MM2F TO MM2F-1 CONVERSION
User Instructions
12000 Portland Avenue South, Burnsville, MN 55337
Phone:952/884-4051, Fax:952/884-0043
www.electrovoice.com
© Telex Communications, Inc. 6/2003
Part Number 38110-269 Rev A
U.S.A. and Canada only. For customer orders, contact Customer Service at:
800/392-3497 Fax: 800/955-6831
Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:
+ 49 9421-706 0 Fax: + 49 9421-706 265
Other International locations. For customer orders, contact Customer Service at:
+ 1 952 884-4051 Fax: + 1 952 736-4212
For warranty repair or service information, contact the Service Repair department at:
800/685-2606
For technical assistance, contact Technical Support at: 866/78AUDIO
Specifications subject to change without notice.
MM2F-1 Conversion Instructions
Tools required
•Phillips Screwdriver
•Torque Driver With Phillips Bit
•Loctite 222 Threadlocker (or equivalent)
Instructions
1. Position the MM2F face down on a flat surface. The six (6) screws and electrical terminals
shall be facing up.
2. With a Phillips screwdriver, remove one (1) of the six screws from the back housing.
3. Position a stave at location where old screw was removed. Use old screw as a guide to
hold stave in place during next step. (see figure below)
4. Place a drop of Loctite 222 threadlocker (or equivalent) on threads of a new screw
(provided). Torque new screw, with lock washer (provided), to 35 inch pounds.
5. Remove old screw and discard.
Repeat steps 2 through 5 for remaining five staves.
