Gorenje NRK6191TX Bruksanvisning

Gorenje Kjøleskap NRK6191TX

Les nedenfor 📖 manual på norsk for Gorenje NRK6191TX (40 sider) i kategorien Kjøleskap. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/40

Instruction manual

Refrigerator freezer

413758

We thank you for the conﬁ dence you have shown by purchasing our appliance.

We wish you ﬁ nd a lot of pleasure in its use.

The appliance is intended to be used in household and similar applications such as

- staff kitchen areas in shops, ofﬁ ces and other working environments;

- bed and breakfast type environments.

It is NOT intended to be used in:

- farm houses and by clients in hotels, motels and other residential type environments;

- catering and similar non-retail applications.

Refrigerator freezer (hereinafter: the appliance) consists of two parts: the upper part is the

refrigerator and the lower part is the freezer.

The refrigerator is intended for storing fresh food at temperatures above 0°C.

The freezer is intended for freezing fresh food and for long-term storage of

frozen food (up to one year, depending on the type of food).

Important notes and warnings ................................... 3

Advice for saving power with refrigeration

appliances .................................................................... 5

Appliance description ................................................. 6

Installation and connection ........................................ 8

Changing the direction of door opening ................. 10

Operating the appliance with mechanic controls... 13

Appliance with electronic control ............................ 14

Appliance interior equipment ................................... 23

Recommended distribution

of food in the appliance ............................................ 27

Storing food in the refrigerator ................................ 28

Storing food in the FreshZone drawer .................... 29

Storing food in the ZeroZone drawer ...................... 30

Freezing and storing frozen food ............................. 31

Defrosting the appliance ........................................... 34

Cleaning the appliance ............................................. 35

Troubleshooting ........................................................ 36

Information about appliance noise .......................... 38

413758

• The appliance is manufactured in compliance with

the effective safety standards. However, it can be

used by children aged from 8 years and above

and persons with reduced physical, sensory or

mental capabilities or lack of experience and

knowledge if they have been given supervision or

instruction concerning use of the appliance in a

safe way and understand the hazards involved.

• Before connecting the appliance to the power

mains, please read carefully the instructions

for use which describe the appliance and its

correct and safe use. The instructions apply for

several appliance types/models; thus, settings

or equipment may be described herein which is

not available in your appliance. The instruction

manual includes the NO FROST version/model of

the freezer which is ﬁ tted with a fan and in which

the defrosting process is automatic.

• Remove the packaging intended for protecting the

appliance or particular parts during transport.

• Spacers are ﬁ tted on the corners of the doors.

Remove them and insert the supplied plugs into

their slots (only in some models).

• Before connecting the appliance to the power

mains, let the appliance rest in a vertical position

for approximately 2 hours. This will reduce the

possibility of operation faults due to the effect of

transport on the cooling system.

• The appliance must be connected to the power

mains and grounded in compliance with the

effective standards and regulations.

• The appliance may not be used outdoors and it

may not be exposed to rain.

• Before cleaning the appliance, unplug the

appliance from the power mains (unplug the

power cord from the wall outlet).

• If the power cord is damaged, it must be replaced

by a service technician or other adequately

trained person.

• If the appliance will be out of use for a prolonged

period of time, switch it off using the relevant

button, and unplug the appliance from the power

Important notes and warnings

Produkspesifikasjoner

Merke:	Gorenje
Kategori:	Kjøleskap
Modell:	NRK6191TX
Innebygd skjerm:	Ja
Vekt:	68000 g
Bredde:	600 mm
Dybde:	640 mm
Høyde:	1850 mm
Dørhengsel:	Riktig/Høyre
Årlig energiforbruk:	299 kWh
Klimaklasse:	SN-T
Støynivå:	42 dB
Energieffektivitetsklasse (gammel):	A+
Frysekapasitet:	12 kg/24t
Hurtigfrysingsfunksjon:	Ja
Antall stjerner:	4*
Temperaturalarm:	Ja
Flaskestativ:	Ja
Total bruttokapasitet:	329 l
Hyllemateriale:	Herdet glass
Kjølemedium:	R600a
Pakkevekt:	70500 g
AC-inngangsspenning:	220 - 230 V
Produktfarge:	Rustfritt stål
Pakkedybde:	750 mm
Pakkehøyde:	1910 mm
Pakkebredde:	640 mm
Skjermtype:	LED
Kjøleskap brutto kapasitet:	231 l
Lagringstid ved strømbrudd:	18 timer
Svinghjul:	Ja
Energibruk:	0.819 kWh/24t
Vendbare dører:	Ja
Strøm:	10 A
Plassering av innretning:	Frittstående
Antall hyller i fryser:	3
Tilkoblet nettbelastning:	120 W
Fryser netto kapasitet:	85 l
Antall hyller/bokser i kjøleskap:	4
Kjøleskap netto kapasitet:	222 l
Super Cool-funksjon:	Ja
Fresh zone compartment:	Ja
Alarm når døren står åpen:	Ja
Justerbare bein:	Ja
Number of compressors:	1
Total netto kapasitet:	307 l
Fryserposisjon:	Bunn-plassert
Fryser brutto kapasitet:	98 l
Egg balcony:	Ja
Multi-Luftflytsystem (kjøleskap):	Ja
Ikke-frost (kjøleskap):	Ja
Dørhyller kjøleskap:	2
Ikke-frost (fryser):	Ja
Multi-Luftflytsystem (fryser):	Ja
