Side 1/4
Instruction for Changing Direction of opening the door6
Changing the Direction of Opening the Door EN
For one - door appliances, 540 mm width
If you find the direction of opening the door on your
appliance inconvenient, you can change it. Holes
on the opposite side have already been prepared
in the factory and are now plugged.
• Remove the cover on the upper hinge,
the appliance (the door is not fixed on the
middle hinge).
• Take off all door corners and interchange
them (instead of the corner with a hole insert
the one without the hole and vice versa).
• Unscrew the lower hinge with foot and the
other foot.
• Fix the lower hinge with foot to the opposite
side and fix the other foot on the place where
previously was the hinge.
• Put the door of the appliance on the lower
hinge.
• Fix the upper hinge and cover it.
• Unscrew the handle and replace it on the
opposite side (not for handles mouinted
horizontally).
Some screws are covered with caps. Take
them off before undoing the screws.
• Plug the remaining holes with decorative
caps.
• Check the gasket, it shouldn't be creased
and it should seal well. In case it does not fit
perfectly, pull it out and rotate for 180°. In
certain models it is not possible to replace
the door gasket. Should the seal not adhere
to the casing of the appliance perfectly, it will
have to be heated from a suitable distance
(by means of hair drier, for example) and
lightly stretched to the required height. In
certain models it is not possible to replace
the door gasket.
Changing the Direction of Opening the Door
on the Low Temperature Compartment
• Unscrew the blocking element and the hinge
of the low temperature compartment and
take off the door.
• Plug the holes with plastic caps provided.
Turn the door for 180° and replace it on the
opposite side of the low temperature
compartment. Fix the hinge and the blocking
element of the door (position of holes
already provided).
1 Cover for the upper hinge
2 Upper hinge
3 Foot
4 Handle
5 Lower hinge with foot
6 Corner without a hole
7 Corner with a hole
8 Low temperature compartment
9 Blocking element
10 Door hinge
Instruction for Changing Direction of opening the door 7
For one - door appliances with worktop,
500 mm width
If you find the direction of opening the door on your
appliance inconvenient, you can change it. Holes
on the opposite side have already been prepared
in the factory and are now plugged.
• Unscrew the lower hinge with foot and
remove the door ot the appliance.
• Unscrew the other foot and fix it on the place
where previously was the hinge with the foot.
• Rotate the fastener having the function of
the upper hinge counter clockwise, take it off
and replace it on the opposite side of the
door.
• Put the door on the fastener having the function of
the upper hinge.
• Put the fastener with foot of the lower hinge
(with a washer) into the plastic corner with a
hole and fix the lower hinge.
• Unscrew the handle and replace it on the
opposite side (not for handles mouinted
horizontally).
Some screws are covered with caps. Take
them off before undoing the screws.
• Plug the remaining holes with decorative
caps.
• Check the gasket, it shouldn't be creased
and it should seal well. In case it does not fit
perfectly, pull it out and rotate for 180°. In
certain models it is not possible to replace
the door gasket. Should the seal not adhere
to the casing of the appliance perfectly, it will
have to be heated from a suitable distance
(by means of hair drier, for example) and
lightly stretched to the required height. In
certain models it is not possible to replace
the door gasket.
Changing the Direction of Opening the Door
on the Low Temperature Compartment
• Unscrew the blocking element and the hinge
of the low temperature compartment and
take off the door.
• Plug the holes with plastic caps provided.
• Turn the door for 180° and replace it on the
opposite side of the low temperature
compartment. Fix the hinge and the blocking
element of the door (position of holes
already provided).
1 Lower hinge with foot
2 Lower hinge washer
3 Foot
4 Fastener
5 Handle
6 Low temperature compartment
7 Blocking element
8 Door hinge
Instruction for Changing Direction of opening the door8
For two - door appliances, 500 mm width
If you find the direction of opening the door on your
appliance inconvenient, you can change it. Holes
on the opposite side have already been prepared
in the factory and are now plugged.
• Remove the cover on the upper hinge,
door (the door is not fixed on the middle
hinge), don't forget to remove the washer
from the middle hinge.
• Unscrew the lower hinge with foot and
washer and remove the refrigerator door.
• Unscrew the middle hinge and the other foot.
• Fix the lower hinge with foot (and washer) to
the opposite side and fix the other foot on
the place where previously was the hinge.
• Put the refrigerator door on the lower hinge.
• Rotate the middle hinge for 180°, replace it
to the opposite side of the door and fix it.
• Put on the washer first and then the upper
door.
• Fix the upper hinge and cover it.
• Unscrew the handles and replace them to
the opposite side (not for handles mouinted
horizontally). Some screws are covered with
caps. Take them off before undoing the
screws.
• Plug the remaining holes with decorative
caps.
• Check the gasket, it shouldn't be creased
and it should seal well. In case it does not fit
perfectly, pull it out and rotate for 180°. In
certain models it is not possible to replace
the door gasket. Should the seal not adhere
to the casing of the appliance perfectly, it will
have to be heated from a suitable distance
(by means of hair drier, for example) and
lightly stretched to the required height. In
certain models it is not possible to replace
the door gasket.
1 Cover for the upper hinge
2 Upper hinge
3 Middle hinge
4 Middle hinge washer
5 Lower hinge with foot
6 Lower hinge washer
7 Foot
8 Handle
