HRM-S
手机专用采访麦克风
①
②
③
咪头
手柄
3.5mm TRRS插头
Type-C
转换线
心型指向
>15mm
Lightning
转换线
HRM-S
Reporter/Interview Microphone for Smartphone
①
②
③
Mic Capsule
Handle
3.5mm TRRS Plug
Type-C
adapter cable
Cardioid Pattern
>15mm
Lightning
adapter cable
使用说明书
.手机设备专用采访麦
.高端定制级采访频响
.超低底噪
.手机专用镀金电容咪头
.全金属结构、超强屏蔽
前 言
包装清单
产品安装
规格参数
感谢您购买COMICA/科唛HRM-S手机专用采访麦克风；本产品专
用于手机，是一款3.5MM TRRS 心型指向麦克风，并具备高端定
制级采访频响;超低底噪;手机专用镀金电容咪头;全金属结构、
超强屏蔽等多种功能。是您拍摄视频的极佳拍档!
为保证产品的顺畅使用，请在使用前严格阅读本说明书，并正
确组装及操作。
注意事项
部件介绍
使用方法
产品主要功能
本产品采用3.5mm TRRS接口输出，其他接口的手机请自行配
备相应的转换线使用
配合Android（安卓）系统的手机使用时，录音模式下均可正
常工作，默认视频模式下大多数手机会出现不兼容情况（此
时建议使用第三方视频软件）
配合iOS系统手机使用时，在所有录音模式、视频模式以及第
三方视频软件下均可正常使用
请勿将本设备放置在热源或干扰源附近使用，如散热器、烤
箱、冰箱、空调、手机和WIFI热点旁边
本产品属于高精密仪器类产品，请避免使用时掉落、碰撞或
重击
不要在雨中或潮湿的环境中使用该设备，否则会有短路的危
险
请在干燥环境中对该产品进行保存
HRM-S
手机专用采访麦克风
使用说明书
麦克风主体 便携袋
话筒台标
说明书 保修卡
1.根据个人需要，把话筒台标安装到麦克风手柄上
2.把3.5mm TRRS插头插入手机上即完成安装
使用时请把话咪对准音源，并保持15mm距离以上
1.频率响应
2.指向性图
3.性能参数
声学原理
指向性
输出阻抗
频响
最大声压级
灵敏度
信噪比
等效噪声（ ）A-weighted
动态范围
尺寸
线长
工作温度
电容式
心型
2.2kΩ Typical
60Hz
~
20kHz
100dB SPL (F=1kHz,THD<1%)
-35dB±2dB (F=1kHz,SPL=1Pa,0dB=1V/Pa)
75dB Typical
19dB Typical
81dB Typical
Ф41mm x 273mm
3.5m
0
~
50℃
Email: support@comica-audio.com
本产品是3.5mm TRRS接口输出，其他接口的手机请自行配备
相应的转换线使用
User Manual
. Designed for Handheld Interview by Smartphone
. Specially Tailored Frequency Response for Reporter
. Super Low Self-noise
. Integrated with Condenser and Gold-plating Capsule
. Full Metal Construction for Better Shielding
Foreword
Packing List
Product Installation
Specification
Thanks for purchasing COMICA HRM-S Reporter/Interview
Microphone for Smartphone. This item is specially designed
for Smartphone, is a Condenser Cardioid Microphone with
3.5mm TRRS Plug, and it has the Specially Tailored Frequency
Response for Reporter; Super Low Self-noise; Integrated with
Condenser and Gold-plating Capsule; Full Metal Construction
for Better Shielding functions, which is a wonderful partner for
your shoot!
To ensure bring you a good using experience, please read this
manual book carefully before using and correctly install and
operate.
Notice
Components Instruction
Product Usage
Main Features
This product uses 3.5mm TRRS output interface, phone with
other interface should be prepared with corresponding
cable adapter to use
For the smartphone with Android system, the Mic works well
in Audio Mode, it may not be compatible with most of the
smartphones in Default Video Mode; (Then we suggest you
to try the 3rd party’s video APP)
For the smartphone with IOS system(iPhone) , the Mic works
well either in Audio or Video mode
Do not use this equipment in the vicinity of heat source or
interference source, such as radiator, oven, refrigerator or
air conditioner, smartphone or next to the WIFI AP
This product belongs to high-precision instruments, please
avoid falling, collision or pounding
Do not use the equipment in rain or in a damp environment
to avoid short-circuit danger
Please keep the product in a dry environment
Microphone Carry Case
LOGO Flag
User Manual Warranty Card
1.Install the LOGO Flag to Microphone Handle according to your needs
2.Insert the 3.5mm TRRS plug into the phone and fix it then finish the
installation
Please aim your mic to the audio source and keep the distance above
15mm when it's working
1.Frequency Response
2.Polar Pattern
3.Technology Parameters
Acoustic Principle
Polar Pattern
Output Impedance
Frequency Response
Maximum SPL
Sensitivity
Signal / Noise
Equivalent Noise(A-weighted)
Dynamic Range
Dimension
Cable Length
Working Temperature
Condenser
Cardioid
2.2kΩ Typical
60Hz~20kHz
100dB SPL (F=1kHz,THD<1%)
-35dB±2dB (F=1kHz,SPL=1Pa,0dB=1V/Pa)
75dB Typical
19dB Typical
81dB Typical
Ф
41mm x 273mm
3.5m
0~50
℃
Email: support@comica-audio.com
This product uses 3.5mm TRRS output interface, phone with
other interface should be prepared with corresponding
adapter cable to use
HRM-S
Omnidirectional Dynamic Reporter/Interview Microphone
User Manual
88X160mm 折页；材质书纸; 英文版首页做封面
