INSTALLATION, USE AND CARE MANUAL
FOR PROFESSIONAL VENTILLATION FOR
THE HOME
IMPORTANT!—PLEASE READ AND FOLLOW
1. THIS APPLIANCE WAS DESIGNED FOR EASE OF INSTALLATION AND OPERATION. HOWEVER, WE
RECOMMEND THAT YOU READ ALL SECTIONS OF THIS MANUAL BEFORE YOU BEGIN INSTALLA-
TION.
2. DO NOT REMOVE PERMANANTLY AFFIXED LABELS, WARNINGS OR DATA PLATES FROM YOUR
APPLIANCE. THIS MAY VOID THE MANUFACTURER’S WARRANTY AND/OR HINDER EFFECTIVE
SERVICING AND MAINTENANCE.
3. THESE INSTRUCTIONS ARE TO REMAIN WITH THE APPLIANCE AND THE CONSUMER IS TO RE-
TAIN THEM FOR FUTURE REFERENCE.
4. PLEASE OBSERVE ALL LOCAL AND NATIONAL BUILDING CODES AND ORDINANCES. IF NO LO-
CAL CODES ARE APPLICABLE, PLEASE FOLLOW ALL WIRING REQUIREMENTS IN ACCORDANCE
WITH THE NATIONAL ELECTRICAL CODE, ANSI/NFPA 70 EDITION.
5. PLEASE CHECK WITH A QUALIFIED AND TRAINED INSTALLER OR YOUR LOCAL CODES FOR ANY
MAKE UP AIR REQUIREMENTS.
6. THIS HOOD IS FOR RESIDENTIAL USE ONLY AND IS NOT DESIGNED FOR INSTALLATION OVER A
COMMERCIAL PRODUCT.
7. MAKE SURE ALL POWER IS TURNED OFF AT THE MAIN BREAKER OR FUSE BOX BEFORE MAKING
ANY CONNECTIONS.
8. TO AVOID RISK OF FIRE , ELECTRIC SHOCK, OR INJURY TO PERSONS, TURN OFF THE ELECTRIC-
ITY TO THE HOOD FROM THE POWER SUPPLY BEFORE CLEANING OR SERVICING.
This product is intended for domestic use only!
P/N 750306 Page 1
TABLE OF CONTENTS
Table of Contents ................................................................................................................................... 2
Safety Instructions ............................................................................................................................... 3-4
Introduction ............................................................................................................................................ 5
Welcome ................................................................................................................................................ 6
Handling & Unpacking .......................................................................................................................... 7
Packing list for your Vent Hood ....................................................................................................... 8-9
Pro Line Hoods ......................................................................................................................... 8
Pyramid Style Hoods ............................................................................................................... 9
Low Profile and Re-Circulating hoods .................................................................................. 10
Installation of Pro Line Series
Dimensions…………. .. ……………………………………………………………………11
Site Preparation …………………………………………………………………………….. 12
The Correct Height …………………………………………………………………………...13
Duct Information ……………………………………………………………………………..14
Blower Installation …………………………………………………………………………...15
Custom Duct Installation ……………………………………………………………………..16
Installation of Pyramid Style
Dimensions ............................................................................................................................. 17
Site Preparation .................................................................................................................... 18
The Correct Height ................................................................................................................ 19
Duct Information ................................................................................................................... 20
Blower Installation ................................................................................................................ 21
Flue Installation ..................................................................................................................... 22
Installation of Low Profile Series
Dimensions ............................................................................................................................. 23
Site Preparation .................................................................................................................... 24
The Correct Height ................................................................................................................ 25
Duct Information and Wiring ................................................................................................ 26
Installation of Low Profile Re-Circulating Series
Dimensions ............................................................................................................................. 27
Site Preparation .................................................................................................................... 28
The Correct Height and Wiring ............................................................................................. 29
Cleaning and Maintenance ................................................................................................................. 30
Warranty .......................................................................................................................................... 31-32
Performance Checklist .................................................................................................................... 33-34
P/N 750306 Page 2
IMPORTANT!—PLEASE READ AND FOLLOW
1. THIS APPLIANCE WAS DESIGNED FOR EASE OF INSTALLATION AND OPERATION. HOWEVER, WE
RECOMMEND THAT YOU READ ALL SECTIONS OF THIS MANUAL BEFORE YOU BEGIN INSTALLA-
TION.
2. DO NOT REMOVE PERMANANTLY AFFIXED LABELS, WARNINGS OR DATA PLATES FROM YOUR
APPLIANCE. THIS MAY VOID THE MANUFACTURER’S WARRANTY AND/OR HINDER EFFECTIVE
SERVICING AND MAINTENANCE.
3. THESE INSTRUCTIONS ARE TO REMAIN WITH THE APPLIANCE AND THE CONSUMER IS TO RE-
TAIN THEM FOR FUTURE REFERENCE.
4. PLEASE OBSERVE ALL LOCAL AND NATIONAL BUILDING CODES AND ORDINANCES. IF NO LO-
CAL CODES ARE APPLICABLE, PLEASE FOLLOW ALL WIRING REQUIREMENTS IN ACCORDANCE
WITH THE NATIONAL ELECTRICAL CODE, ANSI/NFPA 70 EDITION.
5. PLEASE CHECK WITH A QUALIFIED AND TRAINED INSTALLER OR YOUR LOCAL CODES FOR ANY
MAKE UP AIR REQUIREMENTS.
6. THIS HOOD IS FOR RESIDENTIAL USE ONLY AND IS NOT DESIGNED FOR INSTALLATION OVER A
COMMERCIAL PRODUCT.
7. MAKE SURE ALL POWER IS TURNED OFF AT THE MAIN BREAKER OR FUSE BOX BEFORE SERVIC-
ING OR MAKING ANY CONNECTIONS.
TO REDUCE RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS, OBSERVE THE FOLLOW-
ING:
USE THIS UNIT IN THE MANNER INTENDED
BY THE MANUFACTURER, IF YOU HAVE
ANY QUESTIONS PLEASE CALL 800-449-8691
BEFORE CLEANING OR SERVICING UNIT,
SWITCH POWER OFF TO THE UNIT AT THE
SERVICE PANEL AND LOCK OUT THE SER-
VICE PANEL. IF THE SERVICE PANEL CAN-
NOT BE LOCKED OUT, PLEASE AFIX A
WARNING DEVICE PROMINENTLY, SUCH AS
A TAG, TO THE SERVICE PANEL.
WARNING!
WARNING!
P/N 750306 Page 3
TO REDUCE RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS, OBSERVE THE FOLLOW-
ING:
INSTALLATION WORK AND ELECTRICAL
WORK MUST BE PERFORMED BY QUALIFIED
INDIVIDUALS IN ACCORDANCE WITH ALL
APPLICABLE CODES AND STANDARDS, IN-
CLUDING ALL FIRE RATED CONSTRUCTION
DO NOT DAMAGE ANY EXISTING ELECTRI-
CAL OR HIDDEN UTILITIES WHEN DRILL-
ING , CUTTING AND/OR REMOVING A WALL,
CEILING OR FLOOR
DUCTED FANS MUST VENT OUTDOORS
SUFFICIENT AIR IS REQUIRED TO PROPERLY
EXHAUST GASES THROUGH THE FLUE OF
NATURAL AND LIQUID PROPANE FUELED
COOKING EQUIPMENT TO AVOID ANY BACK
DRAFTING. FOLLOW ALL LOCAL AND NA-
TIONAL CODES AND STANDARDS FOR
PROPER AIR REQUIREMENTS.
USE ONLY METAL DUCTWORK
NEVER VENT DUCTED EXHAUST AIR INTO
ANOTHER ROOM OR GARAGE. TO REDUCE
THE RISK OF FIRE AND TO PROPERLY VENT
EXHAUST AIR, DUCT MUST VENT OUT-
DOORS
WARNING!
TO REDUCE THE RISK OF A RANGETOP GREASE
FIRE:
NEVER LEAVE THE APPLIANCE UNAT-
TENDED DURING USE. BOIL-OVERS MAY
OCCUR, CAUSING SPILLS WHICH MAY IG-
NITE.
DO NOT USE WATER ON GREASE FIRES.
NEVER PICK UP A FLAMING PAN. IT IS REC-
OMMENDED YOU PURCHASE A MULTI-
PURPOSE DRY CHEMICAL OR FOAM-TYPE
FIRE EXTINGUISHER FOR YOUR HOME.
STORE IT IN CLOSE PROXIMITY TO YOUR
APPLIANCES.
