Abbildungen können nicht im Serien-Lieferumfang enthaltenes Zubehör darstellen / Illustrations can contain accessories, which are not included in standard extent of delivery.
Abbildungen ähnlich, produktionsbedingte Abweichung vorbehalten / Illustration similar (in design), production-wise modications reserved.
File: S:\shared-pool\Product-Documentation\T-Produktbeschreibung\30_n0t\Originale_Englisch_PA04\2365580_01018.doc
Erstelldatum/create date: 19.05.2008 16:00:00Aktualisiert/up dated: 14.07.2010
Split Air Conditioner
Art.-No.: 23.655.80
SKA 2503 Dual C+H
Bar code: 4006825550740
Sales unit: 1 pc
Air Coniditioner for cooling and heating for wall installation. Automatic air dehumidication.
Complete with remote control and 2 x 4 m connection copper tubes (max. 2x 10 m possible) with insulating tube.
Time programming device for ON/OFF. Easy installation of the air conditioner with a cooling capacity of 2 x 2.850
W heating capacity of 2 x 2.850 Wand a . Ideal for two larger rooms until approx. 80 m³. The outdoor unit can be used
by temperatures from 0°C up to +43°C. Due to the possibility of heating operating, the air conditioner can additionally
also be used as „interseasonal heating“. The unit consists of 3 parts, an outdoor part and two for indoors, in order to
allow quick cooling and warrant an optimal noise level. 3 Settings of fan speed with a maximum speed of 2 x 550 m
3
/h.
With the automatic air dehumidication the units evaporates from its surrounding max. 2 x 1.0 l/h excess humidity.
Timer for program settings automatic- and night functions, . All functions can be set by the remote control with
LCD display. Motorized ventilation lamella in the indoor unit.
Features
:
- Fan (1)
- Pipe connection
- Air suction lter (2)
- LCD-display (3)
- Air escape lamellas (4)
- Remote control (5)
- 2x 2 pcs refrigerant lines 4 m
Technical data
:
- Coolant: R410A
- Energy-eiciency-class: C
- EER / COP: 2.91 / 2.94
- Energy consumption when
cooling: 2 x 490 kWh per year
- Cooling capacity: 2 x 2,850 W / 10,000 BTU/h
- Heating capacity: 2 x 2,850 W / 10,000 BTU/h
- Air performance: 2 x 550 m³/h
- Mains: 230 V ~ 50 Hz
- Capacity of humidity
reduction max.: max. 2 x 1.0 l/h
- Quantity of coolant: approx. 2 x 900 g/ for
5 m tubes (for each metre
add 20 g more coolant)
- Noise level: Indoors: 40 dB (A) ≤
Outdoors: 57 dB (A) ≤
Characteristics according to EN 14511
Tool dimensions
/
Weight
:
2x Indoor unit (WxDxH): 750x260x315 mm / 8 kg
1x outdoor unit (WxDxH): 1,020x410x700 mm / 65 kg
Packing dimensions / Weight:
2x Indoor unit (BxTxH): 790x275x325 mm / 10 kg
1x outdoor unit (BxTxH): 1,100x450x755 mm / 70 kg
1
3
4
2
3
4
2
5
