Side 1/13

CA-IP500 Manual ENGLISH v3.indd 1

25/11/08 9:06:43 AM

Version 3.0

COMPATIBLE WITH THE

FOLLOWING IPOD MODELS:

iPod classic:

Gen 5, Gen 6, Gen 7

iPod touch:

Gen 1, Gen 2

iPod nano:

Gen 2, Gen 3, Gen 4

RECORD YOUR PRODUCT DETAILS HERE:

MODEL NUMBER DATE OF PURCHASE

AFFIX RECEIPT HERE

CONTENTS

• PRECAUTIONS & MAINTENANCE. . . . . . . . . . . . . . . . . . . . . . . . . . .pg 4

• DETACHABLE FRONT PANEL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 6

• BASIC OPERATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 7

• SETUP MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 8

• GENERAL SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg 8

• AUDIO SETUP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg 10

• DISPLAY SETUP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 10

• RDS SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg 11

• RADIO OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 12

• iPOD OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 13

• AUX OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 14

• INSTALLATION GUIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg 14

• TECHNICAL SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 18

• NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg 19

• WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 22

CA-IP500 Manual ENGLISH v3.indd 2-3

25/11/08 9:06:47 AM

PRECAUTIONS & MAINTENANCE

FCC COMPLIANCE STATEMENT

This device complies with part 15 of the FCC rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may

cause undesired operation.

• When cleaning the interior of the vehicle, do not get water or cleaning fluids on the

unit.

• Do not attempt to open the unit chassis. There are no user serviceable parts or

adjustment’s inside.

• This unit has been tested with all compatible authentic iPod models under normal

expected operating conditions, free from any pre-existing defects in either the unit or

the iPod.

No responsibility can be taken for use of the unit other than under normally expected

operating conditions in conjunction with fully functional and undamaged iPod units

which have been manufactured and authorised by Apple Inc.

• Before inserting iPod,

Please ensure iPod dock connector is clean, dry & free from damage.

Check that unit iPod dock is free from obstructions.

Insert correct sleeve combination to match your iPod

(Never insert iPod without a correct sleeve.)

• Ensure iPod is inserted with display facing upwards, Never force your iPod into the

dock, if the iPod does not mate with reasonable ease the sleeve/iPod combination is

most likely incorrect.

• Always remove your iPod from the unit when not in use & do not leave in your vehicle,

this in turn prevents risk of theft or damage as vehicle cabins can reach extreme

temperatures.

• Do not remove iPod or use stereo in a distractive manner whilst operating the vehicle,

check and obey all traffic laws in association with use.

• Take care when removing iPod from unit as surfaces may be warm.

Apple, the Apple logo, iPod and iTunes are Trademarks of Apple Computer, Inc.,

registered in the U.S. and other countries.

“MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thompson.”

“Supply of this product only conveys a license for private, non-commercial use and does not convey a

license nor imply any right to use this product in any commercial (i.e. revenue generation) real time

broadcasting (terrestrial, satellite, cable and/or any other media), broadcasting / streaming via internet,

intranets and/or other networks or in other electronic content distribution systems, such as pay-audio

or audio-on-demand applications. An independent license for such use is required. For details, please visit

http://www.mp3licensing.com”

TUNER SETTING

For correct operation in America, Tuner Frequency stepping needs to be changed,

Default setting is Europe), to Change:

SELECT: Menu - General - Area - America 1

TROUBLE SHOOTING

In the event of a malfunction, where normal operation is not automatically restored within 1

minute. Please remove Front Panel and press “RESET” Button in location shown

(using a paper clip or similar)

CA-IP500 Manual ENGLISH v3.indd 4-5

25/11/08 9:06:48 AM
