Side 1/35
Table of Contents
Description
1. Technical Specifications 1
2. Identification Data 3
3. Location of Parts 5
4. Steering cum Ignition lock 7
5. Fuel Tank Cap / Fuel Tap 8
6. Speedometer Details 9
7. Speedometer Setting 11
8. Control Switches 13
9. Rear seat / Tool kit 15
10. Front Seat / Battery 16
11. Fitment of Front & Rear Seat 17
12. Daily Safety Checks 18
13. How to ride your Bike 19
14. Safe Riding Tips 23
15. Engine Oil 24
16. Wheels - Tube less Tyre 25
17. Battery 26
18. Periodic Maintenance Information 27
19. Brake Fluid 29
20. Periodic Maintenance & Lubrication Chart 30
21. Non Use Maintenance
Notice:
The description and illustration in this booklet
are not to be taken as binding on the
manufacturers. The essential features of the
type described and illustrated herein remaining
unaltered. Bajaj Auto Limited reserves the
right to carry out at any moment without
being obliged to bring this booklet upto-date
& to do modifications on the vehicle, parts or
accessories as may be convenient and
necessary.
Safety and Warning information :
Caution : This indicates that a potential
hazard which could result in vehicle
damage, if advice provided is not
followed.
Warning : This indicates that a potential
hazard or injury to you or other persons &
to the vehicle can happen, if advice
provided is not followed.
Engine : 4 Stroke, Single Cyl.
Bore x Stroke : 56.0 mm x 60.7 mm
Engine Displacement : 149.5 cc
Compression Ratio : 9.8 + 0.5 : 1
Idling Speed : 1400 + 100 RPM
Max. Net Power : 17 PS at 9500 RPM
Max. Net Torque : 13 Nm at 7000 RPM
Ignition System : DC
Spark Plug : 2 Nos
Spark Plug Gap : 0.7 ~ 0.8 mm
Transmission : 5 speed constant
mesh
Gear Shifting Pattern : 1 Down 4 Up
Engine Lubrication : Forced Lubrication
Starting Aid : Electric / Kick start
Front Brake : Petal Disc type
Rear Brake : Drum type
Fuel Tank Capacity
Full : 12 liters
Usable Reserve : 2.4 liters
Unusable Reserve : 0.2 liters
Dimensions : NS 150 AS 150
Length : 2017 mm 2070 mm
Width : 803.5 mm 803.5 mm
Height : 1075 mm 1205 mm
Wheel base : 1363 mm 1363 mm
Ground clearance : 176 mm 170 mm
Tyre Size
Front : 80/100-17,46P tubeless
Rear : 110/80-17,57P tubeless
Tyre Pressure
2
Front : 1.75 kgf/cm (25 PSI)
2
Rear (Solo) : 2.00 kgf/cm (28 PSI)
2
Rear (with pillion) : 2.25 kgf/cm (32 PSI)
Technical Specifications
1
Note :
• All dimensions are under UNLADEN condition.
• Above information is subject to change without
any notice.
Vehicle Kerb Weight : 140 kg.(For )
143 Kg.(For AS 150)
Gross Vehicle Weight : 270 kg. (For NS 150)
273 kg. (For AS 150)
NS 150
Electrical System : 12 Volts DC
Head Lamp : High Beam - 12V 55W
Low Beam - 12V 55W
Position Lamp : 3W (2 nos.)
Tail /Stop Lamp : LED type
Side Indicator lamp : 10W (4 nos.)
Neutral Indicator : Green LED
Hi Beam Indicator : Blue LED
Turn Signal Indicator : Green LED
Side Stand Indicator : LCD
Speedometer Lamp : LCD
Low Battery Indicator : Red LED
Low Oil Pressure : Red LED
Service Reminder : LCD
Bajaj Logo : Blue LED
Rear No. Plate Lamp : 3W
Horn : 12V DC
Battery : 12V - 4 Ah VRLA
2
Technical Specifications
