Café CCES750P4MW2 Bruksanvisning
Les nedenfor 📖 manual på norsk for Café CCES750P4MW2 (2 sider) i kategorien Komfyr. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/2
Café
™
30" Slide-In Front Control
Radiant and Convection Double Oven
Range
CCES750P4MW2
FEATURES
FEATURES & BENEFITS
Seamless glass surface streamlines and simplified cooking - A sleek look is
yours with an edge-to-edge glass cooktop that provides a seamless, easy-to-
clean surface with more usable cooking space for five course meals
The perfect match for pots and pans of all sizes - Tailor your burner size to your
cookware with a 12"/9"/6" element with Power Boil
Create dinners and desserts at the exact same time - From everyday gourmet
meals to large dinner parties, achieve impressive results with two independent
ovens with a total capacity of 7.0 cu. ft. for true cooking flexibility, along with the
accurate heat circulation of True European Convection with Precise Air in the
lower oven
Prepare foods to perfect doneness - Get roasts and meats just right with a
temperature probe that lets you monitor progress without opening the oven door
An attractive appearance at all times - Every detail of your kitchen is designed
to delight, thanks to a sleek backlit glass touch control panel that visually
disappears when not in use and wakes up when prompted
Enjoy total control in the kitchen and beyond - Control your oven with your
smart device or simply your voice using WiFi Connect
Create a look that matches your personal style - Select any combination of
premium finishes and hardware options to create a stunning look customized
to any owner’s taste
Allow your appliances to interact with one another - Create a chef-like
experience with Chef Connect, which can synchronize your appliance clocks
and surface lights and vent when a range burner is in use, and even your
microwave and range clocks
When you’re updating your kitchen, attention to detail is a priority. That’s why
Café 30” slide-in ranges are guaranteed for an exact fi or Café Appliances will
pay up to $300 toward modifications
CAPACITY
Total Capacity (cubic feet)
6.7 cu ft
Capacity (cubic feet)
2.4 Upper / 4.3 Lower
WEIGHTS & DIMENSIONS
APPEARANCE
Oven Door Features
Big View Oven Window; Easy clean oven door
Handle
Professional Style; Customizable; Consumer Removable
Handle Design
Café
Textured Steel Side Panels
Yes
ACCESSORIES
Trim Kit
Optional; JXFILLR1BB
ADA
COMPLIANT
Configuration
Double Oven
Cooking System
True European Convection with Precise Air
Cooking Technology
Convection
Oven Cleaning Type
Self-Clean; Steam Clean
Cooktop Burner Type
Radiant; Smoothtop
Cooktop Surface
Black Ceramic Glass
Control Location
Front controls
Control Type
Backlit; Glass Touch
Oven Control Features
Audible Preheat Signal; Auto Oven Shut-Off with
Override; Auto Recipe Conversion; Auto Self
Clean; Certified Sabbath Mode; Chef Connect;
Control Lock Capability; C° or F° Programmable;
Delay Bake Option (Time Cook); Delay Clean
Option; Electronic Clock & Kitchen Timer; Fast
Preheat; Hi / Low Broil; Oven "ON" Light; Self-
Clean Cool Down Time Display; Temperature
Probe
Oven Cooking Modes
Baked Goods - Both Ovens (No Preheat);
Convection Bake; Convection Roast; Frozen Pizza
Multi Rack - Lower Oven (No Preheat); Frozen
Pizza Single Rack - Both Ovens (No Preheat);
Frozen Snacks Multi Rack - Lower Oven (No
Preheat); Frozen Snacks Single Rack - Both Ovens
(No Preheat); Proof (Lower Oven); Warming (Both
Ovens)
Oven Features
6-Pass Broil Element - Upper
8-Pass Broil Element - Lower
Self-Clean Oven Door Lock
Automatic
Oven Rack Features
2 Self-Clean Heavy-Duty Oven Racks; 1 Roller
Rack; 6 Rack Positions
Oven Interior
Black Gloss Finish; Interior Oven Light
Connected Capabilities
Amazon Alexa; The Google Assistant; IFTTT;
Nest; Drop; Innit; DiGiorno
WiFi Connect
Built-In
Element - Left Front
8"/5" 1900W
Element - Left Rear
8" 2000W
Element - Right Front
12"/9"/6" 3600W Power Boil
Element - Right Rear
6" 1500W
Element - Center
6" 80W Warming Zone
Hot Surface Indicator Lights
1
Heating Element "ON" Indicator Light
Yes
Infinite Heat Controls
Yes
Depth with Door Open
43-7/8 in
Approximate Shipping Weight
267 lb
Net Weight
247 lb
Height to Top of Rear Vent Trim
37-3/8 in
Overall Height
37-3/8 in
Height to Cooking Surface (in.)
36-1/4 +/- 1/4
Overall Width
29-7/8 in
Cabinet Width
30 in
Overall Depth
29-1/2 in
Oven Interior Dimensions
(W x H x D) (in.)
24 x 10-1/8 x 19-1/8 - Upper
24 x 15 x 20-5/8 - Upper
Café
™
30" Slide-In Front Control
Radiant and Convection Double Oven
Range
CCES750P4MW2
DIMENSIONS
Receptacle Locations: Locally
approved flexible service cord or
conduit must be used because
terminals are not accessible after
range installation. See shaded area
in drawing for location of electrical
outlet box. Recommended outlet
locations allow range to be installed
directly against rear wall.
Note: This appliance has been
approved for 0" spacing to adjacent
surfaces above the cooktop.
However, a 6" minimum spacing
to surfaces less than 15" above the
cooktop and adjacent cabinet is
recommended to reduce exposure
to steam, grease splatter and heat.
Installation Information: Before
installing, consult installation
instructions for current dimensional
data and additional requirements.
ADDITIONAL ACCESSORIES
CXFCEHKPMBZ
Brushed Bronze
2 handles; 6 knobs
(Standard on Matte White)
CXFCEHKPMSS
Brushed Stainless
2 handles, 6 knobs
(Standard on Matte Black)
CXFCEHKPMBT
Brushed Black
2 handles, 6 knobs
CXFCEHKPMCU
Brushed Copper
2 handles, 6 knobs
For answers to your Café™ product questions, visit our website at cafeappliances.ca
© 2019 GE Appliances PC91680 01/19
WARRANTY
Parts warranty
Limited 1-year entire appliance
Labor warranty
Limited 1-year entire appliance
POWER / RATINGS
Amp Rating at 208V
40
Amp Rating at 240V
40
Convection Wattage
2500W
Bake Wattage
2650W Upper / 2650W Lower
Broiler Wattage
3000W Upper / 3600W Lower
KW Rating at 208V
11.6
KW Rating at 240V
15.5
Produkspesifikasjoner
| Merke: | Café |
| Kategori: | Komfyr |
| Modell: | CCES750P4MW2 |
