Side 1/44
W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 USA
PHONE: 262.251.3800 • 800.558.8744
USA/CANADA
FAX: 262.251.7067 • 800.329.8744
U.S.A. ONLY
www.alto-shaam.com
M N - 2 8 8 2 0 • 0 3 / 1 1
p r i n t e d i n u . s . a .
Heated Display Cases
Full Service or Self Service
Models:
ED2-48; ED2SYS-48
ED2-48/P; ED2SYS-48/P
EU2SYS-48; EU2SYS-48/P
ED2-72; ED2SYS-72
ED2-72/P; ED2SYS-72/P
ED2-72/PL; ED2SYS-72/PL
ED2-72/PR; ED2SYS-72/PR
EU2SYS-72; EU2SYS-72/P
EU2SYS-72/PL
EU2SYS-72/PR
ED2-96; ED2SYS-96
ED2-96/PL; ED2SYS-96/PL
ED2-96/PR; ED2SYS-96/PR
EU2SYS-96; EU2SYS-96/P
EU2SYS-96/PL
EU2SYS-96/PR
•InstallatIon
•operatIon
•MaIntenance
ED2-48
ED2-96
ED2sys-48
ED2sys-72
ED2sys-96
ED2-72
i
Delivery ..................................1
Unpacking ................................1
Safety Procedures and Precautions.............2
Installation3
Installation Requirements ..................3
Clearance Requirements ..................3
Leveling ...............................3
Cutting Board Installation ..................3
Dimension Drawings .....................4-6
Electrical Connection .....................7
Options & Accessories ....................8
Operating Instructions
User Safety Information ...................9
Start-up Operation .......................9
Operating Procedures.................... 10
Pan Configurations ....................11-13
General Holding Guidelines ............... 14
Care and Cleaning
Cleaning and Preventative Maintenance ...... 15
Protecting Stainless Steel Surfaces ......... 15
Cleaning Agents ........................ 15
Cleaning Materials ...................... 15
Equipment Care ........................ 16
Clean the Probes ....................... 16
Clean Daily ............................ 16
Sanitation ............................. 17
Service
Cable Replacement Kits .................. 18
ED2 Series, Full Assembly, Front View .....19-22
ED2 Series, Base Assembly ............... 23
ED2 Series, Inner Top Assembly ........... 24
BU2 Cart, Full Assembly ................. 25
BU2 Short Cart, Full Assembly ............. 26
Wire Diagrams
ED2(SYS)-48 & /P, 120/208-240V........... 27
ED2(SYS)-48 w/outlets, 120/208-240V ....... 28
ED2(SYS)-48 & /P, 230V ................. 29
ED2(SYS)-72 & /P, /PL, /PR, 120/208-240V ... 30
ED2(SYS)-72 w/outlets, 120/208-240V ....... 31
ED2(SYS)-72 & /P, 230V ................. 32
ED2(SYS)-72 & /P, /PL, /PR, 380-415V ...... 33
ED2(SYS)-96 & /P, /PL, /PR, 120/208-240V ... 34
ED2(SYS)-96 w/outlets, 120/208-240V ....... 35
ED2(SYS)-96 & /P, 230V ................. 36
ED2(SYS)-96 & /P, /PL, /PR, 380-415V ...... 37
Deli Probe Display Optional Kit ............. 38
BU2-48; BU2-48 Short ................... 39
BU2-72; BU2-72 Short ................... 40
BU2-96; BU2-96 Short ................... 41
Warranty
Transportation Damage and Claims ..Back Cover
Limited Warranty.................Back Cover
ED2 & EU2 Series Operation & Care Manual • 1
DElIVEry
This Alto-Shaam appliance has been
thoroughly tested and inspected to ensure only
the highest quality unit is provided. Upon
receipt, check for any possible shipping damage
and report it at once to the delivering carrier.
See Transportation Damage and Claims section
located in this manual.
This appliance, complete with unattached
items and accessories, may have been delivered
in one or more packages. Check to ensure that all
standard items and options have been received
with each model as ordered.
Save all the information and instructions
packed with the appliance. Complete and return
the warranty card to the factory as soon as
possible to ensure prompt service in the event of a
warranty parts and labor claim.
This manual must be read and understood
by all people using or installing the equipment
model. Contact the Alto-Shaam Tech Team Service
Department if you have any questions concerning
installation, operation, or maintenance.
notE: All claims for warranty must include the
full model number and serial number of
the unit.
unPacKInG
1. Carefully remove the
appliance from the
carton or crate.
notE: Do not discard the
carton and other
packaging material
until you have
inspected the unit
for hidden damage
and tested it for
proper operation.
2. Read all instructions in this manual carefully
before initiating the installation of this appliance.
DO NOT DISCARD THIS MANUAL.
This manual is considered to be part of the
appliance and is to be provided to the owner
or manager of the business or to the person
responsible for training operators. Additional
manuals are available from the Alto-Shaam
Tech Team Service Department.
3. Remove all protective plastic film, packaging
materials, and accessories from the appliance
before connecting electrical power. Store any
accessories in a convenient place for future use.
®
®
