. These cleaners may Do r
damage or discolor the interior.
Do not use this apparatus for other than its intended purpose.
Do not store explosive substances such as aerosol cans with a ammable propellant in this
appliance.
Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of
obstruction.
3
Do not use mechanical devices or other means to accelerate the defrosting process, other
than those recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food storage compartments the appliance, of
unless they are of the type recommended the manufacturer. by
NOTE: MODELS SCR600 LBI AND SCR600 LBIADA ARE DESIGNED AS COMMERCIAL BG BG
BEVERAGE MERCHANDISERS.
Risk of child entrapment
Child entrapment and suocation are not problems of the past. Junked or abandoned
refrigerators and freezers are still dangerous, even if they will just sit in the garage a few “
days. ”
Before you throw away your old refrigerator or freezer: Take o the doors. Leave
the shelves or drawers in place so that children may not easily climb inside.
Never allow children to operate, play with, or crawl inside the refrigerator/freezer.
THIS APPLIANCE IS NOT INTENDED FOR USE BY YOUNG CHILDREN OR INFIRM
PERSONS UNLESS THEY HAVE BEEN ADEQUATELY SUPERVISED BY A RESPONSIBLE
PERSON TO ENSURE THAT THEY CAN USE THE APPLIANCE SAFELY. YOUNG CHILDREN
SHOULD BE SUPERVISED TO ENSURE THAT THEY DO NOT PLAY WITH THE APPLIANCE.
- SAVE THESE INSTRUCTIONS –
Technical Information
Model Number
SCR600BGLBI
SCR600BGLBIADA
Description
Black cabinet with 5 shelves and lock; glass door
Capacity
5.5 cu. ft.
Shelves
4 glass, 1 wire
Fans
External and internal
Electrical Input
115V AC/60Hz
Rated Current
1.0A
Refrigerant
R a 600
Installation
Built-in or free-standing
Unit Dimensions
(W x D x H)
23.63" x 23.5" x 33.5"
23.63" x 23.5" x 32. " 38
NOTES: These models are designed as commercial beverage merchandisers. 1.
2. The lower height of the ADA model allows it to be installed under lower
ADA-compliant cabinets.
3. Specications are subject to change without notice.
4
Table of Contents
Important Safeguards ...................................................................................................... 1 - 3
Technical Information ........................................................................................................... 3
Location of Parts ................................................................................................................... 4
Installation Instructions ................................................................................................... 5 - 7
Before Using Your Appliance ............................................................................................ 5
Installing the Refrigerator .................................................................................................. 5
Electrical Connection ................................................................................................... 5 - 6
Extension Cord / Door Handle Installation ........................................................................ 6
Reversing the Door Swing ............................................................................................... 7
Operating Your Refrigerator ................................................................................................ 8
Temperature Control
Defrosting Your Appliance
Care and Maintenance .......................................................................................................... 9
Cleaning Your Appliance / Power Failure / Vacations/
Moving your Appliance Energy-Saving Tips /
Troubleshooting ................................................................................................................... 10
Limited Warranty .................................................................................................................. 11
Location of Parts
Temperature control dial
(thermostat), light switch
and interior light
Glass door
Front ventilation
slots (kick plate)
Leveling legs
Adjustable
glass shelves (4)
plus 1 wire shelf
Defrost water
outlet
Handle
Lock
Interior fan
5
Improper use of the grounded plug can result in the risk of electrical shock. If the power
cord is damaged, have it replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
Installation Instructions
Before Using Your Appliance:
Remove the exterior and interior packing.
Before connecting the unit to a power source, let it stand for approximately 2 hours.
This will reduce the possibility of a malfunction in the cooling system from handling
during transportation.
Remove the shelves and c m the interior surfaces with lean the and of the unit
lukewarm water using a soft cloth.
Installing the Refrigerator:
Place unit on a oor that is strong enough to support the appliance when it is fully the
loaded. To level two leveling legs at the front. the unit, adjust the
Your appliance is designed to be installed either -standing or built-in (fully-free
recessed). For free-standing installation, allow at least 4 of space ” (102mm) at the
sides, and rear allow proper air circulation to cool the compressor top of the unit to for
and condenser. If the unit is to be built-in, leave at least 3/16” at both sides,
1/16” at the top and 2” at the rear. Take care that the air vents at the front of the
appliance are never covered or blocked in any way.
Locate the unit away from direct sunlight and sources of heat (oven, heater, radiator,
etc.). Direct sunlight may aect the acrylic coating and heat sources may increase
electrical consumption. Extreme cold ambient temperatures may also aect ly the
unit's performance.
Avoid locating the unit in moist areas. Too much moisture in the air will cause frost to
form quickly on the evaporator, requiring more frequent defrosting of the interior.
Plug the unit into an exclusive, properly installed and grounded wall outlet. Do not
under any circumstances cut or remove the third (ground) prong from the power cord.
Any questions concerning power and/or grounding should be directed toward a
certied electrician or authorized service center.
Electrical Connection:
This unit should be properly grounded for your safety. The power cord of this unit is
equipped with a three a -prong plug which mates with standard three-prong wall outlet to
minimize the possibility of electrical shock.
Do not under any circumstances cut or remove the third ground prong from the power
cord supplied. For personal safety, this appliance must be properly grounded.
6
This unit requires a standard 115-volt AC/60Hz electrical outlet with three-prong ground.
Have the wall outlet and circuit checked by a qualied electrician to make sure the outlet
is properly grounded. When a standard 2-prong wall outlet is encountered, it is your
responsibility and obligation to have it replaced with a properly grounded 3-prong wall
outlet.
To prevent accidental injury, the cord should be secured behind the unit and not left
exposed or dangling.
The unit should always be plugged into its own individual electrical outlet which has a
voltage rating that matches the rating label on the appliance. This provides the best
performance and also prevents overloading house wiring circuits that could cause a re
hazard from overheated wires. Never unplug the unit by pulling on the power cord.
Always grip the plug rmly and pull straight out from the receptacle. Repair or replace
immediately any power cord s become frayed or otherwise damaged. Do not use that ha
a cord that shows cracks or abrasion damage along its length or at either end. When
moving the unit, be careful not to damage the power cord.
Extension Cord:
Do not use an extension cord with this appliance. If the power cord is too short, have a
qualified electrician or service technician install an outlet near the appliance.
Door Handle Installation:
The door has two screw holes on each side, allowing you to install a handle (included). To
do so, align the handle with the screw holes on the side you prefer. Fix the handle in place
with the included screws, then cover the screw heads with the handle seal (included).
7
Reversing the Door Swing:
(IMPORTANT: The doors on models with pro style handles (SH, TB, HV, or CSS in
model number sux) are not customer-reversible.)
If you nd the direction of opening the door of the inconvenient, you can appliance
change it. Holes on the opposite side have already been prepared at the factory.
This appliance can be opened from either the right side or the left. By default, the door
hinge is on the right side. If you prefer it on the left, please follow these instructions:
NOTES See illustration : below.
All of the parts that are removed must be kept for the reinstallation of the door.
1. Unscrew the lower hinge and take o the door.
2. Push the kick plate to the right in the new position.
3. Undo the upper hinge fastener and x it to the opposite side of the housing, where you
have already removed and replaced the fastener with the hole to the opposite side.
4. Put the door on the upper hinge fastener.
5. Fix the lower hinge in the new position.
6. Unscrew the handle and place it on the opposite side.
7. undoing the screws. Some screws are covered with caps. Take o these caps before
8. Check the door gasket. It should not be creased and should seal well.
1. Upper hinge fastener 4 Handle .
Lower hinge 5 Door hinge xture 2. .
Kick plate Door hinge xture plug 3. 6.
8
Operating Your Refrigerator
Temperature Control:
Your appliance s evaporator system is out of sight behind the interior rear wall ’.
The interior temperature is controlled with a thermostat knob
located inside the unit, towards the upper right-hand corner.
Turn the knob clockwise from the STOP 0 ( ) position toward
the higher numbers for colder temperatures. Higher settings
on the knob (higher numbers) mean lower temperatures
(colder) in the refrigerator.
On the coldest settings, temperatures in some spots inside
the cabinet may drop below 32°F. Use higher thermostat settings only when required
or recommended. When the ambient temperature is normal, we recommend a
medium setting.
Changes in the ambient temperature aect temperature inside refrigerator the the
so choose an appropriate setting of the thermostat knob, depending on ambient
conditions.
In the the appliance does not operate (the cooling system is STOP 0 ( ) position,
switched o), yet power supply is not interrupted (the light still works the ).
The temperature side efrigerator also depends on how often you open the in the r
door.
It is best not to operate th ance mostly empty. If temperatures are erratic, try is appli
putting some water bottles inside to create a load for the compressor.
NOTES :
1. The glass shelves are adjustable. These shelves stop short an inch before the back
wall, which is essential for air ow and the proper operation of the automatic defrost
system. Do not block these gaps.
2. Interior lighting controlled by a manually-operated rocker switch. maintain the is To
proper interior temperature, keep the light on only as long as necessary.
3. refrigerator is unplugged, has lost power, or is turned o, you must wait 3 to 5 If the
minutes before restarting it. If you attempt to restart before this time delay, the will unit
not start.
Defrosting Your Appliance:
This appliance operates with system, so t refrigerator defrosts an automatic defrost he
itself. While the compressor is operating, ice will build along the rear cold wall (the
evaporator plate -cycle, ice will melt, drip is behind the wall). During the compressor’s off
down, collect in the trough at small hole into a tray above the bottom and drain through a
the compressor, where the compressor’s heat will evaporate the water. If you notice
excessive ice bu -up on the rear wall, try adjusting ild the thermostat to a slightly warmer
setting; be sure that the door gasket is sealing well that there is no obstruction of the and
drain hole interior cabinet. at the bottom rear of the
Produkspesifikasjoner
| Merke: | Summit |
| Kategori: | Kjøleskap |
| Modell: | SCR600BGLBIADA |
Trenger du hjelp?
Hvis du trenger hjelp med Summit SCR600BGLBIADA still et spørsmål nedenfor, og andre brukere vil svare deg
Kjøleskap Summit Manualer
31 Mars 2025
31 Mars 2025
29 Mars 2025
20 Januar 2025
27 Desember 2024
27 Desember 2024
27 Desember 2024
27 Desember 2024
27 Desember 2024
27 Desember 2024
Kjøleskap Manualer
- Kjøleskap Teka
- Kjøleskap Maytag
- Kjøleskap Thomson
- Kjøleskap Amana
- Kjøleskap Uniprodo
- Kjøleskap Miele
- Kjøleskap Whirlpool
- Kjøleskap Etna
- Kjøleskap Haier
- Kjøleskap KitchenAid
- Kjøleskap NewAir
- Kjøleskap Insignia
- Kjøleskap Adler
- Kjøleskap Pelgrim
- Kjøleskap Royal Catering
- Kjøleskap LG
- Kjøleskap Bosch
- Kjøleskap Jocel
- Kjøleskap BEKO
- Kjøleskap Exquisit
- Kjøleskap Grundig
- Kjøleskap Hisense
- Kjøleskap Sharp
- Kjøleskap Electrolux
- Kjøleskap Severin
- Kjøleskap Café
- Kjøleskap Balay
- Kjøleskap Siemens
- Kjøleskap Koldfront
- Kjøleskap Arcelik
- Kjøleskap Danby
- Kjøleskap Bartscher
- Kjøleskap Smeg
- Kjøleskap Hoover
- Kjøleskap Philips
- Kjøleskap TCL
- Kjøleskap Russell Hobbs
- Kjøleskap Hotpoint
- Kjøleskap Nabo
- Kjøleskap Amica
- Kjøleskap IKEA
- Kjøleskap Ignis
- Kjøleskap AEG
- Kjøleskap Rosieres
- Kjøleskap Inventum
- Kjøleskap Artusi
- Kjøleskap Cecotec
- Kjøleskap Samsung
- Kjøleskap Neff
- Kjøleskap Delonghi
- Kjøleskap Bomann
- Kjøleskap Edgestar
- Kjøleskap Kogan
- Kjøleskap Caple
- Kjøleskap PKM
- Kjøleskap Create
- Kjøleskap Marvel
- Kjøleskap G3 Ferrari
- Kjøleskap Yamaha
- Kjøleskap Midea
- Kjøleskap Franke
- Kjøleskap Sauber
- Kjøleskap Candy
- Kjøleskap Liebherr
- Kjøleskap Viking
- Kjøleskap Orbegozo
- Kjøleskap Kuppersbusch
- Kjøleskap Gorenje
- Kjøleskap Accucold
- Kjøleskap Brandt
- Kjøleskap Gram
- Kjøleskap Panasonic
- Kjøleskap Monogram
- Kjøleskap Vox
- Kjøleskap Westinghouse
- Kjøleskap Orava
- Kjøleskap Schneider
- Kjøleskap Kluge
- Kjøleskap Juno-electrolux
- Kjøleskap Bertazzoni
- Kjøleskap DCG
- Kjøleskap Coyote
- Kjøleskap Stirling
- Kjøleskap Privileg
- Kjøleskap MPM
- Kjøleskap Cosmo
- Kjøleskap Khind
- Kjøleskap Euro Appliances
- Kjøleskap Bauknecht
- Kjøleskap Frigidaire
- Kjøleskap Whynter
- Kjøleskap GE
- Kjøleskap Concept
- Kjøleskap Guzzanti
- Kjøleskap XO
- Kjøleskap Omega
- Kjøleskap Hitachi
- Kjøleskap Fisher Paykel
- Kjøleskap Fulgor Milano
- Kjøleskap Hyundai
- Kjøleskap Chiq
- Kjøleskap Vintec
- Kjøleskap Nevir
- Kjøleskap Eqtemp
- Kjøleskap Infiniton
- Kjøleskap Indesit
- Kjøleskap Daikin
- Kjøleskap Zephyr
- Kjøleskap Asko
- Kjøleskap Blaupunkt
- Kjøleskap Lamona
- Kjøleskap Mitsubishi
- Kjøleskap Marshall
- Kjøleskap Scandomestic
- Kjøleskap Cylinda
- Kjøleskap Respekta
- Kjøleskap AYA
- Kjøleskap Costway
- Kjøleskap Dometic
- Kjøleskap Blaze
- Kjøleskap Husky
- Kjøleskap Fridgemaster
- Kjøleskap Eldom
- Kjøleskap Fisher And Paykel
- Kjøleskap Elba
- Kjøleskap Worx
- Kjøleskap Philco
- Kjøleskap Jenn-Air
- Kjøleskap Wisberg
- Kjøleskap ECG
- Kjøleskap HomeCraft
- Kjøleskap Igloo
- Kjøleskap ATAG
- Kjøleskap Freggia
- Kjøleskap Becken
- Kjøleskap Element
- Kjøleskap Avanti
- Kjøleskap Acros
- Kjøleskap Kucht
- Kjøleskap Glem Gas
- Kjøleskap True
- Kjøleskap Perlick
- Kjøleskap Toshiba
- Kjøleskap BeefEater
- Kjøleskap Hansa
- Kjøleskap Thor
- Kjøleskap Sub-Zero
- Kjøleskap Koolatron
- Kjøleskap Coca-Cola
- Kjøleskap Kenmore
- Kjøleskap Meireles
- Kjøleskap Fagor
- Kjøleskap Edesa
- Kjøleskap IFB
- Kjøleskap Profilo
- Kjøleskap Gaggenau
- Kjøleskap Milectric
- Kjøleskap Tisira
- Kjøleskap Hiberg
- Kjøleskap LERAN
- Kjøleskap Zerowatt
- Kjøleskap Baumatic
- Kjøleskap Iberna
- Kjøleskap Ilve
- Kjøleskap Wolkenstein
- Kjøleskap Rommer
- Kjøleskap Hoover-Grepa
- Kjøleskap Primo
- Kjøleskap Svan
- Kjøleskap Landmark
- Kjøleskap Signature
- Kjøleskap Trisa
- Kjøleskap Corberó
- Kjøleskap Atosa
- Kjøleskap Scancool
- Kjøleskap FrigeluX
- Kjøleskap Mora
- Kjøleskap DAYA
- Kjøleskap Salora
- Kjøleskap Consul
- Kjøleskap Aconatic
- Kjøleskap Kuhla
- Kjøleskap Hestan
- Kjøleskap Optimum
- Kjøleskap Yolco
- Kjøleskap Thermador
- Kjøleskap Sangiorgio
- Kjøleskap Ardes
- Kjøleskap Fhiaba
- Kjøleskap Ideal
- Kjøleskap Avallon
- Kjøleskap Continental Edison
- Kjøleskap Icecool
- Kjøleskap Crosley
- Kjøleskap Pitsos
- Kjøleskap Winia
- Kjøleskap Schaub Lorenz
- Kjøleskap Premium Levella
- Kjøleskap Linarie
- Kjøleskap Sogo
- Kjøleskap United
- Kjøleskap JennAir
- Kjøleskap Kalamazoo
- Kjøleskap Kaiser
- Kjøleskap Blomberg
- Kjøleskap Robinhood
- Kjøleskap De Dietrich
- Kjøleskap Orima
- Kjøleskap Zanussi
- Kjøleskap Lec Medical
- Kjøleskap Aspes
- Kjøleskap Benavent
- Kjøleskap Vedette
- Kjøleskap Kernau
- Kjøleskap Cookology
- Kjøleskap Hanseatic
- Kjøleskap Goddess
- Kjøleskap Edy
- Kjøleskap Thetford
- Kjøleskap Pando
- Kjøleskap U-Line
- Kjøleskap Equator
- Kjøleskap Romo
- Kjøleskap Rhino
- Kjøleskap Cooluli
- Kjøleskap Hoshizaki
- Kjøleskap SEIKI
- Kjøleskap Premium
- Kjøleskap Corona
- Kjøleskap Oranier
- Kjøleskap Germanica
- Kjøleskap Coors Light
- Kjøleskap FAURE
- Kjøleskap Turbo Air
- Kjøleskap Emperor's Select
- Kjøleskap Beverage-Air
- Kjøleskap Delfield
- Kjøleskap Galanz
- Kjøleskap Snaigė
- Kjøleskap Avantco
- Kjøleskap Ariston Thermo
- Kjøleskap Zanker
- Kjøleskap Miller Lite
- Kjøleskap Lanbo
- Kjøleskap Listo
- Kjøleskap Cool Head
- Kjøleskap Schmick
- Kjøleskap Brass Monkey
- Kjøleskap Helkama
- Kjøleskap Brandy Best
- Kjøleskap Waltham
- Kjøleskap Valberg
- Kjøleskap Rex
- Kjøleskap Momcube
- Kjøleskap LeCavist
- Kjøleskap Smart Brand
- Kjøleskap Castor
- Kjøleskap New World
- Kjøleskap Essentiel B
- Kjøleskap TESLA Electronics
- Kjøleskap Carpigiani
- Kjøleskap Lynx
- Kjøleskap BlueStar
- Kjøleskap Bompani
- Kjøleskap Prima
- Kjøleskap Sheffield
- Kjøleskap Stoves
- Kjøleskap Bushman
- Kjøleskap Richome
- Kjøleskap Sevenstars
- Kjøleskap Climadiff
- Kjøleskap Nemco
- Kjøleskap Haden
Nyeste Kjøleskap Manualer
15 August 2025
15 August 2025
15 August 2025
15 August 2025
15 August 2025
15 August 2025
15 August 2025
15 August 2025
15 August 2025
15 August 2025
