Minx Air100/200 Wireless music system

Wi-fi set-up

Go to your computer and click on the

WiFi/network logo and select Minx Air_XXX.

Mac

iPad

Open a new page in your internet browser (Internet Explorer, Safari,

Chrome etc). In the address bar of your browser, type 192.168.1.1

followed by ‘enter’ and the Minx Air setup page will be displayed.

If you are happy that you have entered your details correctly, click

‘OK’ to finish.

The Minx Air set-up page may now display an ‘error’ or ‘no data

received’ type message. Don’t worry, this is normal. You can now

close your internet browser.

Select your home Wi-Fi network from the ‘Service Set ID (SSID)’

drop-down list of choices.

Made a mistake?

To reset the Minx Air, press and hold the power button

and WPS button on the rear panel for 10 - 15 seconds

until the Minx Air switches off. Then start again at Step 1.

You can also watch the Minx Air connection videos on

the Cambridge Audio website for further explanation.

Type your home Wi-Fi/Network password into the red box,

and click the ‘Apply’ button.

(Don’t know your Wi-Fi password key? It’s commonly found on

a label on your internet modem/router)

After a few seconds, the Minx Air will be connected to your

network (successful connection is indicated by a solid green light

on the rear of the product). This can take up to 30 seconds.

(If your computer/tablet has not already done so automatically, change the

Wi-Fi/network setting on your computer/tablet back to your home network).

Connect the Minx Air to the mains power and press the power

button on top of the unit. Wait for up to 20 seconds for the

flashing light on the rear panel to flash green and orange

iTunes

iPad

iPhone

To enjoy Airplay and internet radio, you must first

connect your Minx Air to your home network.

If you have a laptop computer, tablet, or any

other wi-fi enabled internet browser go to Step 1

below to connect to your home network.

If you have no wi-fi enabled internet browser

(such as a desktop computer) then please see the

online user manual for wired set-up instructions.

Airplay

Congratulations! You are now ready to stream music via Airplay.

When you open iTunes or your Music you will see the

Airplay logo allowing you to select your Minx Air as the

playback device.

Note – when Minx Air is selected, it will take a few seconds

to connect.

Wait for the music to start playing before adjusting the volume.

Bluetooth

Help and Troubleshooting

Get the free

MinxAir App

Search for internet radio stations from

around the world, control the volume,

bass and EQ settings from the comfort of

your armchair.

Free MinxAir App download from the

iTunes App store or Google Play store

(requires iOS 6 or later/Android 3.0 or later).

For set up videos and FAQs visit: www.cambridge-audio.com/MinxAirSetup

Consult the online user manual for more detailed information.

Adjust the bass of your Minx Air to

your listening environment. The bass

can also be controlled from the

MinxAir App and the remote control.

Top tips

Internet

Radio

Bass control

Internet Radio presets –

press to listen to internet radio

Power buttonVolume upVolume down

X Button –

press to listen to the

analogue input

Power button

Volume

Bluetooth

1-10 Internet

Radio presets

Mute

Stop

Bass control

Press the button on the

Minx Air to put your Minx Air

into Bluetooth pairing mode.

Enable Bluetooth connectivity on

your Bluetooth device (eg.

phone, tablet, etc) and pair with

the Minx Air (you may need to

consult your phone or tablet

operating instructions).

Once paired, music from your

device will play through the

Minx Air.

Auto power down

The Minx Air will automatically turn

off after four hours use. This

environmental feature can be

adjusted or disabled in the MinxAir

App, available from the iTunes App

store or Google Play store.

Once you have connected your

Minx Air to your home network

(see overleaf) then you’re ready

to listen to internet radio!

To get you started, we’ve stored

10 of our favourite internet radio

stations in your presets. Presets

1-5 can be easily selected and

played by pressing buttons 1-5 on

the top of the unit.

Presets 1-10 can be selected using

the remote control or the free

MinxAir App.

Also, using the MinxAir App, you

can search for new stations from

around the world and change the

presets to your own preferred

stations.

Bluetooth –

press to listen to Bluetooth

Min Max

X button

Press X once to stop the playback of

Airplay, Bluetooth or Internet radio or to

select the analogue input.

Press X a second time to mute playback of

the analogue input

Minx Air

Minx Air Minx Air

Minx Air

FREE App

Minx Air100/200 Wireless music system

To talk to us, call +44 (0)20 3514 1521 (UK Local) or 1 8773578204 (USA)

Minx Air system

using the App for

FREE lifetime

technical support!
