*All information is subject to change without notice
Specications are preliminary & are subject to change without notice
©Elation Professional • Los Angeles, Ca USA • Kerkade, Netherlands
www.elationlighting.com
Toll Free
(
866
)
245-6726
PLATINUM SPOT LED
. LED Lamp Source with Comparable Output to 250 Discharge
. Nearly ½ Power Consumption of 250
. Improved Optics and Flat Beam Field
. 50,000 Hour Solid State LED Lamp Source Life
. cETLus approved
COLORS 8 Dichroic Colors
GOBOS 14 Gobos
7 Rotating / Indexing Replaceable Gobos
7 Replaceable Static Gobos
SPECIAL EFFECTS 3 Facet, 3D Rotating / Indexing Prisms and Frost Filter
Motorized Iris
Motorized Focus
SHUTTER/DIMMER Variable speed Shutter / Strobe
Smooth Electronic Dimmer 0-100%
LIGHT SOURCE Lamp: LED 90W CRI 70 6,500K
7,478 lux / 695 fc @ 10’
OPTICAL SYSTEM 16° beam angle
MOVEMENT Pan/Tilt: 540/630 x 265
CONTROL 16 Channels DMX
3-pin & 5-pin DMX
POWER SUPPLY 240W MAX / 120v-240V 50/60hz
DIMENSIONS (L x W x H) 16.75” x 16.75” x 19.75” / 425 x 425 x 502 mm
Weight 48.5lbs / 22 kg
Rotating Gobos Static GobosColors
373mm / 14.7”
357mm / 14”
335mm / 13.2”
318mm / 12.5”
84mm / 3.3”
70mm / 2.8”
403.5mm / 15.9”
468mm / 18.4”
218.5mm
/ 18.6”
127.5mm
/ 5”
IRIS
M O T O R I Z E D
FROST FILTER
POWERED BY
LED Light SourcE
*All information is subject to change without notice
Specications are preliminary & are subject to change without notice
©Elation Professional • Los Angeles, Ca USA • Kerkade, Netherlands
www.elationlighting.com
PLATINUM SPOT LED
REAR
ADDRESS
FUNCTION
Toll Free
(
866
)
245-6726
Platinum Spot LED
Photometric Beam Angle Data
Standard 16° Beam Angle
LUX
x
0.0929
= FC
6123 FC / 65910 LUX 1506 FC / 16210 LUX 695 FC / 7478 LUX
16° Beam Angle
0 m
0 ft
1 m
3.28 ft
3 m
9.84 ft
2 m
6.56 ft
Ø 0.29 m / Ø 0.95 ft
Ø 0.58 m / Ø 1.90 ft Ø 0.84 m / Ø 2.76 ft
Beam Diameter
16° Beam Angle
The chart below details the channel layout for 16 DMX channels (default).
In 8bit mode the “Pan Fine” and “Tilt Fine” channels are not used, thus converting the fixture
into a 14-channel DMX fixture. In extended mode the fixture will use 20 DMX channels.
