Bajaj Pulsar AS 200 Bruksanvisning
Bajaj
motorsykkel
Pulsar AS 200
Les nedenfor 📖 manual på norsk for Bajaj Pulsar AS 200 (39 sider) i kategorien motorsykkel. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/39
Table of Contents
Description
1. Technical Specifications 1
2. Identification Data 3
3. Location of Parts 5
4. Steering cum Ignition lock 8
5. Fuel Tank Cap / Fuel Tap 9
6. Speedometer Details 10
7. Speedometer Setting 12
8. Control Switches 14
9. Rear seat / Tool kit 16
10. Front Seat / Battery 17
11. Fitment of Front & Rear Seat 18
12. Removal & Fitment of Side Cover LH & RH 19
13. Daily Safety Checks 20
14. How to ride your Bike 21
15. Safe Riding Tips 25
16. Engine Oil 26
17. Wheels - Tube less Tyre 27
18. Battery 28
19. Engine Cooling System / Coolant 29
20. Periodic Maintenance Information 30
21. Brake Fluid 32
22. Periodic Maintenance & Lubrication Chart 33
23. Non Use Maintenance
Notice:
The description and illustration in this booklet
are not to be taken as binding on the
manufacturers. The essential features of the
type described and illustrated herein remaining
unaltered. Bajaj Auto Limited reserves the
right to carry out at any moment without
being obliged to bring this booklet upto-date
& to do modifications on the vehicle, parts or
accessories as may be convenient and
necessary.
Safety and Warning information :
Caution : This indicates that a potential
hazard which could result in vehicle
damage, if advice provided is not
followed.
Warning : This indicates that a potential
hazard or injury to you or other persons &
to the vehicle can happen, if advice
provided is not followed.
Engine : 4 Stroke, Single Cyl.
Bore x Stroke : 72.0 mm x 49.0 mm
Engine Displacement : 199.5 cc
Compression Ratio : 11 : 1
Idling Speed : 1350 ~ 1450 RPM
Max. Net Power : 23.5 PS at 9500 RPM
Max. Net Torque : 18.3 Nm at 8000 RPM
Ignition System : DC
Spark Plug : 3 Nos
Spark Plug Gap : 0.7 ~ 0.8 mm
Transmission : 6 speed constant
mesh
Gear Shifting Pattern : 1 Down 5 Up
Engine Lubrication : Pressurized oil supply
Engine Cooling : Liquid cooling
Starting Aid : Electric starter
Front Brake : Hydraulic Disc type
Rear Brake : Hydraulic Disc type
Fuel Tank Capacity
Full : 12 liters
Usable Reserve : 2.4 liters
Unusable Reserve : 0.2 liters
Dimensions : Pulsar NS Pulsar AS
Length : 2017 mm 2070 mm
Width : 804 mm 804 mm
Height : 1195 mm 1205 mm
Wheel base : 1363 mm 1363 mm
Ground clearance : 167 mm 167 mm
Tyre Size
Front : 100/80-17,52P tubeless
Rear : 130/70-17,61P tubeless
Tyre Pressure
2
Front : 1.75 kgf/cm (25 PSI)
2
Rear (Solo) : 2.00 kgf/cm (28 PSI)
2
Rear (with pillion) : 2.25 kgf/cm (32 PSI)
Technical Specifications
1
Note :
• All dimensions are under UNLADEN condition.
• Above information is subject to change without
any notice.
Electrical System : 12 Volts DC
Head Lamp : H4, 55/60W
Position Lamp : 3W (2 nos.)
Tail /Stop Lamp : LED type
Side Indicator lamp : 10W
Neutral Indicator : Green LED
Hi Beam Indicator : Blue LED
Turn Signal Indicator : Green LED
Side Stand Indicator : LED
Speedometer Lamp : LED
Rear No. Plate Lamp : 3W
Horn : 12V DC
Battery : 12V - 8 Ah VRLA
Vehicle Kerb Weight : 145 kg.(For NS 200)
153 Kg.(For AS 200)
Gross Vehicle Weight : 275 kg. (For NS 200)
283 kg. (For AS 200)
(Including rider & pillion)
Max. Speed : 136 km/hr.
2
Technical Specifications
