18600 Series and CTP-NB
Service and Installation Manual
Please read this manual completely before attempting to install or operate this equipment! Notify carrier of damage! Inspect all
components immediately. See page 2.
CTP-NB
Countertop Condiment Rail
18600PTBM
Pizza Tables with Raised Rail
18600BUCM
Work Tables
July 2011
IMPORTANT INFORMATION
READ BEFORE USE
PLEASE SAVE THESE INSTRUCTIONS!
CAUTION
18600PTL
Pizza Tables with LiquiTec® Rail
18600BSTM
Work Table with Backsplash
18600PDL
Dual LiquiTec
®
Rail Prep Table
18600 and CTP-NB Series Service and Installation Manual
For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.delfield.com
2
Receiving & Inspecting Equipment ...................................................... 2
Specifications ........................................................................................ 3
Refrigerant Charges .............................................................................. 4
Installation ............................................................................................ 4
Operation
18600PTBM & PTL Series ................................................................ 5
18600BUCM & BSTM Series ............................................................ 5
18600PDL Series ............................................................................... 6
CTP-NB Series ................................................................................... 6
Pressure Control Settings ..................................................................... 7
Temperature Control Settings ............................................................... 7
Care And Cleaning ..............................................................................8-9
Wiring Diagram
18600PTBM & PTL Series .............................................................. 10
18600BUCM & BSTM Series .......................................................... 11
18600PDL ........................................................................................ 11
CTP-NB Series ................................................................................. 12
Replacement Parts ......................................................................... 13-22
Standard Labor Guidelines.................................................................. 23
Standard Warranties ......................................................................24-26
Notes ................................................................................................... 27
The serial number on 18600 Series units is located on the electrical
specifications tag affixed inside the compressor section next to the
pressure control.
The serial number on CTP-NB Series units is located on the front of
the unit.
Always have the serial number of your unit available when calling for
parts or service.
Warranty may be deemed invalid if other than
authorized OEM (original equipment manufacture)
replacement parts are used in Delfield equipment.
©2011 The Delfield Company. All rights reserved. Reproduction without
written permission is prohibited. “Delfield” is a registered trademark of The
Delfield Company.
Contents
Serial Number Information
Receiving And Inspecting The Equipment
Even though most equipment is shipped crated, care should be
taken during unloading so the equipment is not damaged while
being moved into the building.
1. Visually inspect the exterior of the package and skid or
container. Any damage should be noted and reported to
the delivering carrier immediately.
2. If damaged, open and inspect the contents with the
carrier.
3. In the event that the exterior is not damaged, yet upon
opening, there is concealed damage to the equipment
notify the carrier. Notification should be made verbally as
well as in written form.
4. Request an inspection by the shipping company of the
damaged equipment. This should be done within 10 days
from receipt of the equipment.
5. Check the lower portion of the unit to be sure legs or
casters are not bent.
6. Also open the compressor compartment housing and
visually inspect the refrigeration package. Be sure lines
are secure and base is still intact.
7. Freight carriers can supply the necessary damage forms
upon request.
8. Retain all crating material until an inspection has been
made or waived.
Uncrating the Equipment
First cut and remove the banding from around the crate.
Remove the front of the crate material, use of some tools will
be required. If the unit is on legs remove the top of the crate
and lift the unit off the skid. If the unit is on casters it can be
"rolled" off the skid.
18600 and CTP-NB Series Service and Installation Manual
3
For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.delfield.com
Specifications
18600PTBM Pizza tables with raised rail
Model
1/3 Pan Size
Capacity # Of Doors
# Of
Shelves
Shelf Max
Load (LBS)
Shelf Area
FT
2
Storage
Cap. FT
3
BTU Load
Base/Rail
BTU Sys. Cap.
Base/Rail H.P.
Voltz/Hertz/
Phase Amps
NEMA
Plug
Ship Weight
LBS/KG
18648PTBM 6 (1) 27” 1 124 3.95 10.23 470/441 2001/952 1/4 115/60/1 10.0 5-15P 520/236
18660PTBM 7 19” & 27” 2 70/124 6.51 15.12 694/617 2409/1208 1/3 115/60/1 12.0 5-15P 575/260
18672PTBM 9 (2) 27” 2 124 7.9 18.10 776/794 2967/1587 1/2 115/60/1 14.0 5-20P 635/288
18691PTBM 11 (2)27” & (1) 19” 3 124/70 10.29 24.48 1062/1058 3537/1865 1/2 115/60/1 14.0 5-20P 770/350
18699PTBM 12 (3) 27” 3 124 11.85 27.46 1144/1147 3537/1945 1/2 115/60/1 14.0 5-20P 805/365
186114PTBM 14 (3) 32” 3 140 14.46 33.05 1297/1323 5169/2433 3/4 115/60/1 16.0 5-20P 927/420
18600BUCM Work tables
Model # Of Doors
# Of
Shelves
Shelf Max
Load (LBS)
Shelf Area
FT
2
Storage
Cap. FT
3
BTU Load
Base/Rail
BTU Sys. Cap.
Base/Rail H.P.
Voltz/Hertz/
Phase Amps
NEMA
Plug
Ship Weight
LBS/KG
18648BUCM (1) 27” 1 124 3.95 10.23 475/NA 1462/NA 1/5 115/60/1 8.0 5-15P 390/177
18660BUCM 19” & 27” 2 70/124 6.51 15.12 686/NA 1462/NA 1/5 115/60/1 8.0 5-15P 435/197
18672BUCM (2) 27” 2 124 7.90 18.10 856/NA 2261/NA 1/4 115/60/1 10.0 5-15P 495/225
18691BUCM (2)27” & (1) 19” 3 124/70 10.29 24.48 1169/NA 2261/NA 1/4 115/60/1 10.0 5-15P 535/243
18699BUCM (3) 27” 3 124 11.85 27.46 1220/NA 2591/NA 1/3 115/60/1 12.0 5-15P 594/269
186114BUCM (3) 32” 3 106 14.46 37.24 1373/NA 2591/NA 1/3 115/60/1 12.0 5-15P 685/310
18600BSTM Work table with backsplash
Model # Of Doors
# Of
Shelves
Shelf Max
Load (LBS)
Shelf Area
FT
2
Storage
Cap. FT
3
BTU Load
Base/Rail
BTU Sys. Cap.
Base/Rail H.P.
Voltz/Hertz/
Phase Amps
NEMA
Plug
Ship Weight
LBS/KG
18648BSTM (1) 27” 1 124 3.95 10.23 475/NA 1462/NA 1/5 115/60/1 8.0 5-15P 390/177
18660BSTM 19” & 27” 2 70/124 6.51 15.12 686/NA 1462/NA 1/5 115/60/1 8.0 5-15P 435/197
18672BSTM (2) 27” 2 124 7.90 18.10 856/NA 2261/NA 1/4 115/60/1 10.0 5-15P 495/225
18691BSTM (2)27” & (1) 19” 3 124/70 10.29 24.48 1169/NA 2261/NA 1/4 115/60/1 10.0 5-15P 535/243
18699BSTM (3) 27” 3 124 11.85 27.46 1220/NA 2591/NA 1/3 115/60/1 12.0 5-15P 594/269
186114BSTM (3) 32” 3 106 14.46 37.24 1373/NA 2591/NA 1/3 115/60/1 12.0 5-15P 685/310
18600PTL Pizza table with LiquiTec® rail
Model
1/3 Pan Size
Capacity # Of Doors
# Of
Shelves
Shelf Max
Load (LBS)
Shelf Area
FT
2
Storage
Cap. FT
3
BTU Load
Base/Rail
BTU Sys. Cap.
Base/Rail H.P.
Voltz/Hertz/
Phase Amps
NEMA
Plug
Ship Weight
LBS/KG
18648PTL 6 (1) 27” 1 124 3.95 10.23 470/441 2001/952 1/4 115/60/1 10.0 5-15P 520/236
18672PTL 9 (2) 27” 2 124 7.90 18.10 776/794 2967/1587 1/2 115/60/1 14.0 5-20P 635/288
18699PTL 12 (3) 27” 3 124 11.85 27.46 1144/1147 3537/1945 1/2 115/60/1 14.0 5-20P 805/365
18600PDL Pizza table with Dual LiquiTec® rails
Model
1/3 Pan Size
Capacity # Of Doors
# Of
Shelves
Shelf Max
Load (LBS)
Shelf Area
FT
2
Storage
Cap. FT
3
BTU Load
Base/Rail
BTU Sys. Cap.
Base/Rail H.P.
Voltz/Hertz/
Phase Amps
NEMA
Plug
Ship Weight
LBS/KG
18648PDL 6 (1) 27” 1 124 3.95 10.23 424/1058 2001/1865 1/5,
1/3
115/60/1 10.1 5-20P 691/313
18672PDL 9 (2) 27” 2 124 7.90 18.10 703/1588 2001/3174 1/5,
1/2
115/60/1 12.7 5-20P 873/396
CTP-NB Counter top containment rail
Model
1/3 Pan Size
Capacity # Of Adapter Bars BTU Load
BTU System
Capacity H.P.
Voltz/Hertz/
Phase Amps
NEMA
Plug
Ship Weight
LBS/KG
CTP8146-NB 4 5 305 523 1/5 115/60/1 4.0 5-15P 121/54.9
CTP8160-NB 6 7 462 653 1/5 115/60/1 4.0 5-15P 158/71.7
