Side 1/51

SAVE THESE INSTRUCTIONS

Please read this manual and follow the instructions for installation and operation.

-01

INSTALLATION AND OPERATION MANUAL

SMART APP ONLINE

UPS SYSTEM

OL6KRTMB | OL8KRTMB | OL10KRTMB

OL6KRTHW | OL8KRTHW | OL10KRTHW

SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

This manual contains important instructions that should be followed during installation and maintenance of

the UPS and batteries.

The SmartApp Online 6-10kVA UPS models that are covered in this manual are intended for installation in

an environment within 32°F to 104°F (0°C to 40°C), free of conductive contaminants.

SPECIAL SYMBOLS

Warning: High voltage – Risk of Electric Shock

Caution - Important Instructions: must always be followed.

Do Not Discard: the UPS or UPS batteries in trash. The batteries

contain lead acid. For more information, contact your local recycling

or hazardous waste facility.

Information, advice, help

See applicable user manual

III

SAFETY INSTRUCTIONS CONT.

PERSONAL SAFETY

CAUTION

To reduce the risk of ﬁre, connect the UPS to a branch circuit with 40 amperes

(6,000 VA)/50 amperes (8,000 VA)/70 amperes (10,000 VA) maximum over-current

protection in accordance with the National Electric Code, ANSI/NFPA 70.

The AC electrical service where the UPS is connected should be close to the unit and

easily accessible.

Please use only UL-marked mains cable, (e.g. the mains cable of your equipment), to

connect the UPS to the AC outlet.

Please use only UL-marked power cables to connect any equipment to the UPS.

When installing the equipment, ensure that the sum of the leakage current of the UPS

and the connected equipment does not exceed 3.5mA.

Do not unplug the unit from AC power during operation, as this will disconnect the

protective ground insulation.

Do not use an improper size power cord as it may cause damage to your equipment

and cause ﬁre hazards.

Make sure everything is turned o and disconnected completely before conducting

any maintenance, repairs or shipment.

DO NOT INSTALL THE UPS WHERE IT WOULD BE EXPOSED TO DIRECT SUNLIGHT

OR NEAR A STRONG HEAT SOURCE!

DO NOT BLOCK OFF VENTILATION OPENINGS AROUND THE HOUSING!

DO NOT CONNECT DOMESTIC APPLIANCES SUCH AS HAIR DRYERS TO UPS

OUTPUT SOCKETS!

SERVICING OF BATTERIES SHOULD BE PERFORMED OR SUPERVISED BY

PERSONNEL KNOWLEDGE OF BATTERIES AND THE REQUIRED PRECAUTIONS.

KEEP UNAUTHORIZED PERSONNEL AWAY FROM BATTERIES!

FOR PERMANENTLY CONNECTED EQUIPMENT, A READILY ACCESSIBLE DISCONNECT

DEVICE SHALL BE INCORPORATED IN THE BUILDING INSTALLATION WIRING.

RISK OF ELECTRIC SHOCK

A battery can present a risk of electric shock and high short circuit current. The

following precaution should be observed when working on batteries:

Remove watches, rings or other metal objects.

Use tools with insulated handles.

The UPS must be connected to a grounded AC power outlet with fuse or circuit

breaker protection. DO NOT plug the UPS into an outlet that is not grounded. If you

need to power-drain this equipment, turn o and unplug the unit.

Produkspesifikasjoner

Merke:	CyberPower
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	Smart App Online OL6KRTHW
Vekt:	104280 g
Bredde:	433 mm
Dybde:	820 mm
Høyde:	264 mm
Støynivå:	65 dB
LED-indikatorer:	Battery replacement, Fault, Power
Batterikapasitet:	7 Ah
USB-port:	Ja
Pakkevekt:	129230 g
Utgangseffekt:	6000 W
Batterivekt:	76000 g
Utgangsspenning (maks.):	240 V
Batteriteknologi:	Forseglet blysyre (VRLA)
UPS topologi:	Dobbeltkonvertering (Online)
Utgangsfrekvens:	50/60 Hz
Hørbare alarmmoduser:	Fault, Low battery alarm
Bølgeform:	Sinus
Batteriladetid:	4 timer
Inngangsspenning (maks.):	280 V
Batteribredde:	433 mm
Batteridybde:	660 mm
Batterihøyde:	132 mm
Produktfarge:	Sort
Pakkedybde:	619 mm
Pakkehøyde:	1120 mm
Pakkebredde:	650 mm
Antall støttede batterier:	20
Skjermtype:	LCD
Kabler inkludert:	Phone (RJ-11), Serial, USB cable
Batterispenning:	12 V
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 45 °C
Lagringsrelativ fuktighet:	0 - 95
Bærekraftsertifikater:	RoHS
Formfaktor:	Rackmontering
Inngangsfrekvens:	40/70 Hz
Kroppsmateriale:	Stål
Overspenningsvern:	Ja
Strømbeskyttelsesfunksjoner:	Overload, Short circuit
Driftshøyde:	0 - 3000 m
Rack-kapasitet:	6U
Relativ luftfuktighet under drift (H-H):	0 - 90
Antall AC outlets:	13 AC-utganger
Bærekraftsamsvar:	Ja
Hørbare alarmer:	Ja
AC-utgangstyper:	Hardwire
Strømuttak:	Hardwire
Strømfaktor:	1
Rack-montert sett:	Ja
Høyde når uvirksom:	0 - 15000 m
EMI/RFI-lydfiltrering:	Nei
Output strømkapasitet (VA):	6 kVA
Inngangsspenning (min.):	120 V
Utgangsspenning (min.):	120 V
Utgangsspenning total harmonisk forvrengning (THD):	5
Modem (RJ-11)-porter:	1
Inngangsstrømfaktor:	0.99
Crest-faktor:	3:1
Hot-swap-batterier:	Ja
Utbyttbare batteripatroner:	RB1270X10
Utgangsstrømfaktor:	1
