Side 1/20
Owner’s Manual
TOC
Table of Contents .............................. TOC
Safety First ..................................... TOC
Product Description ...............................1
Welcome ...............................................1
Important Features ............................... 1
Model Summary ................................... 2
Packing List .......................................... 2
EVID
TM
Product Feature Identification .............. 3
SAM
TM
(Strong-Arm-Mount
TM
) System . 4
Step-by-Step Installation and Wiring .... 4
Step 1 - Mount the SAM
TM
Bracket ..4
Step 2 - Select Wattage Tap (Models
4.2t and 6.2t Only)............................ 5
Step 3 - Mount the Speaker to the
SAM
TM
Bracket ................................. 5
Step 4 - Wire the Speaker ................ 6
Step 5 - Secure the Seismic Tab
Connection Point .............................. 6
Step 6 - Test System Operation ....... 6
Packing List (12.1 Subwoofer) ............. 7
Product Feature Identification (12.1
Subwoofer) ...........................................7
Step-by-Step Installation and Wiring
(12.1 Subwoofer) .................................. 8
Step 1 - Mount the Bracket .............. 8
Step 2 - Install the Safety Line .........8
Step 3 - Wire the Speaker ................ 8
EVID
TM
Owner’s Manual
Table of Contents
Step 4 - Mount the Speaker to the
Bracket ............................................. 9
Step 5 - Test System Operation .....10
Safety Agency Compliance ................ 10
Maintenance ....................................... 10
Uniform Limited Warranty ................... 11
Exclusions and Limitations ................. 11
Obtaining Warranty Service ............... 11
Incidental and Consequential Damages
Excluded ............................................. 11
Other Rights ....................................... 11
Speakers and Electronics .................. 11
Appendix A - Integrating the 12.1
Subwoofer .............................................12
Installation Examples ......................... 12
Using the 12.1 in Passive Mode ........ 12
Crossover Freq. and Impedance ....... 12
Using a Separate Amplifier Channel for
the 12.1 ...............................................12
Characteristics of All Subwoofers ......12
Appendix B - Painting the Speaker .... 13
Painting Process (3.2, 4.2, 6.2) ......... 13
Painting the Grille ............................... 13
Painting Process (12.1 Subwoofer) ...13
Appendix C - Troubleshooting Table .14
Appendix D - Technical Specs ............ 15
3.2/3.2t; 4.2/4.2t .................................15
6.2/6.2t; 12.1 ...................................... 16
Notes ......................................................17
Safety First
Suspending any object is potentially dangerous and should only be attempted by individuals who
have a thorough knowledge of the techniques and regulations of rigging objects overhead. Electro-
Voice® strongly recommends that all speakers be suspended taking into account all current national,
federal, state and local regulations. It is the responsibility of the installer to ensure that all speakers
are safely installed in accordance with all such regulations. When speakers are suspended, Electro-
Voice® strongly recommends that the system be inspected at least once a year. If any sign of
weakness or damage is detected, remedial action should be taken immediately. The user is
responsible for making sure that the supporting surfaces, and any additional hardware used, is
capable of supporting the loudspeaker. Any hardware used to suspend a loudspeaker array that is
not provided by/associated with Electro-Voice® is the responsibility of others.
EVID
TM
Owner’s Manual
1
Product Description
Welcome
Thank you for purchasing EVID™ Series
loudspeakers. Read through this manual
to familiarize yourself with the features,
applications, and precautions before you
use these products.
EVID™ Series loudspeakers use
innovative design and materials to provide
premium-level performance from compact
surface-mount speakers.
Four models comprise the EVID™ Series:
the 6.2 with dual 6-inch LF drivers and a 1-
inch titanium tweeter with waveguide; the
4.2 with dual 4-inch LF drivers and a 1-
inch titanium tweeter with waveguide; the
3.2 with dual 3.5-inch LF drivers and a .75-
inch titanium direct radiator tweeter. The
EVID™ 12.1, a subwoofer designed to
augment and extend the full-range model’s
low-frequency response completes the
line.
Important Features
•Line-array enhanced coverage control
•Organic, unobtrusive shape
•SAM™ (Strong-Arm-Mount™) system
for secure and reliable mounting
•Extremely large speaker swing and
rotation ranges for flexible placement
and coverage everywhere
•Full bandwidth overload protection
•Weather resistant and paintable
•Dual LF transducers
•Extended bass
•Greater power handling and output
•Titanium HF transducers (4.2, 6.2
waveguide coupled)
•High sensitivity
•Shielded for video applications
