EVID FM6.2

Dual 6.5” Two-Way

Flush-Mounted

Loudspeaker System

Key Features:

• 6.5”two-waysystemwithpolypropylenediaphragmforreli-

ablelong-termoperation.

• 6.5”passiveradiatorcoupledtothewooferdramatically

extendsandsmoothesthelowfrequencyresponse.

• Extremelycompactdepthfitsintotightspacesincluding

wallsandtightceilingspaces.

• Titaniumcoatedtweetergivesevenuniformhighfrequency

coverage

• Fullbandwidthoverloadprotection

• Frontbafflewattagetapadjustmentallowsforeasylevel

matchingafterinstallation.

• Easy4pinphoenixstyleterminalsforquickinstallation

• Integratedlowlossmatchingtransformerallowsforeither

70v/100vor8ohmoperation.

General Description:

TheElectro-Voice®EVIDFM6.2loudspeakersystemisacomplete

two-wayin-wallloudspeakerpackage.Thepackageconsistsofabezel

assembly,grille,rearenclosure,6.5”two-wayloudspeakercoupledwith

a6.5”passiveradiatorandaninternalline-matchingtransformer.The

loudspeakerfeatures6.5”low-frequencyconeandhigh-temperature

voice-coilassemblyalongwitha6.5”longexcursionpassiveradiator

andtitaniumcoateddometweeter.TheEVIDFM6.2loudspeakeruti-

lizesacrossovernetwork,centeredat3,300Hz,thatprovides16-dB-

per-octavetweeterprotectionoutsideofitsoperatingrange.Inaddition

theFM6.2featuresacomprehensiveprotectioncircuittoshieldthe

wooferandtweeterdriversfromexcessivepowerlevels.

TheFM6.2utilizesatransformerthatoffersaselectionof7.5,15,30,

or60wattsdeliveredtotheloudspeakersystemusingeither70-Vor

100-Vlines.Thewattageisselectedviaaconvenientswitchonthe

frontbaffle.Theunitcanalsobeoperatedasan8-ohmspeakerviathe

samefrontpanelselectorswitch.

Theperforatedgrilleisfinishedinsemi-glosswhitepowder-coated

enamel.ThebaffleandbezelisconstructedfromheatresistantABS.

Therearenclosureisconstructedfromzinc-plated,steel.Therear

enclosureprovidesanoptimuminternalvolume,ensuringextendedlow-

frequencyperformance.Itisconstructedfromheavy-gauge,rugged

steel.ThesteelrearenclosurewasoptimizedusingFEAtovirtually

eliminatepanelresonance.Theentireenclosureislessthan4”deep

providinganeasyinstallationintonearlyanytightwallorceilingspace.

Arearcover,withprovisionsforajunctionboxfitting,providesaccess

toa4-pinterminalblockthatallowsdirectconnectiontothespeaker

andprovidespassthroughtoadditionalspeakers.FM6.2loudspeakers

providewidedispersion,high-efficiency,high-maximumoutput,easeof

installation,andwide-rangereproductionofmusicorvoice.

Technical Specifications:

Freq.Response(-3dB): 60Hz-20kHz

Freq.Range(-10dB): 52Hz-20kHz

AxialSensitivity: 90dB(SPL1W/1m)

Impedance: 8ohmsnominal(transformerbypass)

CrossoverFrequency: 3.3kHz

Rec.HighpassFrequency: 60Hz

PowerHandling

: 150WCont.Prog./300WPeak

HFTransducer: 1in.(25.4mm)

LFTransducer:

PassiveRadiator:

6.5in.(165.1mm)

TransformerTaps: 70V:7.5,15,30,or60W

100V:15,30,or60W

Bypass:8ohmsnominal

Connectors: 4pinphoenixstyleterminals

EnclosureMaterial: Baffle:UL94V-OratedABS

Backcan:Zincplatedsteel

Grille: Perforatedpowdercoatedsteelwithsafety

tether

MountingSystem: Integratedtoggleanchors

SupportHardware: Cutouttemplate,Paintshield

Dimensions: 465.4mmx256.4mmx100.3mm

(18.32”x10.09”x3.95”)

NetWeight(Each): 5.8kg(12.7lb)

ShippingWeight(Pair): 12.9kg(28.4lb)

AllSpecificationsbasedonHalf-SpaceEnvironmentasflush-mounted.

ContinuousProgramRating:3dBgreaterthancontinuouspinknoise

rating(IEC-shapedpinknoisewith6dBcrestfactor)
