Side 1/32
U S E R M A N U A L
W i n e s C e l l a r s
1
www.fhiaba.com ∙ info@fhiaba.com ∙ Info Line 800-344222 ∙ Tel +39 (0)434 420160 ∙ Fax +39 (0)434 420161
Index
Important instructions for safety and the environment
For your safety
Respect for the environment
Installation
Installation
Connection to the electrical mains
Before starting
Getting to know the appliance
Main features
Main components
Electronic Control
Main control panel
Turning the appliance on and off
Turning on and off
How to adjust the temperature to suit various needs
Information and malfunction signals on the display
Settings and Special Functions
Customization and Language Settings
Special functions activated through the Menu
Basic settings of the Menu
Internal Layout
Internal Layout (positioning, adjustment, removal)
Lighting
Lighting
Use of the TriMode compartment
Use of the TriMode compartment
TriMode compartment
Conservation of wines
General directions
Wine conservation temperature
Time of conservation
Consumption temperature
Position of bottles
Food Conservation
Recommendations for conserving fresh food
Recommendations for conserving frozen food
Recommended times for food conservation
Care and Cleaning
Care and Cleaning
Condenser cleaning
Internal cleaning
Troubleshooting guide
Troubleshooting guide
Malfunction indications appearing on the display
Prior to calling Service
Prior to calling Service
Fhiaba Access Menu Map
Functions
Settings
1
1.1
1.2
2
2.1
2.2
3
3.1
3.2
3.3
3.4
3.5
4
4.1
4.2
4.3
5
5.1
5.2
5.3
6
6.1
7
7.1
8
8.1
8.2
9
9.1
9.2
9.3
9.4
9.5
10
10.1
10.2
11
12
12.1
12.2
12.3
13
13.1
13.2
14
14.1
15
15.1
15.2
Page 2
3
4
8
10
15
16
17
18
21
22
23
24
26
27
3
2
2.1
2.2
1.2
www.fhiaba.com ∙ info@fhiaba.com ∙ Info Line 800-344222 ∙ Tel +39 (0)434 420160 ∙ Fax +39 (0)434 420161
Make sure you dispose properly of all packing materials.
The appliance must not be disposed of with urban waste.
Contact local waste disposal authorities for information on the disposal
of recyclable waste.
For disposal, cut the power supply cord and make it impossible to
close the door.
During disposal, avoid damage to the refrigeration circuit.
Neither the refrigeration circuit nor the insulation contain substances
that are hazardous to the ozone layer
Respect for the environment
Make sure that installation is performed correctly, adhering to all of
the instructions in the specic installation guide provided with the
appliance.
Installation
Connection to the electrical mains
The appliance is equipped with a Schuko type 16A plug.
It must be connected to the electrical mains by means of a corre-
sponding Schuko socket.
Do not use extension cords and/or multiple adapters for connection.
Do not use extension cords and/or multiple
adapters for connection.
Installation
If energy is supplied through an alternative ener-
gy power source (solar, geothermal, etc..) or if
home automation systems are installed, it is ne-
cessary to install the Alternative Energy Kit to in-
tegrate the unit into the power grid.
5
3
3.3
CantinaTriMode
TriMode
1
1
7
8
8
9
9
10
10
11
11
12
12
2
2
3
3
5
4
5
6
6
7
Wine Cellar
Wine Cellar
www.fhiaba.com ∙ info@fhiaba.com ∙ Info Line 800-344222 ∙ Tel +39 (0)434 420160 ∙ Fax +39 (0)434 420161
Before starting
Main components
One drawer Wine Cellar
1 Structure in stainless steel
with aluminium trim
2 Wine Cellar and TriMode
control panels with Menu
3 Sliding bottle shelfs,
mounted on wheels for
easy extraction
4 Cantina area control panel
5 Wine Cellar
6 Frezer compartment that
can be transformed into a
refrigerator or Crisper-Fresco
compartment
(TriMode function)
7 Double refrigeration system
8 Temperature display
9 Acoustic signals
10 Vacation function
(in Menu)
11 Innovative lighting
12 Automatic door and
drawer closure
1T Models
0T Models
8
4
4.1
www.fhiaba.com ∙ info@fhiaba.com ∙ Info Line 800-344222 ∙ Tel +39 (0)434 420160 ∙ Fax +39 (0)434 420161
Turning the appliance on and off
To prevent accidental modication of settings,
the keypad locks automatically after a certain
period of time and the display shows the mes-
sage “keypad locked”. To re-activate it, simul-
taneously press the keys Menu and Up/Down
(Down) for three seconds.
At the rst start-up, if the message Standby does
not appear, it means that the appliance has al-
ready started the cooling process. If this is the
case, deactivate any possible acoustic signals
by pressing the Alarm key , close the door and
wait until the set temperature is reached.
During the rst start-up, you will not be able to use
the Menu to modify factory settings until the de-
fault temperature has been reached. It is howev-
er possible to set the time and date immediately;
these parameters are required to activate some
of the special functions.
If only the Cantina or Wine Cellar compartment
is turned off, the corresponding fan will continue
to run independently to prevent the formation of
unpleasant odours and mould.
First start-up
Once you have turned on all of the compartments of the appliance,
you can turn off only the wine cellar compartment by pressing the
relevant key for three seconds.
The TriMode compartment is always on and cannot be turned off
except by completely turning off the appliance.
To shut down the unit completely for cleaning or maintenance, press
the Unit key for three seconds.
Also take the plug out of the socket and turn off the omnipolar switch
that powers it.
Turning off the Wine Cellar compartment
Turning the Wine Cellar compartment on
again
Complete shutdown
Lengthy shutdown periods
Turning on and off
Press again for three seconds the relevant key.
When the appliance is connected to the electrical power supply but
has not yet been turned on, the display shows the message
This is a safety message to warn that power is supplied to the appli-
ance, while all of the keys on the panel are off.
To switch on all the appliance compartments, press the Unit button
for three seconds.
After you have completely shut down the appliance and unplugged
it, empty it of all its contents, clean it and dry it. Leave the doors and
the drawers ajar to prevent the formation of unpleasant odours.
9
4
4.4
4.2
www.fhiaba.com ∙ info@fhiaba.com ∙ Info Line 800-344222 ∙ Tel +39 (0)434 420160 ∙ Fax +39 (0)434 420161
An integrated control system provides information through luminous
signals or text messages shown on the display.
The information signal is always displayed with a xed text message,
while a malfunction signal is shown with blinking text.
The acoustic signal that accompanies some malfunction signals can be
deactivated by pressing the Alarm key on the main control panel.
The list of malfunction signals is located in the back of this manual.
Turning on the appliance
To adjust the temperature in the various compartments, use the up/
down key for that compartment (see chapter 3.5).
If the “keypad locked” message appear, simultaneously press the keys
Menu and Up/Down (Down) for 3 seconds.
Wines compartment
TriMode compartment
Each model has been carefully tested before leaving the factory and
is adjusted so as to ensure high performance and low consumption.
The ideal temperature for wine conservation does however depend
on the types of wine you want to conserve, the method of conserva-
tion (Wine Cellar for conservation and consumption, or Cantina for the
conservation and aging of prized bottles).
It also varies according to personal taste.
Please refer to the guide on wine conservation included further ahead
in this manual.
As needed, you can reset the temperatures as follows:
Cantina Compartment:
from +4° C to +18° C (from 39.2° F to 64.4° F).
The default temperature is +12° C (53.6° F).
Wine Cellar compartment:
from +4° C to +18° C (from 39.2° F to 64.4° F).
The default temperature is +10° C (50° F).
The TriMode compartment is default set to freezer mode but it can also
be set to run as a refrigerator or cooler compartment.
Instructions for conversion are provided in the paragraph on special
functions and settings.
As needed, you can reset the temperatures as follows:
Freezer compartment: from -15° C to -22° C (from 5° F to -7.6° F).
The default temperature, which is recommended, is -18° (0° F)
Refrigerator compartment: from +2° C to +8° C (from 35.6° F to 46.4° F).
The default temperature, which is recommended, is +5° C (41° F).
Cooler compartment: from -2° C to +2° C (from 28.4° F to 35.6° F),
The default temperature, which is recommended, is 0° C (32° F).
The displayed temperature may vary slightly
with respect to the set temperature if the doors
are continuously opened or insertion of room
temperature food or large quantities of food.
It takes 6 to 12 hours to reach the selected tem-
perature.
Information and malfunction signals on the display
How to adjust the temperature for suit various needs
If the “keypad locked” message appear, simul-
taneously press the keys Menu and Up/Down
(Down) for 3 seconds.
10
5
5.1
5.2
FRIDGE
UNIT
www.fhiaba.com ∙ info@fhiaba.com ∙ Info Line 800-344222 ∙ Tel +39 (0)434 420160 ∙ Fax +39 (0)434 420161
Settings and Special Functions
To prevent accidental modication of settings,
the keypad locks automatically after a certain
period of time and the display shows the mes-
sage “keypad locked”.
To re-activate it, simultaneously press the keys
Menu and Up/Down (Down) for at least
three seconds.
Customization and Language Settings
Special functions activated through the Menu
It is possible to customized the functions of your Fhiaba to adapt it to di-
verse usage needs, resetting the main parameters (Settings) or activating
special functions (Functions).
Functions are visualized on the main display by pressing the Menu button
.
The Up/Down buttons permit scrolling the available functions, which can
be selected by pressing the Enter button . The display visualizes the cur-
rent functioning status.
Using the Up/Down buttons , it is also possible to scroll through the select-
ed function, activating or deactivating by pressing the Enter button .
Once the function is conrmed, the display will automatically visualize the
main menu to select other functions.
At any time it is possible to return to the previous selection through
the Menu button .
The language of the messages appearing on the display can be changed
by operating as follows:
Enter the Menu by pressing the Menu button select Settings via the Up/
Down buttons and conrm via Enter .
Then select the Language function and the desired language.
This function can be activated only on models featuring a wine cellar
without internal separator. It allows to differentiate the temperature in
the upper part of the cellar (warmer and therefore better suited to keep
red wines) from the temperature in the lower part (colder and therefore
better suited to keep white wines).
This function must be activated at least 24 hours before inserting room
temperature items into the freezer, or several hours before placing into
the freezer previously frozen items which have been subject to a slight
temperature rise. This function is automatically deactivated when the
programmed time period expires.
It is possible o program timed activation of the function.
After a prolonged interruption of the electrical power, it is necessary to
reactivate the function.
To use special functions, select the Menu key and use the Up/Down
key to access the menu, conrming the selection
.
How to activate
How to activate
How to deactivate
How to deactivate
How to program timed activation
Shopping TriMode
Dual Zone
11
5
www.fhiaba.com ∙ info@fhiaba.com ∙ Info Line 800-344222 ∙ Tel +39 (0)434 420160 ∙ Fax +39 (0)434 420161
Settings and Special Functions
This function (recommended in case of prolonged absences since it
allows considerable energy savings) brings the Tri-Mode compartment
temperature to - 18°C (46.4°F).
It is possible to program the duration, or it can be manually deacti-
vated upon re-entry after a period of absence.
This function remains active even if during the period of absence there
is a prolonged interruption of electrical power.
It is possible to program a period from 1 to 90 days.
This function can be activated when it is necessary to cool off bever-
ages quickly, by placing them inside the freezer compartment.
It is possible to select a duration of 1 to 45 minutes. A sound signal will
indicated when the optimal temperature has been reached.
After removing the beverages, deactivate the sound signal by press-
ing the Alarm button .
Bottle Cooler
How to activate
How to deactivate upon re-entry
How to program the duration
How to activate
How to deactivate
How to program the duration
Vacation TriMode
The function makes it possible to comply to certain religious observ-
ances requiring that the operation of the appliance is not affected by
the opening or closing of the doors (the thermostatic control, the inner
lighting and the ice maker are deactivated).
Sabbath Mode (Optional)
How to activate
How to deactivate
5.3
12
5
www.fhiaba.com ∙ info@fhiaba.com ∙ Info Line 800-344222 ∙ Tel +39 (0)434 420160 ∙ Fax +39 (0)434 420161
Settings and Special Functions
Basic settings of the Menu
This offers the possibility to reset default factory settings and cancels
any previous changes.
Default Setting
How to reset default settings
Using this function it is possible to deactivate/activate the date visuali-
zation on the display.
Show Date
How to activate the date
How to deactivate the date
The display will visualize the date in the format dd:mm:yy (day:month:year),
the day will blink. Use the Up/Down buttons to modify the setting, con-
rm with Enter to go on to the next setting; once the year is conrmed
the date will be set.
Date
Set Date
How to set the date
Select the Menu button and used the Up/Down button
to select .
The freezer compartment can, if required, be converted to the refrig-
eration o Crisper-Fresco operating mode.
TriMode Options
How to set the Fridge function
How to set the Crisper-Fresco function
How to revert to the Freezer function
ATTENTION: If the default settings are restored, it is
necessary to reactivate the choice of operation of
the TriMode compartment in case it was previously
set as Fridge or Fresco.
Produkspesifikasjoner
| Merke: | Fhiaba |
| Kategori: | Kjøleskap |
| Modell: | S5990TWT6A |
Trenger du hjelp?
Hvis du trenger hjelp med Fhiaba S5990TWT6A still et spørsmål nedenfor, og andre brukere vil svare deg
Kjøleskap Fhiaba Manualer
9 Februar 2025
9 Februar 2025
9 Februar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
Kjøleskap Manualer
- Kjøleskap Teka
- Kjøleskap Maytag
- Kjøleskap Thomson
- Kjøleskap Amana
- Kjøleskap Uniprodo
- Kjøleskap Miele
- Kjøleskap Whirlpool
- Kjøleskap Etna
- Kjøleskap Haier
- Kjøleskap KitchenAid
- Kjøleskap NewAir
- Kjøleskap Insignia
- Kjøleskap Adler
- Kjøleskap Pelgrim
- Kjøleskap Royal Catering
- Kjøleskap LG
- Kjøleskap Bosch
- Kjøleskap Jocel
- Kjøleskap BEKO
- Kjøleskap Exquisit
- Kjøleskap Grundig
- Kjøleskap Hisense
- Kjøleskap Sharp
- Kjøleskap Electrolux
- Kjøleskap Severin
- Kjøleskap Café
- Kjøleskap Balay
- Kjøleskap Siemens
- Kjøleskap Koldfront
- Kjøleskap Arcelik
- Kjøleskap Danby
- Kjøleskap Bartscher
- Kjøleskap Smeg
- Kjøleskap Hoover
- Kjøleskap Philips
- Kjøleskap TCL
- Kjøleskap Russell Hobbs
- Kjøleskap Hotpoint
- Kjøleskap Nabo
- Kjøleskap Amica
- Kjøleskap IKEA
- Kjøleskap Ignis
- Kjøleskap AEG
- Kjøleskap Rosieres
- Kjøleskap Inventum
- Kjøleskap Artusi
- Kjøleskap Cecotec
- Kjøleskap Samsung
- Kjøleskap Neff
- Kjøleskap Delonghi
- Kjøleskap Bomann
- Kjøleskap Edgestar
- Kjøleskap Kogan
- Kjøleskap Caple
- Kjøleskap PKM
- Kjøleskap Create
- Kjøleskap Marvel
- Kjøleskap G3 Ferrari
- Kjøleskap Yamaha
- Kjøleskap Midea
- Kjøleskap Franke
- Kjøleskap Sauber
- Kjøleskap Candy
- Kjøleskap Liebherr
- Kjøleskap Viking
- Kjøleskap Orbegozo
- Kjøleskap Kuppersbusch
- Kjøleskap Gorenje
- Kjøleskap Summit
- Kjøleskap Accucold
- Kjøleskap Brandt
- Kjøleskap Gram
- Kjøleskap Panasonic
- Kjøleskap Monogram
- Kjøleskap Vox
- Kjøleskap Westinghouse
- Kjøleskap Orava
- Kjøleskap Schneider
- Kjøleskap Kluge
- Kjøleskap Juno-electrolux
- Kjøleskap Bertazzoni
- Kjøleskap DCG
- Kjøleskap Coyote
- Kjøleskap Stirling
- Kjøleskap Privileg
- Kjøleskap MPM
- Kjøleskap Cosmo
- Kjøleskap Khind
- Kjøleskap Euro Appliances
- Kjøleskap Bauknecht
- Kjøleskap Frigidaire
- Kjøleskap Whynter
- Kjøleskap GE
- Kjøleskap Concept
- Kjøleskap Guzzanti
- Kjøleskap XO
- Kjøleskap Omega
- Kjøleskap Hitachi
- Kjøleskap Fisher Paykel
- Kjøleskap Fulgor Milano
- Kjøleskap Hyundai
- Kjøleskap Chiq
- Kjøleskap Vintec
- Kjøleskap Nevir
- Kjøleskap Eqtemp
- Kjøleskap Infiniton
- Kjøleskap Indesit
- Kjøleskap Daikin
- Kjøleskap Zephyr
- Kjøleskap Asko
- Kjøleskap Blaupunkt
- Kjøleskap Lamona
- Kjøleskap Mitsubishi
- Kjøleskap Marshall
- Kjøleskap Scandomestic
- Kjøleskap Cylinda
- Kjøleskap Respekta
- Kjøleskap AYA
- Kjøleskap Costway
- Kjøleskap Dometic
- Kjøleskap Blaze
- Kjøleskap Husky
- Kjøleskap Fridgemaster
- Kjøleskap Eldom
- Kjøleskap Fisher And Paykel
- Kjøleskap Elba
- Kjøleskap Worx
- Kjøleskap Philco
- Kjøleskap Jenn-Air
- Kjøleskap Wisberg
- Kjøleskap ECG
- Kjøleskap HomeCraft
- Kjøleskap Igloo
- Kjøleskap ATAG
- Kjøleskap Freggia
- Kjøleskap Becken
- Kjøleskap Element
- Kjøleskap Avanti
- Kjøleskap Acros
- Kjøleskap Kucht
- Kjøleskap Glem Gas
- Kjøleskap True
- Kjøleskap Perlick
- Kjøleskap Toshiba
- Kjøleskap BeefEater
- Kjøleskap Hansa
- Kjøleskap Thor
- Kjøleskap Sub-Zero
- Kjøleskap Koolatron
- Kjøleskap Coca-Cola
- Kjøleskap Kenmore
- Kjøleskap Meireles
- Kjøleskap Fagor
- Kjøleskap Edesa
- Kjøleskap IFB
- Kjøleskap Profilo
- Kjøleskap Gaggenau
- Kjøleskap Milectric
- Kjøleskap Tisira
- Kjøleskap Hiberg
- Kjøleskap LERAN
- Kjøleskap Zerowatt
- Kjøleskap Baumatic
- Kjøleskap Iberna
- Kjøleskap Ilve
- Kjøleskap Wolkenstein
- Kjøleskap Rommer
- Kjøleskap Hoover-Grepa
- Kjøleskap Primo
- Kjøleskap Svan
- Kjøleskap Landmark
- Kjøleskap Signature
- Kjøleskap Trisa
- Kjøleskap Corberó
- Kjøleskap Atosa
- Kjøleskap Scancool
- Kjøleskap FrigeluX
- Kjøleskap Mora
- Kjøleskap DAYA
- Kjøleskap Salora
- Kjøleskap Consul
- Kjøleskap Aconatic
- Kjøleskap Kuhla
- Kjøleskap Hestan
- Kjøleskap Optimum
- Kjøleskap Yolco
- Kjøleskap Thermador
- Kjøleskap Sangiorgio
- Kjøleskap Ardes
- Kjøleskap Ideal
- Kjøleskap Avallon
- Kjøleskap Continental Edison
- Kjøleskap Icecool
- Kjøleskap Crosley
- Kjøleskap Pitsos
- Kjøleskap Winia
- Kjøleskap Schaub Lorenz
- Kjøleskap Premium Levella
- Kjøleskap Linarie
- Kjøleskap Sogo
- Kjøleskap United
- Kjøleskap JennAir
- Kjøleskap Kalamazoo
- Kjøleskap Kaiser
- Kjøleskap Blomberg
- Kjøleskap Robinhood
- Kjøleskap De Dietrich
- Kjøleskap Orima
- Kjøleskap Zanussi
- Kjøleskap Lec Medical
- Kjøleskap Aspes
- Kjøleskap Benavent
- Kjøleskap Vedette
- Kjøleskap Kernau
- Kjøleskap Cookology
- Kjøleskap Hanseatic
- Kjøleskap Goddess
- Kjøleskap Edy
- Kjøleskap Thetford
- Kjøleskap Pando
- Kjøleskap U-Line
- Kjøleskap Equator
- Kjøleskap Romo
- Kjøleskap Rhino
- Kjøleskap Cooluli
- Kjøleskap Hoshizaki
- Kjøleskap SEIKI
- Kjøleskap Premium
- Kjøleskap Corona
- Kjøleskap Oranier
- Kjøleskap Germanica
- Kjøleskap Coors Light
- Kjøleskap FAURE
- Kjøleskap Turbo Air
- Kjøleskap Emperor's Select
- Kjøleskap Beverage-Air
- Kjøleskap Delfield
- Kjøleskap Galanz
- Kjøleskap Snaigė
- Kjøleskap Avantco
- Kjøleskap Ariston Thermo
- Kjøleskap Zanker
- Kjøleskap Miller Lite
- Kjøleskap Lanbo
- Kjøleskap Listo
- Kjøleskap Cool Head
- Kjøleskap Schmick
- Kjøleskap Brass Monkey
- Kjøleskap Helkama
- Kjøleskap Brandy Best
- Kjøleskap Waltham
- Kjøleskap Valberg
- Kjøleskap Rex
- Kjøleskap Momcube
- Kjøleskap LeCavist
- Kjøleskap Smart Brand
- Kjøleskap Castor
- Kjøleskap New World
- Kjøleskap Essentiel B
- Kjøleskap TESLA Electronics
- Kjøleskap Carpigiani
- Kjøleskap Lynx
- Kjøleskap BlueStar
- Kjøleskap Bompani
- Kjøleskap Prima
- Kjøleskap Sheffield
- Kjøleskap Stoves
- Kjøleskap Bushman
- Kjøleskap Richome
- Kjøleskap Sevenstars
- Kjøleskap Climadiff
- Kjøleskap Nemco
- Kjøleskap Haden
Nyeste Kjøleskap Manualer
17 August 2025
17 August 2025
17 August 2025
17 August 2025
17 August 2025
17 August 2025
17 August 2025
17 August 2025
17 August 2025
17 August 2025
