Elation Design Spot 1400E Bruksanvisning
Les nedenfor 📖 manual på norsk for Elation Design Spot 1400E (68 sider) i kategorien belysning. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/68
Rev. 08/28/2008-visage
Design Spot 1400E
Elation Professional
6122 S. Eastern Ave
Los Angeles, Ca. 90040
Design Spot 1400E™
©Elation Professional® 2 Design Spot 1400E™
CONTENTS
1. General Information……………………………………………………………………… 4
a. Introduction………………………………………………………………………. 4
b. Customer Support…………………………………………….………………… 3
c. Warranty Registration……………………………………………………..……. 5
d. Discharge Lamp Warning………………………………………………………. 5
2. Safety Instructions………………………………………………………........…………. 7
3. Features…………………………………………………………………………………… 9
4. General Guidelines………………………………………………………………………. 10
5. Lamp Installation…………………………………………………………………………. 11
a. Lamp installation…………………………………………………….………….. 11
b. Lamp optimization……………………………………………………..………… 12
6. Mounting and Installation………………………………………………………….……. 14
a. Mounting Positions……………………………………………………………… 14
b. Mounting Points…………………………………………………………………. 15
c. Securing………………………………………………………………………….. 16
7. Understanding DMX……………………………………………………………………... 17
a. DMX Linking……..………………………………………………………………. 17
b. DMX Cable Requirements..……………………………………………………. 17
c. DMX Termination………..………………………………………………………. 19
d. DMX Addressing………………………………………………………………… 19
8. Fixture Menu……………………………………………………………………………… 21
a. Menu functions………………………………………………………………….. 23
9. Menu Functions.…………………………………………………………………………. 24
10. DMX Addressing…………………………………………………………………………. 32
11. Operation…………………………………………………………………………………. 34
12. Working with Built-In Programs…………………………………………………………. 36
13. DMX Channel Traits……………………………………………………………………… 40
14. Fuse Replacement……………………………………………………………………….. 46
15. Error Codes……………………………………………………………………………….. 47
16. Cleaning and Maintenance……………………………………………………………… 51
17. Warranty…………………………………………………………………………………... 52
18. Photometric Data………………………………………………………………………… 54
19. Dimensional Drawings………………………………………………….……………….. 56
20. Circuit Schematic………...………………………………………………………………. 57
21. Technical Specifications…………………………………………...………….………… 59
Design Spot 1400E™
©Elation Professional® 3 Design Spot 1400E™
1. GENERAL INFORMATION
INTRODUCTION: Congratulations, you have just purchased one of the most innovative and
reliable lighting fixtures on the market today! The Design Spot 1400E,™ has been designed
to perform reliably for years when the guidelines in this booklet are followed. Please read
and understand the instructions in this manual carefully and thoroughly before attempting to
operate this unit. These instructions contain important information regarding safety during
use and maintenance.
UNPACKING: Thank you for purchasing the Design Spot 1400E™ by Elation Professional®.
Every Design Spot 1400E™ has been thoroughly tested and has been shipped in perfect
operating condition. Carefully check the shipping carton for damage that may have occurred
during shipping. If the carton appears to be damaged, carefully inspect your unit for damage
and be sure all accessories necessary to operate the unit have arrived intact. In the event
damage has been found or parts are missing, please contact our customer support team for
further instructions. Please do not return this unit to your dealer without first contacting
customer support at the number listed below.
CUSTOMER SUPPORT: Elation Professional® provides a customer support line, to provide
set up help and to answer any question should you encounter problems during your set up
or initial operation. You may also visit us on the web at www.elationlighting.com for any
comments or suggestions. For service related issue please contact Elation Professional®.
Service Hours are Monday through Friday 8:00 a.m. to 5:00 p.m. Pacific Standard Time.
Voice: (323) 582-3322
Fax: (323) 832-9142
E-mail: support@elationlighting.com
Forum: www.ElationLighting.com/forum
Warning! To prevent or reduce the risk of electrical shock or fire, do not expose this unit to
rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not attempt any repairs
yourself, doing so will void your manufactures warranty.
