Side 1/32

freshnrebel.com

#freshnrebel

Keep in touch:

ROCKBOX

BRICK XL

manual

1RB5500 Manual v2.indd 1-2 22/09/2017 09:33

ROCKBOX BRICK XL

1. Battery capacity LEDs: 1/4 = 25%, 2/4 = 50%, 3/4 = 75%, 4/4 = 100%

2. On/O

3. Bluetooth pairing button

4. Micro USB

5. Powerbank

6. Audio in

7. Audio out

Volume down

Previous song

Short press = play / pause

Short press = take / end calls

Long press = decline calls

Next song

Volume up

Touch buttons

Touch buttons1 2 4 63 5 7

1RB5500 Manual v2.indd 3-4 22/09/2017 09:33

READY TO ROCK? HERE’S HOW:

1. Charge the speaker with the Micro USB cable

The battery capacity LEDs will light up when the speaker is charging and

turn o when it’s done.

2. Turn the speaker on

Press the Bluetooth button for 3 seconds. When the touch buttons are

pulsing white, your speaker is ready for the Bluetooth connection.

3. Connect your device

Turn on Bluetooth and select the speaker from the list of available

devices. The touch buttons will turn solid white and you’ll hear a beep

when you’re connected.

Speaker (1) Speaker (2)

Left Right

TURN ON THE DOUBLE FUN MODE

Before you start - turn o Bluetooth on your phone/laptop/tablet.

1. Hold the Bluetooth button on the speaker (1) until the touch buttons will turn

blinking white.

2. Press the Bluetooth button on the speaker (2) twice in quick succession

(double click).

3. Once you have heard the *bleep* from both speakers, they are successfully

linked together.

4. Now turn on the Bluetooth connection on your phone/tablet/laptop.

5. Hold the Bluetooth button on the speaker (1) until the touch buttons will turn

blinking white.

6. In the Bluetooth menu select ‘Rockbox Brick XL’.

7. *Bleep*, your device is connected!

NOW YOU CAN ENJOY SUPERSTEREO SOUND.

1RB5500 Manual v2.indd 5-6 22/09/2017 09:33

Produkspesifikasjoner

Merke:	Fresh N Rebel
Kategori:	hub & dokkstasjon
Modell:	Rockbox Brick XL Fabriq Edition
Produkttype:	Stereo bærbar høyttaler
Vekt:	920 g
Bredde:	230 mm
Dybde:	95 mm
Høyde:	95 mm
Batterikapasitet:	5000 mAh
Bluetooth:	Ja
Bluetooth-versjon:	4.2
USB-kontakttype:	Micro-USB, USB Type-A
Tilkoblingsteknologi:	Trådløs
Strømkildetype:	Batteri
Antall USB 2.0-porter:	2
Antall høyttalere:	1
Anbefalt bruk:	Mobiltelefon/Smart-telefon
Impedans:	4 Ω
Batteritype:	Innebygget
Produktfarge:	Grafitt
Batteriliv (maks.):	15 timer
Hodetelefon ut:	Ja
AUX-inngang:	Ja
Signal-til-støy-forhold (SNR):	75 dB
USB-lading:	Ja
Lyd-utgang kanaler:	2.0 kanaler
RMS-rangert strøm/utgangseffekt:	20 W
Belysningsdiode:	Ja
Antall drivere:	2
Frekvensrekkevidde:	60 - 20000 Hz
Sensitivitet/følsomhet:	80 dB
Driverdiameter:	55.88 mm
Diameter på subwoofer-driver:	55.8 mm
Innebygget lader:	Ja
