Side 1/30
VG27A/VG27B series
LCD Monitor
User Guide
ii
First Edition
April 2019
Copyright © 2019 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or tran
slated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM
ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN
THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
iii
Contents
1.3.1 Front view ....................................................................... 1-2
1.3.2 Back view ........................................................................ 1-3
1.3.3 GamePlus Function ........................................................ 1-4
1.3.4 GameVisual Function ...................................................... 1-5
3.1.1 How to recongure .......................................................... 3-1
3.1.2 OSD function introduction ............................................... 3-1
iv
Notices
Federal.Communications.Commission.Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the graphics card is
required to assure compliance with FCC regulations. Changes or modications
to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.
Canadian.Department.of.Communications.Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the
Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.
This Class B digital apparatus meets all requirements of the Canadian Interference
- Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Réglement
sur le matériel brouiller du Canada.
v
Safety information
• Before setting up the monitor, carefully read all the documentation that came
with the package.
• Topreventreorshockhazard,neverexposethemonitortorainormoisture.
• Never try to open the monitor cabinet. The dangerous high voltages inside the
monitor may result in serious physical injury.
• Ifthepowersupplyisbroken,donottrytoxitbyyourself.Contactaqualied
service technician or your retailer.
• Before using the product, make sure all cables are correctly connected and the
power cables are not damaged. If you detect any damage, contact your dealer
immediately.
• Slots and openings on the back or top of the cabinet are provided for
ventilation. Do not block these slots. Never place this product near or over a
radiator or heat source unless proper ventilation is provided.
• The monitor should be operated only from the type of power source indicated
on the label. If you are not sure of the type of power supply to your home,
consult your dealer or local power company.
• Use the appropriate power plug which complies with your local power standard.
• Donotoverloadpowerstripsandextensioncords.Overloadingcanresultin
reorelectricshock.
• Avoiddust,humidity,andtemperatureextremes.Donotplacethemonitorin
any area where it may become wet. Place the monitor on a stable surface.
• Unplug the unit during a lightning storm or if it will not be used for a long period
of time. This will protect the monitor from damage due to power surges.
• Neverpushobjectsorspillliquidofanykindintotheslotsonthemonitor
cabinet.
• To ensure satisfactory operation, use the monitor only with UL listed
computerswhichhaveappropriateconguredreceptaclesmarkedbetween
100-240VAC.
• Ifyouencountertechnicalproblemswiththemonitor,contactaqualied
service technician or your retailer.
• Adjustmentofthevolumecontrolaswellastheequalizertoothersettings
than the center position may increase the ear-/headphones output voltage and
therefore the sound pressure level.
• The adapter is only used for this monitor, do not use it for other purpose.
Your device uses one of the following power supplies:
- Manufacturer: Delta Electronics Inc., Model: ADP-65GD B/ADP-65GD D.
This symbol of the crossed out wheeled bin indicates that the product (electrical,
electronicequipment,andmercury-containingbuttoncellbattery)shouldnot
be placed in municipal waste. Please check local regulations for disposal of
electronic products.
1-1ASUS VG27 Series LCD Monitor
1.1 Welcome!
Thank you for purchasing the ASUS
®
LCD monitor!
The latest widescreen LCD monitor from ASUS provides a broader, brighter and
crystal-clear display, plus a host of features that enhance your viewing experience.
With these features, you can enjoy the convenience and delightful visual
experience that the monitor brings to you!
1.2 Package contents
Check your package for the following items:
LCD monitor
Monitor base
Quick start guide
Warranty card
Power adapter
Power cord
DisplayPort cable (optional)
HDMI cable (optional)
If any of the above items is damaged or missing, contact your retailer
immediately.
1-3ASUS VG27 Series LCD Monitor
• Displays the input selection bar when the monitor enters standby mode
or displays the “NO SIGNAL“ message.
5. Power button/power indicator
• Turns the monitor on/off.
• The color definition of the power indicator is as the below table.
White ON
Amber Standby mode/No signal
OFF OFF
7
4 5 6
This port is for connection with an HDMI compatible device.
. This port is for connection with an HDMI compatible device.
. This port is for connection with a DisplayPort compatible
device.
This port is only available when an HDMI/DisplayPort cable
is connected.
This port connects the power cord.
.
1-4 Chapter 1: Product introduction
The GamePlus function provides a toolkit and creates a better gaming environment
for users when playing different types of games. The crosshair overlay with four
different crosshair options lets you choose the one that best suits the game you're
playing. There's also an onscreen timer you can position on the left of the display
so you can keep track of the elapsed gaming time; while the FPS (frames per
second) counter lets you know how smooth the game is running. Display Alignment
displays alignment lines on 4 sides of the screen, serving as an easy and handy
tool for you to line up multiple monitors perfectly.
To active GamePlus:
1. Press the GamePlus hotkey.
2. Move the ( ) button up/down to select among different functions.
3. Press the ( ) button or move the ( ) button right to confirm the
function you choose, and move the ( ) button up/down to navigate
through the settings. Move the ( ) button left to go back, off, and exit.
4. Highlight the desired setting and press the ( ) button to activate it.
Press the button to inactivate it.
GamePlus Main Menu GamePlus — Crosshair GamePlus — Timer
NEXT BACK/EXIT
GamePlus
FPS
Crosshair
Timer
FPS Counter
Display Alignment
(Practice Mode)
NEXT BACK/EXIT
GamePlus
NEXT BACK/EXIT
GamePlus
1-5ASUS VG27 Series LCD Monitor
The GameVisual function helps you select among different picture modes in a
convenient way.
To active GameVisual:
Press the GameVisual hotkey repeatedly to select.
: This is the best choice for scenery photo displaying with
GameVisual
TM
Video intelligence Technology.
: This is the best choice for racing game playing with
GameVisual
TM
Video intelligence Technology.
: This is the best choice for movie watching with
GameVisual
TM
Video intelligence Technology.
: This is the best choice for Real-Time Strategy (RTS)/
Role-Playing Game (RPG) playing with GameVisual
TM
Video intelligence
Technology.
: This is the best choice for First Person Shooter game playing
with GameVisual
TM
Video intelligence Technology.
: This is the best choice for viewing photos and graphics
from PCs.
: This is the best choice for multiplayer online battle arena
game playing with GameVisual
TM
Video intelligence Technology.
• In the Racing mode, the following function(s) are not user-congurable:
Saturation, Skin Tone, Sharpness, ASCR.
• In the sRGB mode, the following function(s) are not user-configurable:
Brightness, Contrast, Saturation, Color Temp., Skin Tone, Sharpness,
ASCR.
• In the MOBA mode, the following function(s) are not user-configurable:
Saturation, Skin Tone, Sharpness, ASCR.
1-6 Chapter 1: Product introduction
2-1ASUS VG27 Series LCD Monitor
2.1 Assembling the monitor arm/base
To assemble the monitor base:
1. Have the front of the monitor face down on a table.
2. Attach the base into the arm, making sure the tab on the arm fits into the groove
on the base.
3. Fix the base to the arm by fastening the bundled screw.
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
2-2 Chapter 2: Setup
2.2 Adjusting the monitor
• For optimal viewing, we recommend that you look at the full face of the
monitor, then adjust the monitor to the angle that is most comfortable for you.
• Hold the stand to prevent the monitor from falling when you change its angle.
• The recommended adjusting angle is +33˚ to -5˚ (for tilt)/+90˚ to -90˚ (for
swiveling/ +130 mm (for height adjustment)/90˚ (for portrait view).
130mm
90° 90°
0°
-5°~+33°
(Tilt) (Swivel) (Height adjustment)
It is normal that the monitor slightly shakes while you adjust the viewing angle.
Pivoting.the.monitor
1. Lift the monitor to the highest position.
2. Tilt the monitor to its maximum angle.
3. Pivot the monitor to the angle you need.
-5°~+33°
0°
90°
0°
- 90°
It is normal that the monitor slightly shakes while you adjust the viewing angle.
Produkspesifikasjoner
| Merke: | Asus |
| Kategori: | Følge |
| Modell: | TUF Gaming VG27AQE |
Trenger du hjelp?
Hvis du trenger hjelp med Asus TUF Gaming VG27AQE still et spørsmål nedenfor, og andre brukere vil svare deg
Følge Asus Manualer
9 April 2025
12 Mars 2025
5 Mars 2025
27 Februar 2025
27 Februar 2025
27 Februar 2025
27 Februar 2025
27 Februar 2025
27 Februar 2025
29 Januar 2025
Følge Manualer
- Følge Bauhn
- Følge LG
- Følge Hisense
- Følge Sharp
- Følge Vorago
- Følge Jensen
- Følge Gigabyte
- Følge AOC
- Følge Philips
- Følge TCL
- Følge Godox
- Følge Samsung
- Følge Kogan
- Følge Behringer
- Følge Sony
- Følge Planar
- Følge Festo
- Følge Xiaomi
- Følge BlueBuilt
- Følge Extron
- Følge HP
- Følge Panasonic
- Følge Lenovo
- Følge Medion
- Følge Fujitsu
- Følge JVC
- Følge EMOS
- Følge Optoma
- Følge Yealink
- Følge Christie
- Følge Dell
- Følge Brandson
- Følge Mybeo
- Følge CSL
- Følge Bearware
- Følge Viewsonic
- Følge Nec
- Følge Ag Neovo
- Følge Dahua Technology
- Følge Thermaltake
- Følge Simrad
- Følge Posiflex
- Følge Hikvision
- Følge Acer
- Følge Joy-it
- Følge Iiyama
- Følge Titan Army
- Følge Soundstream
- Følge MSI
- Følge Chauvet
- Følge V7
- Følge Cocopar
- Følge Asrock
- Følge Advantech
- Følge Orion
- Følge BenQ
- Følge Antelope Audio
- Følge DTEN
- Følge Crestron
- Følge Casalux
- Følge IOIO
- Følge Barco
- Følge GVision
- Følge Allen & Heath
- Følge Postium
- Følge OSEE
- Følge Ikan
- Følge Approx
- Følge Triton
- Følge Voxicon
- Følge Kramer
- Følge KRK
- Følge LC-Power
- Følge Vimar
- Følge HoverCam
- Følge AVer
- Følge HyperX
- Følge Continental Edison
- Følge ELO
- Følge Mobile Pixels
- Følge Ernitec
- Følge Peerless-AV
- Følge PreSonus
- Følge Enttec
- Følge Feelworld
- Følge Prestigio
- Følge Midas
- Følge Cooler Master
- Følge Jupiter
- Følge SWIT
- Følge KeepOut
- Følge Elvid
- Følge Hollyland
- Følge AOpen
- Følge Xenarc
- Følge Alogic
- Følge Delvcam
- Følge Adam
- Følge Hamlet
- Følge Wohler
- Følge Hannspree
- Følge Wimaxit
- Følge BookIT
- Følge Motrona
- Følge X-Rite
- Følge Phoenix Contact
- Følge Dynaudio
- Følge HELGI
- Følge TVLogic
- Følge Freedom Scientific
- Følge UPERFECT
- Følge Qian
- Følge IStarUSA
- Følge SideTrak
- Følge Lilliput
- Følge Desview
- Følge ProDVX
- Følge TRIUMPH BOARD
- Følge Japannext
- Følge Satco
- Følge PureTools
Nyeste Følge Manualer
9 April 2025
8 April 2025
8 April 2025
5 April 2025
5 April 2025
3 April 2025
2 April 2025
31 Mars 2025
31 Mars 2025
31 Mars 2025
