Side 1/69

AXISQ3617-VENetworkCamera

UserManual

AboutthisDocument

Thismanualisintendedforadministratorsandusersof

AXISQ3617-VEFixedDomeNetworkCamera,andisapplicableto

rmware6.15andlater.Itincludesinstructionsforusingandmanaging

theproductonyournetwork.Previousexperienceofnetworking

willbeofusewhenusingthisproduct.SomeknowledgeofUNIXor

Linux-basedsystemsmayalsobeusefulwhendevelopingshellscripts

andapplications.Laterversionsofthisdocumentwillbepostedat

www.axis.com.Seealsotheproduct’sonlinehelp,availablethrough

theweb-basedinterface.

LegalConsiderations

Videosurveillancecanberegulatedbylawsthatvaryfromcountryto

country.Checkthelawsinyourlocalregionbeforeusingthisproduct

forsurveillancepurposes.

Thisproductincludesone(1)H.264decoderlicense.Topurchase

furtherlicenses,contactyourreseller.

Liability

Everycarehasbeentakeninthepreparationofthisdocument.Please

informyourlocalAxisofceofanyinaccuraciesoromissions.Axis

CommunicationsABcannotbeheldresponsibleforanytechnicalor

typographicalerrorsandreservestherighttomakechangestothe

productandmanualswithoutpriornotice.AxisCommunicationsAB

makesnowarrantyofanykindwithregardtothematerialcontained

withinthisdocument,including,butnotlimitedto,theimplied

warrantiesofmerchantabilityandtnessforaparticularpurpose.Axis

CommunicationsABshallnotbeliablenorresponsibleforincidentalor

consequentialdamagesinconnectionwiththefurnishing,performance

oruseofthismaterial.Thisproductisonlytobeusedforitsintended

purpose.

IntellectualPropertyRights

AxisABhasintellectualpropertyrightsrelatingtotechnologyembodied

intheproductdescribedinthisdocument.Inparticular,andwithout

limitation,theseintellectualpropertyrightsmayincludeoneormore

ofthepatentslistedatwww.axis.com/patent.htmandoneormore

additionalpatentsorpendingpatentapplicationsintheUSandother

countries.

Thisproductcontainslicensedthird-partysoftware.Seethemenuitem

“About”intheproduct’suserinterfaceformoreinformation.

ThisproductcontainssourcecodecopyrightAppleComputer,

Inc.,underthetermsofApplePublicSourceLicense2.0(see

www.opensource.apple.com/apsl).Thesourcecodeisavailablefrom

https://developer.apple.com/bonjour/

EquipmentModications

Thisequipmentmustbeinstalledandusedinstrictaccordancewiththe

instructionsgivenintheuserdocumentation.Thisequipmentcontains

nouser-serviceablecomponents.Unauthorizedequipmentchangesor

modicationswillinvalidateallapplicableregulatorycertications

andapprovals.

TrademarkAcknowledgments

AXISCOMMUNICATIONS,AXIS,ETRAX,ARTPECandVAPIXare

registeredtrademarksortrademarkapplicationsofAxisABinvarious

jurisdictions.Allothercompanynamesandproductsaretrademarksor

registeredtrademarksoftheirrespectivecompanies.

Apple,Boa,Apache,Bonjour,Ethernet,InternetExplorer,Linux,

Microsoft,Mozilla,Real,SMPTE,QuickTime,UNIX,Windows,Windows

VistaandWWWareregisteredtrademarksoftherespectiveholders.

JavaandallJava-basedtrademarksandlogosaretrademarksor

registeredtrademarksofOracleand/oritsafliates.UPnP

isa

certicationmarkoftheUPnP

ImplementersCorporation.

SD,SDHCandSDXCaretrademarksorregisteredtrademarksofSD-3C,

LLCintheUnitedStates,othercountriesorboth.Also,miniSD,microSD,

miniSDHC,microSDHC,microSDXCarealltrademarksorregistered

trademarksofSD-3C,LLCintheUnitedStates,othercountriesorboth.

RegulatoryInformation

Europe

ThisproductcomplieswiththeapplicableCEmarkingdirectives

andharmonizedstandards:

•ElectromagneticCompatibility(EMC)Directive2014/30/EU.See

ElectromagneticCompatibility(EMC)onpage2.

•LowVoltage(LVD)Directive2014/35/EU.SeeSafetyonpage3.

•RestrictionsofHazardousSubstances(RoHS)Directive201 1/65/EU.

SeeDisposalandRecyclingonpage3.

Acopyoftheoriginaldeclarationofconformitymaybeobtainedfrom

AxisCommunicationsAB.SeeContactInformationonpage3.

ElectromagneticCompatibility(EMC)

Thisequipmenthasbeendesignedandtestedtofulllapplicable

standardsfor:

•Radiofrequencyemissionwheninstalledaccordingtothe

instructionsandusedinitsintendedenvironment.

•Immunitytoelectricalandelectromagneticphenomenawhen

installedaccordingtotheinstructionsandusedinitsintended

environment.

USA

Thisequipmenthasbeentestedusingashieldednetworkcable(STP)

andfoundtocomplywiththelimitsforaClassBdigitaldevice,

pursuanttopart15oftheFCCRules.Theselimitsaredesigned

toprovidereasonableprotectionagainstharmfulinterferenceina

residentialinstallation.Thisequipmentgenerates,usesandcanradiate

radiofrequencyenergyand,ifnotinstalledandusedinaccordance

withtheinstructions,maycauseharmfulinterferencetoradio

communications.However,thereisnoguaranteethatinterference

willnotoccurinaparticularinstallation.Ifthisequipmentdoes

causeharmfulinterferencetoradioortelevisionreception,which

canbedeterminedbyturningtheequipmentoffandon,theuseris

encouragedtotrytocorrecttheinterferencebyoneormoreofthe

followingmeasures:

•Reorientorrelocatethereceivingantenna.

•Increasetheseparationbetweentheequipmentandreceiver.

•Connecttheequipmentintoanoutletonacircuitdifferentfrom

thattowhichthereceiverisconnected.

•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

Theproductshallbeconnectedusingashieldednetworkcable(STP)

thatisproperlygrounded.

Canada

ThisdigitalapparatuscomplieswithCANICES-3(ClassB).Theproduct

shallbeconnectedusingashieldednetworkcable(STP)thatis

properlygrounded.Cetappareilnumériqueestconformeàlanorme

CANNMB-3(classeB).Leproduitdoitêtreconnectéàl'aided'uncâble

réseaublindé(STP)quiestcorrectementmisàlaterre.

Europe

ThisdigitalequipmentfulllstherequirementsforRFemission

accordingtotheClassBlimitofEN55022.Theproductshallbe

connectedusingashieldednetworkcable(STP)thatisproperly

grounded.

Thisproductfulllstherequirementsforemissionandimmunity

accordingtoEN50121-4andIEC62236-4railwayapplications.

Thisproductfulllstherequirementsforimmunityaccording

toEN61000-6-1residential,commercialandlight-industrial

environments.

Thisproductfulllstherequirementsforimmunityaccordingto

EN61000-6-2industrialenvironments.

Thisproductfulllstherequirementsforimmunityaccordingto

EN55024ofceandcommercialenvironments.

Australia/NewZealand

ThisdigitalequipmentfulllstherequirementsforRFemission

accordingtotheClassBlimitofAS/NZSCISPR22.Theproductshall

beconnectedusingashieldednetworkcable(STP)thatisproperly

grounded.

Japan

この装置は、クラスB情報技術装置です。この装置は、家

庭環境で使⽤することを⽬的としていますが、この装置が

ラジオやテレビジョン受信機に近接して使⽤されると、受

信障害を引き起こすことがあります。取扱説明書に従って

正しい取り扱いをして下さい。本製品は、シールドネット

ワークケーブル(STP)を使⽤して接続してください。また

適切に接地してください。

Korea

이기기는가정용(B급)전자파적합기기로서주로가정에

서사용하는것을목적으로하며,모든지역에서사용할수

있습니다.적절히접지된STP(shieldedtwistedpair)케이

블을사용하여제품을연결하십시오.

Safety

ThisproductcomplieswithIEC/EN/UL60950-1and

IEC/EN/UL60950-22,SafetyofInformationTechnology

Equipment.Theproductshallbegroundedeitherthroughashielded

networkcable(STP)orotherappropriatemethod.

Battery

TheAxisproductusesa3.0VCR2032lithiumbatteryasthepower

supplyforitsinternalreal-timeclock(RTC).Undernormalconditions

thisbatterywilllastforaminimumofveyears.

LowbatterypoweraffectstheoperationoftheRTC,causingittoreset

ateverypower-up.Whenthebatteryneedsreplacing,alogmessage

willappearintheproduct’sserverreport.Formoreinformationabout

theserverreport,seetheproduct´ssetuppagesorcontactAxissupport.

Thebatteryshouldnotbereplacedunlessrequired,butifthebattery

doesneedreplacing,contactAxissupportatwww.axis.com/techsupfor

assistance.

Lithiumcoincell3.0Vbatteriescontain1,2-dimethoxyethane;ethylene

glycoldimethylether(EGDME),CASno.110-71-4.

WARNING

•Riskofexplosionifthebatteryisincorrectlyreplaced.

•Replaceonlywithanidenticalbatteryorabatterywhichis

recommendedbyAxis.

•Disposeofusedbatteriesaccordingtolocalregulationsor

thebatterymanufacturer'sinstructions.

DisposalandRecycling

Whenthisproducthasreachedtheendofitsusefullife,disposeof

itaccordingtolocallawsandregulations.Forinformationabout

yournearestdesignatedcollectionpoint,contactyourlocalauthority

responsibleforwastedisposal.Inaccordancewithlocallegislation,

penaltiesmaybeapplicableforincorrectdisposalofthiswaste.

Europe

Thissymbolmeansthattheproductshallnotbedisposedof

togetherwithhouseholdorcommercialwaste.Directive2012/19/EU

onwasteelectricalandelectronicequipment(WEEE)isapplicablein

theEuropeanUnionmemberstates.Topreventpotentialharmto

humanhealthandtheenvironment,theproductmustbedisposed

ofinanapprovedandenvironmentallysaferecyclingprocess.For

informationaboutyournearestdesignatedcollectionpoint,contact

yourlocalauthorityresponsibleforwastedisposal.Businessesshould

contacttheproductsupplierforinformationabouthowtodispose

ofthisproductcorrectly.

ThisproductcomplieswiththerequirementsofDirective2011/65/EUon

therestrictionoftheuseofcertainhazardoussubstancesinelectrical

andelectronicequipment(RoHS).

China

Thisproductcomplieswiththerequirementsofthelegislative

actAdministrationontheControlofPollutionCausedbyElectronic

InformationProducts(ACPEIP).

ContactInformation

AxisCommunicationsAB

Emdalavägen14

22369Lund

Sweden

Tel:+46462721800

Fax:+4646136130

www.axis.com

Support

Shouldyourequireanytechnicalassistance,pleasecontactyourAxis

reseller.Ifyourquestionscannotbeansweredimmediately,your

resellerwillforwardyourqueriesthroughtheappropriatechannelsto

ensurearapidresponse.IfyouareconnectedtotheInternet,youcan:

•downloaduserdocumentationandsoftwareupdates

•ndanswerstoresolvedproblemsintheFAQdatabase.Search

byproduct,category,orphrase

•reportproblemstoAxissupportstaffbyloggingintoyourprivate

supportarea

•chatwithAxissupportstaff

•visitAxisSupportatwww.axis.com/techsup/

LearnMore!

VisitAxislearningcenterwww.axis.com/academy/forusefultrainings,

webinars,tutorialsandguides.

Produkspesifikasjoner

Merke:	Axis
Kategori:	Sikkerhetskamera
Modell:	Q3617-VE
Vekt:	2300 g
Dybde:	166 mm
Wi-Fi:	Nei
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	3072 x 2048 piksler
Videokomprimeringsformater:	H.264, M-JPEG, MPEG4
Diameter:	198 mm
Strømkildetype:	PoE
Antall kameraer:	1
HTTPS-kryptering:	Ja
Strømforbruk (maks.):	11.4 W
Digital zoom:	2 x
Optisk zoom:	2.2 x
Internminne:	1000 MB
Støyreduksjon:	Ja
Kablingsteknologi:	10/100Base-T(X)
Nettverksstandard:	IEEE 802.3af, IEEE 802.3at
Støttede nettverksprotokoller:	IPv4/v6, HTTP, HTTPS, SSL/TLS, DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMP v1/v2c/v3, DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Progressiv skanning:	Ja
Flash-minne:	256 MB
PTZ-kontroll:	Ja
Rotasjonsvinkel:	270 °
Dag/natt-modus:	Ja
Antall språk:	11
Justering av bildekvalitet:	Brightness, Contrast, Sharpness
Wide Dynamic Range (WDR):	Ja
Iris:	Ja
Synsfelt:	101 °
Bildefrekvens:	30 fps
Sensortype:	CMOS
Produktfarge:	Hvit
Vippevinkelområde:	-81 - 81 °
Minnekortenhet:	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Støttede grafikkoppløsninger:	160 x 90, 3072 x 2048
Zoomfunksjon:	Ja
Brennviddeområde:	4.1 - 9 mm
Strømforbruk (vanlig bruk):	6.1 W
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	-40 - 60 °C
Oppbevaringstemperaturomåde (Celsius):	-40 - 65 °C
Innebygd kortleser:	Ja
Harmonisert system (HS)-kode:	85258900
Lukkerhastighet:	1/100000 - 2 s
nattsyn:	Ja
Formfaktor:	Kuppel
Quality of Service (QoS) støtte:	Ja
CCD-sensorstørrelse:	1/1.8 "
IP-adressefiltrering:	Ja
Modell/Type:	IP-sikkerhetskamera
Kroppsmateriale:	Polykarbonat (PC)
Innebygd harddisk:	Nei
Internasjonal beskyttelses (IP)-kode:	IP67
Språkstøtte:	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, KOR, POR, RUS
Sikkerhetsalgoritmer:	802.1x RADIUS, HTTPS, SMTP-AUTH, SNMP, SSL/TLS
Minimumsbelysning:	0.03 lx
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	10 - 100
Monteringsbeslag inkludert:	Ja
Støttede plasseringer/plasseringer som kan benyttes:	Inne & Ute
Montasjetype:	Tak/Vegg
Totale megapiksler:	6 MP
Strøm over Ethernet (PoE):	Ja
Guide for hurtiginstallering:	Ja
Privacy maske:	Ja
Maksimal blenderåpning:	1.6
Infrarød (IR) avbruddsfilter:	Ja
Passordbeskyttelsestype:	Bruker
Fjerndrevet:	Ja
Ekstern visning:	Ja
Solskjold inkludert:	Ja
