LAVATORY
FAUCETS
■ Compel
®
Collection
■ Single Handle Deck Mount
■ 1 or 3 Hole Sink Mount
(Optional 6" Escutcheon Included)
Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
STANDARD SPECIFICATIONS:
• Lever handle. Control mechanism is the diamond
embedded ceramic disc cartridge.
• 1 or 3 hole installation.
• 5" (127 mm) long reach on spout.
• Red/blue markings on handle for
hot/cold identification.
• Control handle shall return to neutral position
when valve is turned off.
• 3/8" O.D. straight, staggered pex supply tubes 35"
(889 mm) and 36" (914 mm) long.
• Models with suffix "MPU"have metal drain with
pop-up type fitting with plated flange and stopper.
• Models with suffix "LPU" are less pop-up.
• Models with suffix "TP" have 50/50 pop-up type
fitting with plated flange and stopper.
• Max. 1.50 gpm @ 60 psi, 5.7 L/min @ 414 kPa
561LF-MPU▲
561LF-TP▲
55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2015 Masco Corporation of Indiana
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for finish options and product availability.
DSP-L-561LF-MPU Rev. E
COMPLIES WITH:
• ASME A112.18.1 / CSA B125.1
• ASME A112.18.2 / CSA B125.2
Indicates compliance to
ICC/ANSI A117.1
•
EPA WaterSense
®
•
Verified compliant with .25% weighted average
Pb content regulations.
3 3/8"
(86 mm)
1 3/8"
(35 mm)
Dia.
1 1/4"
(32 mm)
Dia.
2 1/8"
(54 mm)
Dia.
1 5/8"
(41 mm)
to
2 3/8"
(60 mm)
4 5/8"
(117 mm)
1 5/8"
(42 mm)
Diameter
3 5/16"
(84 mm)
2 1/4"
(57 mm)
35"
(889 mm)
36"
(914 mm)
6"
(152 mm)
Optional
Escutcheon
2 1/4"
(57 mm)
Max. Deck
Thickness
Optional 6"
Escutcheon
7 1/2"
(191 mm)
8"
(203 mm)
5"
(127 mm)
561LF-LPU▲
4 3/8"
(111 mm)
1 3/8"
(35 mm)
Dia.
1 1/4"
(32 mm)
Dia.
2 1/8"
(54 mm)
Dia.
1 5/8"
(41 mm)
to
2 3/8"
(60 mm)
4"
(102 mm)
▲ Designate Proper Finish Suffix
3/8"
(9 mm)
Compression
Fitting
MPU TP
WARRANTY
•
Lifetime limited warranty on parts (other than
electronic parts and batteries) and finishes:
or, for commercial users, for 5 years from
date of purchase.
•
5 year limited warranty on electronic parts
(other than batteries); or, for commercial
users, for 1 year from the date of purchase.
No warranty is provided on batteries.
1 1/8" to 1 3/8"
(29 mm to 35 mm)
Hole Size
