Side 1/330
4
F A M I L I A R I S A T I O N
Panoramic glass roof
82
Xenon directional head-
lamps
Whether on dipped beams
or main beams, this function
allows your headlamps to fol-
low the direction of the road
ahead.
89
Opening rear screen
81
Pneumatic rear suspension
This enhances driving comfort and
maintains a constant body height,
whatever the vehicle load.
154
Exterior side lighters
These light up the zones facing
the driver’s and passenger’s
doors.
88
Front/rear parking assist-
ance
Sensors, located in the
bumpers, detect obsta-
cles.
152
Parking space sensor
This measures the size of a
space and informs you of the
possibility of parking.
149
Exterior rear view mirrors
With electric foldback.
Automatically tilts in reverse
gear.
67
E X T E R I O R
5
F A M I L I A R I S A T I O N
A. Central locking
B. Unlocking
C. Guide-me-home lighting
D. Key release/storage
Press on control A , located on the
control panel to the right of the dash-
board. The fuel fl ap automatically opens
up fully.
Insert the nozzle so as to push in the
metallic gate valve B .
Push the fuel fl ap to reclose it.
After switching off the ignition, con-
trol A is only active for a few minutes.
If necessary, switch on the ignition
again to reactivate it.
Bonnet stay: detach the stay and
pivot it upwards to insert it into the
notch.
69
Bonnet opening/closing
To unlock, pull the control located on the
right-hand side under the dashboard
towards you.
157
83
Opening
Using the multifunction screen, you can
choose from the following options when
opening your vehicle with the remote
control:
- either all of the doors and the tail-
gate,
- or the driver’s door with a fi rst press,
then all of the other doors with a
second press.
To close: move the stay back to
its initial position, lower the bon-
net, then allow it to slam shut at
the end of its travel.
Remote control key Fuel tank
Capacity: approximately 60 litres.
