LUMINA STRIP™
SKU# LUM001
The new Lumina Strip™ features (10) 7W Warm White
(2,700K) <80 CRI LEDs packaged in perfectly aligned
halogen looking reflectors, 15° beam producing
a smooth wash or blinder effect, electronic 16bit
dimming (0-100%), variable dimming curves, individual
pixel control (1-10), chase macros with variable speed
and fade control, icker free operation for TV and FILM,
integrated dual yoke / oor stand, multiple unit power
linking, 90W max power consumption, remote device
management protocol support, and a multi-voltage
universal auto switching power supply (120-240v).
FEATURES
(10) 7W Warm White (2,700K) <80 CRI LEDs
Perfectly Aligned Halogen Looking Reectors
15° Beam Producing a Smooth Wash or Blinder Effect
Electronic 16bit Dimming (0-100%) + Variable Curves
Individual Pixel Control (1-10)
Chase Macros with Variable Speed and Fade Control
Flicker Free Operation for TV and FILM
Integrated Dual Yoke / Floor Stand
Multiple Unit Power Linking
90W Max Power Consumption
Remote Device Management Protocol Support
Specications are subject to change without notice ©Elation Professional
Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040
323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com
Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, Netherlands
+31 45 546 85 66 | +31 45 546 85 96 fax | www.elationlighting.eu | info@elationlighting.eu
ELATION I LUMINA STRIP™ I Product Specification Sheet
IP20
VARIABLE
D I M M I N G C U R V E
RDM
Remote Device Management
FEATURES
15° Beam Producing a Smooth Wash or Blinder Effect
Electronic 16bit Dimming (0-100%)
Variable Dimming Curves
Individual Pixel Control (1-10)
Flicker Free Operation for TV and FILM
Integrated Dual Yoke / Floor Stand
Multiple Unit Power Linking
Remote Device Management Protocol Support
SOURCE
(10) 7W Warm White (2,700K) <80 CRI LEDs
PHOTOMETRIC DATA
20,334 LUX (1,889 FC) @ 3.3’ (1m) (FULL ON)
5,084 LUX (472 FC) @ 6.6’ (2m) (FULL ON)
2,259 LUX (210 FC) @ 9.8’ (3m) (FULL ON)
1,271 LUX (118 FC) @ 13.1’ (4m) (FULL ON)
813 LUX (76 FC) @ 16.4’ (5m) (FULL ON)
EFFECTS
Electronic 16bit Dimming: 0% - 100%
Variable Dimming Curves
(Stage, TV, Architectural, Theatre)
Chase Macros with Variable Speed and Fade Control
CONTROL / CONNECTIONS
(9) DMX Channel Modes
(8-Bit: 7 / 8 / 10 / 11 / 16) (16-Bit: 8 / 10 / 16 / 26)
RDM (Remote Device Management)
(4) Button Control Panel
LCD Menu Display
5pin DMX In/Out
powerCON In/Out
SIZE / WEIGHT
Length: 41.0” (1042mm)
Width: 5.1” (128.5mm)
Vertical Height: 5.7” (146mm)
Weight: 13.9 lbs. (6.3 kg)
ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
90W Max Power Consumption
Multiple Unit Power Linking:
MAX 16pcs (AC100-120V) or MAX 32pcs (220-240V)
APPROVALS / RATINGS
CE | IP20
INSTALLATION
Rigging: Integrated Dual Yoke / Floor Stand
Working Position: Any (360°)
INCLUDED ITEMS
(1) powerCON Cable
(2) Mounting Brackets and Screws
24.2”
(615mm)
39.4”
(1000mm)
41.0”
(1042mm)
2.1”
(54mm)
3.0”
(75mm)
3.1”
(78.2mm)
32.0”
(812mm)
(130mm)
5.1”
5.7”
(146mm)
3.7”
(94mm)
1.2”
(30mm)
0.4”
(11mm)
5.1”
(128.5mm)
2.6”
(66.5mm)
specifications
I
ELATION LUMINA STRIP™
I
www.elationlighting.com
Specications are subject to change without notice ©Elation Professional
Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040
323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com
Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, Netherlands
+31 45 546 85 66 | +31 45 546 85 96 fax | www.elationlighting.eu | info@elationlighting.eu
15°
Beam
1m
2m
3m
4m
5m
Distance 1 m 3.3 ft 2 m 6.6 ft 3 m 9.8 ft 4m 13.1 ft 5 m 16.4 ft
Photometrics lux fc lux fc lux fc lux fc lux fc
FULL ON @2,700K
20,334 1,889 5,084 472 2,259 210 1,271 118 813 76
DIMENSIONAL DIAGRAM
PRODUCT SPECIFICATIONS
PHOTOMETRIC DATA
ORDER CODE ITEM
TRIGGER CLAMP Heavy Duty Wrap Around Hook Style Clamp
EWDMXSYSTEM Wireless DMX System (1 Transmitter, 1 Receiver)
EWDMXT Wireless DMX Transmitter
EWDMXR Wireless DMX Receiver
AC5PDMX5PRO 5 ft. (1.5m) 5pin PRO DMX Cable
PLC3 3’ (1m) PowerCON PRO Link Cable
Additional cable lengths available
OPTIONAL ACCESSORIES
