Side 1/13

PERFORMANCE ACCESS

100 AC/130 AC/165 AC/

570 AC/690 AC

User manual / Manuel d’utilisation

English page 2

Français page 6

English version

PERFORMANCE ACCESS

100 AC/130 AC/165 AC/570 AC/690 AC

User manual

Thank you for choosing Focal and for sharing our passion for the “Spirit of Sound”. Designed using the latest

technology, these speakers integrate Focal’s perfectionist believes, developing products with high power

handling, and unrivalled sound quality. To obtain the best results from this product, we recommend that you

follow carefully all the information contained in this user’s manual. If not correctly followed, any fault observed

may not be covered by the guarantee.

Warning

Continuous listening at high sound level (above 110dB) can durably damage your hearing. Listening above 130dB can

damage your hearing permanently.

Important recommendations

Before attempting any installation work, it is very important to check how much space is available to fit the speakers

into the vehicle.

Key points:

• Ensure the speaker is clean from debris and metallic particles that maybe attached (especially after drilling).

• Clean before mounting the speakers.

Conditions de garantie

All Focal loudspeakers are covered by guarantee drawn up by the official Focal distributor in your country.

Your distributor can provide all details concerning the conditions of guarantee. Guarantee cover extends at least to

that granted by the legal guarantee in force in the country where the original purchase invoice was issued.

The Focal guarantee only applies if the enclosed guarantee card

is returned to us within 10 days of purchase.

Orientation of the tweeter

The tweeter includes a rotary and adjustable tilt mechanism, that gives

the user a huge advantage in deciding the position the tweeter points,

ultimately changing the strength of the high frequencies produced.

Carefully turn the tweeter into position and make sure that it is directly

in line with the listener’s ears. (Cf. See drawing)

Your Focal-JMlab product was developed and manufactured with high-quality materials and components

which can be recycled and/or re-used. This symbol indicates that electrical and electronic equipment

must be disposed of separately from normal garbage at the end of its operational lifetime.Please dispose

of this product by bringing it to your local collection point or recycling centre for such equipment. This will

help to protect the environment in which we all live.

Produkspesifikasjoner

Merke:	Focal
Kategori:	Høyttaler
Modell:	690 AC
Vekt:	1050 g
Bredde:	239.4 mm
Dybde:	167.4 mm
Høyde:	91.7 mm
Høyttalere:	1
Impedans:	4 Ω
Toppeffekt:	150 W
Nominell effekt:	75 W
Forsterker inkludert:	Nei
Produktfarge:	Sort
Inngangsfrekvens:	55.06 Hz
Separate komponenter:	Nei
Subwoofer inkludert:	Nei
Basshøyttalerens diameter:	90 mm
Sensitivitet/følsomhet:	91.3 dB
Innbygningsdybde:	81.7 mm
Diameter for monteringshull:	222 mm
Subwoofer-driverens membranmateriale:	Fiberglass
Magnet vekt:	400 g
