Side 1/60

USER MANUAL

Washing machine

WM75.1

Carefully read the instructions for use before using the washing machine.

W4096R/1/2/3

Safety precautions 3

Washing machine description 6

Detergent compartment 6

Before using the appliance for the ﬁ rst time 7

Installation and connection 10

Tips before washing 17

Washing process, step by step (1 – 8) 19

System settings 31

Special features 35

Cleaning and maintenance 39

Errors – what to do? 44

Service 49

Technical information 50

Program table 53

Table: washing mode/temperature 56

Table options 57

Disposal 58

Quick guide 59

Original instructions

The following symbols are used throughout the manual and they have the following meanings:

Information, advice, tip, or recommendation Warning – danger of hot surface

Warning – general danger Warning – danger of fire

Warning – danger of electric shock

See Quick guide on the last page.

Dear Customer,

We thank you for purchasing this quality ASKO product.

We hope it meets all your expectations. Scandinavian design combines pure lines, everyday functionality,

and high quality. These are the key characteristics of all our products, and the reason why they are highly

appreciated across the globe.

We kindly recommend you to read these instructions before using the appliance for the ﬁ rst time. The

instruction manual also includes information on how you can help protect the environment.

TABLE OF CONTENTS

GENERAL

Please read the instruction manual and save it for future reference.

• Please do not use the washing machine if you have not read and

understood these instructions or use ﬁ rst.

• Failure to observe the instructions for use or inappropriate use of the

washing machine may result in damage to the laundry or machine, or injury

to the user. Keep the instruction manual handy, near the washing machine.

• Instructions for use are available on our website at www.asko.com.

• Your washing machine is intended solely for household use.

• The appliance has to be connected to the water and power supply by a

trained expert.

• Any repair and maintenance pertaining to safety or performance should be

done by trained experts.

• To avoid hazard, damaged power cord may only be replaced by the

manufacturer, authorized service technician, or other authorized person.

• After installation, the washing machine should stand still for two hours before

it is connected to the power mains.

• The washing machine may not be connected to the power mains using an

extension cord.

• Do not connect the washing machine to an electrical outlet intended for an

electric shaver or hair dryer.

• To connect the washing machine to water supply, make sure to use the

supplied water supply hose and gaskets. Water pressure has to be between

0.1 and 1 MPa (approximately 1–10 kp/cm

, 1-10 bar, 10–100 N/cm

• Always use a new water supply hose to connect the appliance to water

supply; do not reuse an old water supply hose.

• After the washing cycle, close the water tap and pull out the washing

machine plug from the power socket.

• Only use the washing machine for washing laundry, as described in the

instruction manual. The machine is not intended for dry cleaning.

• In case of incorrect appliance connection, incorrect use, or servicing by an

unauthorized person, the user shall bear the cost of any damage.

• Only use detergents intended for the washing machine!

• Only use agents for machine washing and care of laundry. We shall not be

responsible for any damages or discolouration of gaskets and plastic parts

resulting from incorrect use of bleaching or colouring agents.

SAFETY PRECAUTIONS

Produkspesifikasjoner

Merke:	Asko
Kategori:	Vaskemaskin
Modell:	W4096R.W/3
Innebygd skjerm:	Ja
Vekt:	77500 g
Bredde:	595 mm
Dybde:	585 mm
Høyde:	850 mm
Dørhengsel:	Venstre
Energieffektivitetsklasse:	A
Barnelås:	Ja
Døråpning:	Sideåpning
Vannforbruk per syklus:	49 l
Støynivå (vask):	- dB
Støyutslippsklasse:	B
Antall vaskeprogrammer:	23
Energiforbruk per 100 sykluser:	49 kWh
Pakkevekt:	80700 g
Doseringsassistent:	Ja
Justerbar temperatur:	Ja
Automatisk doseringssystem:	Ja
Feilmeldingsindikator:	Ja
Nominell kapasitet:	9 kg
AC-inngangsspenning:	220 - 240 V
AC-inngangsfrekvens:	50 Hz
Energieffektivitetsskala:	A til G
Vaskeprogrammer:	Auto, Bedding, Blouse/shirt, Cotton, Daily care, Easy care, Eco, Hand/wool, Hygiene/anti-allergy, Intensive/outdoor, Jeans/denim, Mix, Pre-wash, Quick, Rinse, Spin, Steam, Timed
Strømforbruk (standby):	0.3 W
Kabellengde:	2.1 m
Produktfarge:	Hvit
Pakkedybde:	661 mm
Pakkehøyde:	920 mm
Pakkebredde:	640 mm
Skjermtype:	LCD
Kontrolltype:	Buttons, Rotary
Sentrifugeringsklasse:	A
Støynivå (spinn):	76 dB
Lastetype:	Frontmatet
Motortype:	Induksjon
Restfuktighet:	44
Aquastop-funksjon:	Ja
Menyspråk:	Multi
Dybde med åpen dør:	942 mm
Strøm:	10 A
Plassering av innretning:	Frittstående
Tilkoblet nettbelastning:	2200 W
Strømforbruk, av:	0.3 W
Dør farge:	Hvit
Døråpeningsvinkel:	110 °
Lenge på tilkoblingsslange:	1.5 m
Lengde utløpsslange:	1.6 m
Justerbare bein:	Ja
Gjenværende tid angis:	Ja
Forsinket start:	24 timer
Forsinket start timer:	Ja
Trommelvolum:	60 l
Trommelmateriale:	Rustfritt stål
Materiale til kar:	Rustfritt stål
Maksimal sentrifugeringshastighet:	1600 RPM
Syklustid (maksimum):	210 min
Justerbar spinnhastighet:	Ja
Belastningsbalansering:	Ja
Inverteringsteknologi:	Ja
Overflow beskyttelse:	Ja
Mulighet for å legge til plagg (opphold):	Ja
Trommelrensing:	Ja
Tittevindu:	Ja
Energiforbruk ved vask per syklus:	0.494 kWh
Maksimum vaske temperatur:	90 °C
Beinjustering:	10 mm
