Side 1/28

BL A C K B O X

Extend DVI-D video and stereo audio up to

1.5 kilometers over a strand of single-mode fiber or

distribute DVI-D and stereo audio to 32 displays.

Mini Extender Kit for DVI-D and Stereo Audio over Fiber

AVX-DVI-FO-MINI AVX-DVI-FO-SP4

AVX-DVI-FO-MINI-RX AVX-DVI-FO-SP8

AVX-DVI-FO-SPCS AVX-DVI-FO-USBPS

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S.

call 724-746-5500) FREE technical support 24 hours a day, 7 days

a week: Call 724-746-5500 or fax 724-746-0746 Mailing address:

Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

Web site: www.blackbox.com • E-mail: info@blackbox.com

Customer

Support

Information

724-746-5500 | blackbox.com

Page 2

FCC and IC RFI Statements/NOM Statement

FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY

CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS

This equipment generates, uses, and can radiate radio-frequency energy, and if

not installed and used properly, that is, in strict accordance with the manufacturer’s

instructions, may cause inter ference to radio communication. It has been tested

and found to comply with the limits for a Class A computing device in accordance

with the specifications in Subpart B of Part 15 of FCC rules, which are designed

to provide reasonable protection against such interference when the equipment

is operated in a commercial environment. Operation of this equipment in a

residential area is likely to cause interference, in which case the user at his own

expense will be required to take whatever measures may be necessary to correct

the interference.

Changes or modifications not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

This digital apparatus does not exceed the Class A limits for radio noise emis sion

from digital apparatus set out in the Radio Interference Regulation of Industry

Canada.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant

les limites applicables aux appareils numériques de classe A prescrites dans le

Règlement sur le brouillage radioélectrique publié par Industrie Canada.

Normas Oficiales Mexicanas (NOM)Electrical Safety Statement

INSTRUCCIONES DE SEGURIDAD

1. Todas las instrucciones de seguridad y operación deberán ser leídas antes

de que el aparato eléctrico sea operado.

2. Las instrucciones de seguridad y operación deberán ser guardadas para

referencia futura.

3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de

operación deben ser respetadas.

Produkspesifikasjoner

Merke:	Black Box
Kategori:	AV ekstender
Modell:	AVX-DVI-FO-MINI
Vekt:	100 g
Bruksanvisning:	Ja
Maksimal oppløsning:	1920 x 1200 piksler
Lydutgang:	1
Kompatible produkter:	AVX-DVI-FO-SP8\r\nAVX-DVI-FO-SP4\r\nAVX-DVI-FO-SPCS\r\nAVX-DVI-FO-USBPS\r\nAVX-DVI-FO-PS\r\nEFN310-LCLC\r\nEFNT010-LCLC
Dimensjoner (B x D x H):	69 x 30 x 15 mm
Driftsspenning:	5 V
Produktfarge:	Sort
Støttede grafikkoppløsninger:	1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Støttede videofunksjoner:	1080p
Modell/Type:	AV-sender og -mottaker
Ekstern strømadapter:	Ja
DC-inngangskontakt:	Ja
Lydsystem:	Stereo
Lydkontakter:	1
DVI inngangs-porter:	1
DVI utgangs-porter:	1
Største båndbredde for port:	5 Gbit/s
Maksimal overføring avstand:	1500 m
Kabeltyper som støttes:	Fiber
