PROTEUS BEAM™
SKU# PRB014
Interchangable-Rotating Gobos Specications
Specifications/designs are subject to change without notice.
Gobo image not to scale - for illustration purposes only.
ELATION I PROTEUS BEAM™ I Interchangable-Rotating Gobos Specifications
Elation Professional USA | |6122 S. Eastern Ave. Los Angeles, CA. 90040
323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com
Elation Professional B.V. | | Junostraat 2 6468 EW Kerkrade, The Netherlands
+31 45 546 85 66 | +31 45 546 85 96 fax | www.elationlighting.eu | info@elationlighting.eu
* * * IMPORTANT NOTICE REGARDING CUSTOM GOBOS * * *
Due to the extreme high temperature optical system which can reach up to 968
°
F (520
°
C),
special STAINLESS STEEL material and design requirements are required. Due to varing gobo
manufacturing processes and tolerances, it is highly recommended to provide a
gobo sample from the xture to the custom gobo vendor for accurate sizing.
Extended testing of custom gobo designs is highly recommended prior to using.
Please contact ELATION Customer Support for further information.
O.D.
(Max. Outer Diameter)
13.8mmф
I.D.
(Max. Image Diameter)
ф6mm
Gobo Holder
Diameter
ф14mm
Thickness 0.5mm
Material STAINLESS STEEL
MAX I.D.
MAX O.D.
THICKNESS
GOBO HOLDER
0.5
6.0
13.8
14.0
1.0
PROTEUS BEAM™
SKU# PRH014
Custom Rotating Gobos Guidelines
Specifications/designs are subject to change without notice.
Gobo image not to scale - for illustration purposes only.
ELATION I PROTEUS HYBRID™ I Custom Rotating Gobos Specifications
Elation Professional USA | |6122 S. Eastern Ave. Los Angeles, CA. 90040
323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com
Elation Professional B.V. | | Junostraat 2 6468 EW Kerkrade, The Netherlands
+31 45 546 85 66 | +31 45 546 85 96 fax | www.elationlighting.eu | info@elationlighting.eu
GOBO ID
Extremely Intricate/Solid Area Designs
NOT RECOMMENED!
* * * IMPORTANT NOTICE REGARDING CUSTOM GOBO DESIGNS* * *
Full Color / Solid Area custom gobo designs are NOT RECOMMENDED due to the extreme
high temperature optical system which can reach up to 842
°
F (450
°
C).
Custom gobo designs as illustrated above can burn during extended use periods.
Please contact ELATION Customer Support for further information.
Produkspesifikasjoner
| Merke: | Elation |
| Kategori: | belysning |
| Modell: | Proteus BEAM |
