LAVATORY FAUCETS
■ Dryden™ Collection
■ Single Handle Deck Mount
Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
STANDARD SPECIFICATIONS:
• Max. 1.2 gpm @ 60 psi, 4.5 L/min @ 414 kPa
• One or three hole mount (escutcheon
optional, included)
• Diamond coated ceramic cartridge
• Solid brass fabricated body
• 3/8" O.D. straight, staggered PEX supply tubes
• Models have metal drain with pop-up type fitting
with plated flange and stopper
551-▲-DST
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for finish options and product availability.
DSP-L-551-DST Rev. D
COMPLIES WITH:
• ASME A112.18.1 / CSA B125.1
• ASME A112.18.2 / CSA B125.2
Indicates compliance to
ICC/ANSI A117.1
•
EPA WaterSense
®
• Meets 0.25% weighted average lead
content regulations.
3 3/8"
(86 mm)
1 3/8"
(35 mm) Dia.
1 1/4"
(32 mm) Dia.
2 1/8"
(54 mm)
Dia.
1 5/8"
(41 mm)
to
2 3/8"
(60 mm)
4 5/8"
(117 mm)
1 5/8"
(41 mm)
Diameter
3 7/8"
(98 mm)
2 7/8" (73 mm)
Max. Deck
Thickness
35 "
(889 mm)
36"
(914 mm)
6"
(152 mm)
Optional
Escutcheon
2 1/8"
(54 mm)
Optional 6"
Escutcheon
7 7/8"
(201 mm)
8 5/16"
(211 mm)
5 3/8"
(137 mm)
3/8" (9 mm)
Compression
Fitting
7 3/4"
(197 mm)
WARRANTY
•
Lifetime limited warranty on parts (other than
electronic parts and batteries) and finishes:
or, for commercial users, for 5 years from
date of purchase.
•
5 year limited warranty on electronic parts
(other than batteries); or, for commercial
users, for 1 year from the date of purchase.
No warranty is provided on batteries.
55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2017 Masco Corporation of Indiana
FEATURES:
• DIAMOND Seal
®
Technology
▲ Designate Proper Finish Suffix
Recommended Min. 2 1/2" (64 mm)
Clearance to Back Splash
1 1/8" - 1 1/2"
(29-38 mm)
Hole Size
