Side 1/38

Welcome

FP92G/FP92G

LCD Color Monitor

19.0" LCD Panel Size

User’s Manual

reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language

or computer language, in any form or by any means, electronic, mechanical, magnetic, optical,

chemical, manual or otherwise, without the prior written permission of BenQ Corporation.

Disclaimer

BenQ Corporation makes no representations or warranties, either expressed or implied, with

respect to the contents hereof and specifically disclaims any warranties, merchantability or fitness

for any particular purpose. Further, BenQ Corporation reserves the right to revise this publication

and to make changes from time to time in the contents hereof without obligation of BenQ

Corporation to notify any person of such revision or changes.

Please follow these safety instructions for best

performance, and long life for your monitor

Power Safety

• The AC plug isolates this equipment from the AC supply.

• The power supply cord serves as a power disconnect device for pluggable equipment. The socket

outlet should be installed near the equipment and be easily accessible.

• This product should be operated from the type of power indicated on the marked label. If you are

not sure of the type of power available, consult your dealer or local power company.

Care And Cleaning

• Cleaning. Always unplug your monitor from the wall outlet before cleaning. Clean the LCD

monitor surface with a lint-free, non-abrasive cloth. Avoid using any liquid, aerosol or glass

cleaners.

• Slots and openings on the back or top of the cabinet are for ventilation. They must not be blocked

or covered. Your monitor should never be placed near or over a radiator or heat source, or in a

built-in installation unless proper ventilation is provided.

• Never push objects or spill liquid of any kind into this product.

Servicing

• Do not attempt to service this product yourself, as opening or removing covers may expose you to

dangerous voltages or other risks. If any of the above mentioned misuse or other accident such as

dropping or mishandling occurs, contact qualified service personnel for servicing.

iii

Table of Contents

Getting started ...................................................................................................................... 4

Getting to know your monitor ............................................................................................ 5

Front View ...................................................................................................................5

Back View .....................................................................................................................5

How to install your monitor hardware ...............................................................................6

Viewing Angle Adjustment .........................................................................................8

Portrait Viewing Installation (Optional) ...................................................................9

Storing the Monitor ...................................................................................................11

Getting the most from your BenQ monitor ...................................................................... 12

How to install the monitor on a new computer ......................................................13

How to upgrade the monitor on an existing computer ..........................................14

How to install on Windows XP systems ...................................................................15

How to install on Windows 2000, ME, & 98 systems ..............................................17

How to complete the Windows Upgrade Device Driver Wizard ...........................18

How to adjust the screen resolution .................................................................................. 20

How to adjust the screen refresh rate ................................................................................ 21

How to set the picture optimization .................................................................................. 22

How to adjust your monitor .............................................................................................. 23

A Look at the Control Panel .....................................................................................23

Hot Key Mode ...........................................................................................................24

Main Menu Mode ......................................................................................................24

Troubleshooting ................................................................................................................. 32

Frequently Asked Questions (FAQ) .........................................................................32

Need More Help? .......................................................................................................33

Supported operating modes ............................................................................................... 34

Specifications ...................................................................................................................... 35

Produkspesifikasjoner

Merke:	BenQ
Kategori:	skjerm
Modell:	FP92G+
Berøringsskjerm:	Nei
Synsvinkel, horisontal:	160 °
Lydutgang:	Nei
Vekt (med stativ):	7000 g
Kontrastforhold:	550:1
Skjermoppløsning:	1280 x 1024 piksler
Strømforbruk (standby):	2 W
Produktfarge:	Sølv
Bredde (med stativ):	432 mm
Dybde (med stativ):	222 mm
Høyde (med stativ):	422.2 mm
Skjermdiagonal:	19 "
Antall DVI-D-porter:	1
Horisontalt frekvensområde:	31 - 81 kHz
Strømforbruk (vanlig bruk):	40 W
Antall VGA (D-Sub)-porter:	1
Synsvinkel, vertikal:	160 °
Oppdateringsresponstid:	8 ms
Pikselbredde:	0.294 mm
Panelmonterbart grensesnitt:	100 x 100 mm
Skjermlysstyrke (typisk):	250 cd/m²
Display antall farger:	16.78 million farger
Kabellåsport:	Ja
Vertikal scanningsratio:	56 - 76 Hz
Kabellåstype:	Kensington
Gjennomsnittstid mellom feil (MTBF):	60000 timer
Dreietapp/dreiemekanisme:	-171 - 171 °
Omdreiningsakse/midtpunkt:	Ja
Lydkontakter:	Nei
