Electrolux Home Products Australia
telephone: 1300 363 640
fax: 1800 350 067
email: customercare@electrolux.com.au
web: www.electrolux.com.au
Electrolux Home Products New Zealand
phone: 09 573 2384
fax: 09 573 2221
email: customercare@electrolux.co.nz
web: www.electrolux.co.nz
The Thoughtful Design Innovator.
Do you remember the last time you opened a gift that made you say
“Oh! How did you know? That’s exactly what I wanted!” That’s the kind of
feeling that the designers at Electrolux seek to evoke in everyone who
chooses or uses one of our products. We devote time, knowledge, and a
great deal of thought to anticipating and creating the kind of appliances that
our customers really need and want.
This kind of thoughtful care means innovating with insight. Not design for
design’s sake, but design for the user’s sake. For us, thoughtful design means
making appliances easier to use and tasks more enjoyable to perform, freeing
our customers to experience that ultimate 21st century luxury, ease of mind.
Our aim is to make this ease of mind more available to more people in more
parts of their everyday lives, all over the world. So when we say we’re thinking
of you, you know we mean just that.
Electrolux. Thinking of you.
Share more of our thinking at www.electrolux.com.au or www.electrolux.co.nz
Thank you for choosing the new
Electrolux induction cooktop – the most
beautiful cooktop in the world.
This product combines beauty and style
with induction technology to deliver you a
truly modern cooking solution. To ensure
that you get the most enjoyment out of
your Electrolux induction cooktop please
take a few moments to review this manual.
Enjoy!
• Important safety instructions 1
• Displays 3
• Operating the appliance 4
• Locking/unlocking the control panel 5
• Using the child safety device 6
• Switching the power boost function
on and off 7
• Using the timer 8
• Automatic switch off 11
• Tips on cooking and frying 12
• Examples of cooking applications 14
• Cleaning and care 15
• Troubleshooting 17
• Disposal 19
• Installation instructions 20
• Assembly 22
• Information label 23
• Warranty 24
• Service 25
Contents
The symbols you will see in this booklet
have these meanings:
This symbol indicates information
concerning your personal safety
This symbol indicates information on
how to avoid damaging the cooktop
This symbol indicates tips and
information about use of the cooktop
This symbol indicates tips and
information about economical and
ecological use of the cooktop
dangerous voltage
This symbol indicates risk of injury
from electrical current
electrolux induction cooktop contents i
user manual
induction cooktop
EHD90LLUM
P/No. 867 200 534-A-190407-01
© Copyright 2007 Electrolux Home Products Pty Ltd
ABN 51 004 762 341
Print code: EAURORAUM_Dec 07
Congratulations
Electrolux Home Products Australia
telephone: 1300 363 640
fax: 1800 350 067
email: customercare@electrolux.com.au
web: www.electrolux.com.au
Electrolux Home Products New Zealand
phone: 09 573 2384
fax: 09 573 2221
email: customercare@electrolux.co.nz
web: www.electrolux.co.nz
The Thoughtful Design Innovator.
Do you remember the last time you opened a gift that made you say
“Oh! How did you know? That’s exactly what I wanted!” That’s the kind of
feeling that the designers at Electrolux seek to evoke in everyone who
chooses or uses one of our products. We devote time, knowledge, and a
great deal of thought to anticipating and creating the kind of appliances that
our customers really need and want.
This kind of thoughtful care means innovating with insight. Not design for
design’s sake, but design for the user’s sake. For us, thoughtful design means
making appliances easier to use and tasks more enjoyable to perform, freeing
our customers to experience that ultimate 21st century luxury, ease of mind.
Our aim is to make this ease of mind more available to more people in more
parts of their everyday lives, all over the world. So when we say we’re thinking
of you, you know we mean just that.
Electrolux. Thinking of you.
Share more of our thinking at www.electrolux.com.au or www.electrolux.co.nz
Thank you for choosing the new
Electrolux induction cooktop – the most
beautiful cooktop in the world.
This product combines beauty and style
with induction technology to deliver you a
truly modern cooking solution. To ensure
that you get the most enjoyment out of
your Electrolux induction cooktop please
take a few moments to review this manual.
Enjoy!
• Important safety instructions 1
• Displays 3
• Operating the appliance 4
• Locking/unlocking the control panel 5
• Using the child safety device 6
• Switching the power boost function
on and off 7
• Using the timer 8
• Automatic switch off 11
• Tips on cooking and frying 12
• Examples of cooking applications 14
• Cleaning and care 15
• Troubleshooting 17
• Disposal 19
• Installation instructions 20
• Assembly 22
• Information label 23
• Warranty 24
• Service 25
Contents
The symbols you will see in this booklet
have these meanings:
This symbol indicates information
concerning your personal safety
This symbol indicates information on
how to avoid damaging the cooktop
This symbol indicates tips and
information about use of the cooktop
This symbol indicates tips and
information about economical and
ecological use of the cooktop
dangerous voltage
This symbol indicates risk of injury
from electrical current
electrolux induction cooktop contents i
user manual
induction cooktop
EHD90LLUM
P/No. 867 200 534-A-190407-01
© Copyright 2007 Electrolux Home Products Pty Ltd
ABN 51 004 762 341
Print code: EAURORAUM_Dec 07
Congratulations
Cooking surface layout Control panel layout
Cooking zone indicators
Timer function
Timer display
Timer
Display
Power boost function
Heat setting selector
On/Off
with power indicator
Lock
Touch control sensor fields
The appliance is operated using Touch Control sensor fields. Functions are controlled
by touching sensor fields and confirmed by displays and acoustic signals.
Touch the sensor fields from above, without covering other sensor fields.
Sensor Fields Function
On / Off To switch the appliance on and off
Increase settings Increasing heat setting/time
Decrease settings Decreasing heat setting/time
Timer Timer selection
Lock Locking/unlocking the control panel
Power boost Switching the power boost function on and off
ii product description electrolux induction cooktop electrolux induction cooktop control panel layout iii
Important Notice
Before calling a Service Technician please check carefully the operating instructions,
service booklet and the warranty terms and conditions.
FOR SERVICE
or to find the address of your nearest
state service centre in Australia
PLEASE CALL 13 13 49
For the cost of a local call (Australia only)
SERVICE AUSTRALIA
ELECTROLUX HOME PRODUCTS
www.electrolux.com.au
FOR SPARE PARTS
or to find the address of your nearest
state spare parts centre in Australia
PLEASE CALL 13 13 50
For the cost of a local call (Australia only)
FOR SERVICE
or to find the address of your nearest
authorised service centre in New Zealand
FREE CALL 0800 10 66 10
(New Zealand only)
SERVICE NEW ZEALAND
ELECTROLUX HOME PRODUCTS
www.electrolux.co.nz
FOR SPARE PARTS
or to find the address of your nearest
state spare parts centre in New Zealand
FREE CALL 0800 10 66 20
(New Zealand only)
electrolux induction cooktop service 25
904mm
556mm
46mm
Dimensions
Cut-out dimensions
704mm
444mm
radius
55mm
Induction cooking zone 1400W
with power boost function 2500W
Induction cooking zone 1800W
with power boost function 2800W
Control panel
Control panel
Induction cooking zone 2200W
with power boost function 3100W
Induction cooking zone 1800W
with power boost function 2800W
Corian
®
frame
Decorative
lighting strip
145mm
180mm
210mm
180mm
Corian® is a registered trademark of E. I. du Pont de Nemours and Company.
Chux® and Magic Eraser® are registered trademarks of the Clorox Australia Pty Limited
If you were not able to remedy the problem
yourself, please contact the Customer Care
Department or one of our service partners.
In order to be able to assist you quickly, we require
the following information:
– Model description
– Product number (PNC)
– Serial number (S No.)
(for numbers see rating plate)
– Type of fault
– Any error messages displayed by
the appliance
So that you have the necessary reference numbers
from your appliance at hand, we recommend that
you write them in here. They are locataed either n
the carton or base of product.
Serial number: ....................................................................
Location of product
information label
Information label
Assembled in China from German designed and made induction hob technology.
