USER'S MANUAL

AXIS P5522 PTZ Dome Network Camera

About this document

This manual is intended for administ r a tors and users of the AXIS P55 22

PTZ Dom e Network Camera, an d is applicab le to ﬁrm ware 5.25 and

later. It includes instruction s for using and managing the product on

your network. Previous ex perience of networking will be of use when

using this product. Some knowledge of UNIX or Linux-based systems

may also be beneﬁcial, for developing shell s cripts and applications.

Later version of this document will be posted to the Axis website,

as required. See also the prod uct’ s online help, available via the

web-based interface.

Liability

Every care has been taken in the preparation of this manual. Please

inform your local Axis ofﬁce of any inaccuracies or omissions. Axis

Communications AB cannot be held responsible for any technical or

typographical errors and reserves the right to make changes to the

product and manuals w ithout prior notice. Axis Communications AB

makes no warranty of any kind with regard to the material contained

within this document, in cluding, but not limited to, the implied

warranties of merch antability and ﬁtnes s for a partic u lar purpose. Axis

Communications AB shall not be liable nor responsib le for incidental or

consequential damages in connection with the furnishing, performance

or use of this material.

Intellectual Property R ights

Axis AB has intellectual property rights relating to technology embodied

in the product described in this document. In particular, and without

limitation, these in tel lectual property rights may in clude one or more

of the patents list e d at http://www.axis.co m/patent.htm and one or

more additional patents or pending pat e nt applications in the US a nd

other countries.

This product contains licensed third-party software. Se e the menu item

“About” in the product’s user interface for more information.

This product contains source code copyright Apple Computer,

Inc.,underthetermsofApplePublicSourceLicense2.0(see

http://www.opensource.ap ple.com/apsl). The source code is available

from http://develo per .apple.com/darwin/p rojects/bonjour/

Equipment Modiﬁcations

This equipment must be ins talled and used in strict accordance with the

instructions given in the user docum entation. This equipment contains

no user-serviceable co mponents. Unauthorized equipment changes o r

modiﬁcations will invalidate all applicable regulatory certiﬁcations

and approvals.

Trademark Acknowledgments

Apple, Boa, Bo njour, Ethernet, Internet Explorer, Linux, Microsoft,

Mozilla, Real, SMPTE, QuickTime, UN I X, Win dows, WWW are registere

trademarks of the respective holders. Java and all Java-based

trademarks and lo gos are trademarks or registered trademarks of Oracle

and/or its afﬁliates. UPnP

is a certiﬁcation mark of the UPnP

Implementers Corporation.

Support

Should you require any technical assistance

,pleasecontactyourAxis

reseller. If your questions cannot be answered immediately, your

reseller will forward your queries through the appropriate channels to

ensure a rapid response. If you are connec

tedtotheInternet,youcan:

• download user documentation and software updates

• ﬁnd answers to resolved problems in the FAQ database. Search

by product, category, or phrase

• report problems to Axis support staff by logging in to your private

support area

• chat with Axis support staff (se lected countries only)

• visit Axis Support at www.axis.com/techsup/

AXIS P5522 PTZ Dome Network Camera

Table of contents

Hardwareoverview .......................................... 4

Connectors .................................................... 4

LEDindicators .................................................. 5

Accessingtheproduct ....................................... 6

Accessfromabrowser ........................................... 6

AccessfromtheInternet .......................................... 7

Settherootpassword ............................................ 7

TheLiveViewpage .............................................. 8

Mediastreams .............................................. 11

HowtostreamH.264 ............................................ 11

MJPEG ........................................................ 11

AXISMediaControl(AMC) ........................................ 11

Alternativemethodsofaccessingthevideostream .................... 12

Accessingaudiostreams .......................................... 13

Settinguptheproduct ....................................... 14

BasicSetup .................................................... 14

VideoandAudio ............................................ 15

VideoStream ................................................... 15

Stream Proﬁles ................................................. 16

CameraSettings ................................................ 16

Overlay ........................................................ 18

PrivacyMask ................................................... 18

AudioSettings .................................................. 18

AudioClips .................................................... 20

Live View Conﬁg ............................................ 21

PTZ (Pan Tilt Zoom) ......................................... 24

Presetpositions ................................................. 24

GuardTour ..................................................... 24

OSDIZones .................................................... 25

Advanced ...................................................... 25

ControlQueue .................................................. 26

Applications . .............................................. 27

Events .................................................... 28

EventServers ................................................... 28

EventTypes .................................................... 29

Gatekeeper .................................................... 31

Motiondetection ............................................... 31

Audiodetection ................................................. 33

PortStatus ..................................................... 33

Recordings ................................................. 34

Eventrecordings ................................................ 34

Continuousrecording ............................................ 35

SystemOptions ............................................. 37

Security ....................................................... 37

Date&Time .................................................... 38

Network ....................................................... 39

Storage ....................................................... 43

Ports&Devices ................................................. 44

Maintenance ................................................... 44

Support ....................................................... 44

Advanced ...................................................... 45

Resettofactorydefaultsettings ................................... 46

Multi-ConnectorCable(soldseparately) ........................ 47

Troubleshooting ............................................ 49

Checking the ﬁrmware ........................................... 49

Upgrading the ﬁrmware .......................................... 49

Emergencyrecoveryprocedure ..................................... 49

Symptoms,possiblecausesandremedialactions ...................... 50

Technical Speciﬁcations ...................................... 53

Performanceconsiderations ....................................... 55

Produkspesifikasjoner

Merke:	Axis
Kategori:	Sikkerhetskamera
Modell:	P5522
Vekt:	2000 g
Wi-Fi:	Nei
Maksimal oppløsning:	720 x 480 piksler
Strømkildetype:	PoE
Sertifisering:	IEC 60529 IP66, NEMA 250 Type 4X; IEC 60721-4-3 Class 4K1, 4C3, 4M3, EN/IEC 60068-2
Digital zoom:	12 x
Optisk zoom:	18 x
Internminne:	256 MB
Kablingsteknologi:	10/100Base-T(X)
Støttede nettverksprotokoller:	IPv4/v6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Progressiv skanning:	Ja
Flash-minne:	128 MB
Dimensjoner (B x D x H):	195 x 195 x 183 mm
AC-inngangsspenning:	100-240 V
Linsesynsvinkel, horisontal:	47 °
Bildefrekvens:	30 fps
Sensortype:	CMOS
Vippevinkelområde:	0 - 180 °
Strømforbruk (vanlig bruk):	37 W
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 50 °C
Lukkerhastighet:	1 s
nattsyn:	Ja
Panoreringsomfang:	0 - 360 °
Minimumsbelysning:	0.01 lx
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	20 - 80
Støttede plasseringer/plasseringer som kan benyttes:	Inne & Ute
Videoformat som støttes:	H.264, M-JPEG, MPEG
Strøm over Ethernet (PoE):	Ja
