Side 1/27
Version 4.4 AUS
TUNGSTEN SMART-HEAT™
GAS HEATER
BY BROMIC
INSTALLATION, INSTRUCTION AND
SERVICE MANUAL
SUITABLE FOR GAS RADIANT HEATER MODELS:
TUNGSTEN 300 - BURNER AND TUNGSTEN 500 - BURNER
WARNING: Improper installation,
adjustment, alteration, service or maintenance
can cause property damage, injury or death.
Read the installation, operating and
maintenance instructions thoroughly before
installing or servicing this equipment.
!
!
!
!
DANGER
If you smell gas:
1. Shut off gas to the appliance
2. Extinguish any open flame
3. If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
Do not store or use petrol or other flamable vapor and
liquids in the vicinity of this or any other appliance.
This appliance to be connected only to
reticulated gas & installed in accordance with AS/NZS
5601
WARNING: For Outdoor or Amply
Ventilated area use and for NON
RESIDENTIAL INDOOR APPLICATION
WARNING
2
www.bromicheating.com
Head Office: 10 Phiney Place, Ingleburn, Sydney, NSW 2565 Australia
T: 1300 276 642 (within Australia) or +61 2 9748 3900 (from overseas) F: +61 2 9748 4289
E: info@bromicheating.com W: www.bromic.com.au
!
Note: Bromic Heating reserves the right to make changes to specifications, parts, components and equipment without prior notification.
This Installation, operation and service manual may not be reproduced in any form with prior written consent from Bromic Heating.
This manual contains important information about the assembly, operation, and maintenance of
Tungsten Smart-Heat™ Heaters. Please pay close attention to the important safety information
shown throughout this instruction manual. Any safety information will be accompanied by the
following safety alert symbols:
DANGER, WARNING, IMPORTANT
• READ THIS MANUAL CAREFULLY before installing or servicing
this product.
• Improper installation, operation, or maintenance can result in
death, severe injury, or property damage.
• Installation must be carried out by Authorised person/s in
accordance with AS5601 Gas Installation Code.
• This appliance is to be used ONLY for outdoor and non-
residential indoor use (minimum room volume must be
250m
3
)
• When installed outdoors this appliance MUST be protected
!
!
!
3
www.bromicheating.com
CONTENTS
IMPORTANT NOTES & WARNINGS 4
PRODUCT OVERVIEW 5
PRODUCT DESCRIPTION 5
SPECIFICATIONS 5
GENERAL INFORMATION 6
PRODUCT FEATURES 6
INSTALLATION REQUIREMENTS 6
GAS REQUIREMENTS 6
INSTALLATION CLEARANCES 7
INSTALLATION INSTRUCTIONS 8
HEATER INSTALLATION INSTRUCTIONS 8
GAS SUPPLY INSTALLATION 12
POWER SUPPLY INSTALLATION 12
LEAKAGE TEST 12
HEAT DEFLECTOR INSTALLATION INSTRUCTIONS 13
CEILING MOUNT POLE INSTALLATION INSTRUCTIONS 13
OPERATING INSTRUCTIONS 14
TURNING THE APPLIANCE ON 14
TURNING THE APPLIANCE OFF 14
MAINTENANCE AND SERVICING 14
REGULAR SERVICE REQUIREMENTS 14
EXTERIOR SERVICING 14
OPTIMUM MOUNTING DISTANCE 15
HONEYWELL CONTROL 15
HONEYWELL VALVE 16
OPERATION DATA - BRAHMA CONTROL BOX 17
DUNGS GAS VALVE 18
WHITE RODGERS GAS VALVE 18
WIRING DIAGRAM 19
REPLACEMENT PARTS 22
POST-INSTALLATION REPORT 24
TROUBLE SHOOTING 25
APPENDIX A 26
WARRANTY 28
