Side 1/5

80PK-24

SureGrip

Air Temperature

Probe

Instruction Sheet

XWWarning

To avoid electrical shock, do not use this

probe when voltages exceeding 24 V ac rms

or 60 V dc are present. The probe tip is

electronically connected to the output

terminals.

Introduction

The 80PK-24 SureGripTM Air Temperature Probe is

designed for measuring the temperature of air or gases.

The measuring bead of the probe is protected by a

perforated 304 Stainless Steel baffle to prevent accidental

damage. The sheath material is 300 Stainless Steel. The

38-inch (1 meter) cable is terminated with a Type K

miniature thermocouple connector with 0.792-mm (.312-in)

pin spacing. The 80PK-24 can be used with any

temperature-measuring instrument that is designed to

accept Type K thermocouples and has a miniature

connector input.

Specifications

Type

K Standard Grade Ni-Cr vs Ni-Al (Chromel vs Alumel)

Measurement Range

-40 °C to 816 °C (-40 °F to 1500 °F)

Accuracy

(With respect to ANSI MC96.1-1982-Standard Limits of

Error):

Note

All error calculations should be done in °C, then

scaled to °F.

Range

Accuracy

(% of reading)

-40 °C to 293 °C

(-40 °F to 559.4 °F)

±2.2 °C

293 °C to 816 °C

(559.4 °F to 1500 °F)

±0.75 %

November 2004 Rev.2, 9/09

All product names are trademarks of their respective companies

Produkspesifikasjoner

Merke:	Fluke
Kategori:	temperaturmåler
Modell:	80PK-24
Produkttype:	Testsonde
Materiale:	Rustfritt stål
Antall per pakke:	1 stykker
Lengde:	319 mm
Isolasjonsmateriale:	PVC
Kabellengde:	1 m
Produktfarge:	Black, Silver, Yellow
DC-spenning (maks):	60 V
