Side 1/20
F R i
SPEAKER
SYSTEMS
MANUAL
Welcome
Dear Sound Professional:
Thank you for choosing EV products. For more than 70 years, we have
persevered to design, engineer, and manufacture the most innovative and
highest quality audio products for indoor and outdoor spaces, including
offices, houses of worship, live music venues, auditoriums and stadiums.
This perseverance has led to our pioneering new technologies that have
become industry standards: constant directivity horns, manifold technology,
Variable-D
®
microphones, hum-bucking coils for microphones, and the inclusion
of ultra-light weight neodymium in magnet structures (previously only utilized
by the auto industry) for microphones and loudspeakers, to name just a few.
It is our pleasure to provide you with the audio solution best suited for
your critical sound reinforcement needs. Congratulations on your
FRi-Series purchase!
To get the most out of your FRi-Series investment, please read carefully
through this entire FRi-Series guide. Inside you will find information that will
help you achieve maximum product life, optimum performance, and a safe,
successful installation.
If you need more information, call your EV dealer or contact EV directly:
Electro-Voice
12000 Portland Avenue
Burnsville, MN 55337
U.S.A.
Customer Service
1-800-392-3497
Hours: 8:00 a.m. to 5:00 p.m. CST
Web site: www.electrovoice.com
Warning! Only fully licensed, qualified professionals following safe
rigging standards should suspend any Electro-Voice system.
1
F R i
SPEAKER
SYSTEMS
Contents
Page
2-4 FRi Series Overview
5 FRi Series Warranty
6 Installation Environments
7-10 Rigging
10 Amplifier Recommendations
11 Biamp Operations
12 Electronic Crossover
13-14 Basic Configuration
Appendix
15 A: Mechanical Adjustments
16 B: Dimensional Specifications
17 C: Frequency Curve
18 D: Beamwidth Curve
19 E: Product Specifications
The purpose of this guide is to familiarize you with the
Electro-Voice FRi-Series of installation loudspeakers.
Main system features are identified along with unique
characteristics found in specific models.
F R i
SPEAKER
SYSTEMS
FRi Series Overview
2
FRi Series Overview
The Electro-Voice FRi-Series of fixed installation, sound
reinforcement loudspeakers deliver a broad range of
performance options to accommodate the acoustic
requirements of most environments. All full range FRi
models employ EV’s renowned DH2t two-inch diaphragm
compression driver to deliver sound reproduction that is
smooth and linear.
In addition to the superior performance of the FRi Series,
flexibility, ease of suspension and array configuration all
merit the series suitable for most environments. The FRi
12-inch, 15-inch full range and 18-inch sub models all
measure 28 inches in the vertical dimension, allowing neat,
concise, and visually appealing arrays in either vertical or
horizontal arrays. The fully rotatable horn allows the
installer to construct the array to meet their coverage
needs while maintaining the most aesthetically pleasing
cabinet configuration. The structural integrity of all full
range FRi cabinets allow for vertical arrays up to a four
cabinet hang. In addition, the FRi-122/64 and FRi-
152/64 two-way speakers contain 12 suspension
points that enable a wide variety of flying configurations.
All are constructed in a trapezoidal design of 13 ply Baltic
Birch plywood with a detachable steel grille. The grilles
may be easily covered with acoustically transparent cloth.
The FRi-181S is supplied with 16 suspension points for
the ultimate in flexibility.
The FRi Series is specifically designed for use in stadiums,
houses of worship, live music clubs/discos, arenas and
gymnasiums. All systems employ EV’s exclusive Ring Mode
Decoupling (RMD™) and high-performance DL series
woofers to ensure maximum speech intelligibility and musical
clarity. Coupled with a fully rotatable high frequency horn,
all FRi models provide maximum flexibility.
