Ventilation Solutions
Ventilation Solutions
1
Ventilation Facts
Two Types of Ventilation
Power Sources Factors to Consider
OVERHEAD
Width & Depth of Cooking Product
Capture Area: Width, Height & Depth
Mounting Height (see chart)
Blower Size
Duct Diameter:
Use Manufacturer’s
Recommendation
Duct Length (see chart)
Internal Blowers
External Blowers:
REMP3, REMP16
ILHSF8, ILHSF10
(Over-the-Range models
internal blower only)
Hoods
Powerpacks
Over-the-Range
Microwaves (OTR)
DOWNDRAFT
Width & Depth of Cooking Product
Blower Size
Duct Diameter:
Use Manufacturer’s
Recommendation
Duct Length (see chart)
HVAC Experts recommend
Internal Blowers:
CABP3 (RV only)
External Blowers:
REMP3, REMP16
In-Line Blowers:
ILHSF8, ILHSF10
RV
ERV
ERV-ER
PRV
FACTORS THAT NEGATIVELY INFLUENCE
VENTILATION
Open Windows & Doors, Air Conditioning Vents,
Ceiling Fans, Island Cooking, Foot Traffic
GENERAL RULE OF THUMB
100 CFM for every 10,000 BTU
(*Increase if duct run is long or complicated)
Heat, Odors, Grease,
Gases, Steam & Smoke
POLLUTANTS TO REMOVE FROM THE KITCHEN
2
1
Ventilation Facts
2
Keep duct run as short as possible.
Whenever possible, use round duct instead of rectangle.
Do not use back to back elbows–24" minimum between elbows.
Do not use flex duct.
Do not use duct smaller then the recommended size– and never reduce!
Seal ductwork with duct tape and use screws to support weight.
Match roof or wall cap with duct size.
In Pro, Island cooking, we recommend you oversize the hood a minimum of 6".
Support and insulate duct to reduce all noise and vibration.
DO’S & DONT’S
Hoods: EH/EHR/MH - Bottom of the hood should be 25” minimum above
the cooktop surface. DHI, DHW, PHW - Bottom of the hood should
be 30” minimum above the cooktop surface.
PowerPacks (with SS Liner): Bottom of liner should be 36" from the
finished counter.
OTR (above electric cooking): Top of microwave should be 34" above
the finished counter.
OTR (above gas cooking): Top of microwave should be 36" above the
finished counter. (36" mandatory above ERD30, ER30D, ER30DSR and
EGR30)
*
In hoods or Powerpacks, if you must install the hood higher than the recommended
h
eight, it is very important that you increase the size (width) of the hood and the power
(
CFM) to provide the best possible ventilation.
RECOMMENDED
MOUNTING HEIGHTS
Elbows & Transitions count extra-you must add to straight run
to get the total duct run.
90º, 8" Round=7' 45º, 8" Round=3' 90º, Rectangle=15'
90º, 10" Round=5' 45º, 10" Round=2' 90º, Flat Rectangle Elbow=20'
Straight Transition, 8" or 10" Rd to 3
1/4
"x10" Rectangle = 4'
Elbow Transition, 8" or 10" Rd to 3
1/4
"x10" Rectangle = 25'
8" Round: 60' max
10" Round: 50' max
3
1/4
"x10" Rectangle: 50' max
RECOMMENDED DUCT LENGTHS
(VARIES BY PRODUCT)
Ventilation Solutions
