Gorenje RK62358OR-L Bruksanvisning

Gorenje Kjøleskap RK62358OR-L

Les nedenfor 📖 manual på norsk for Gorenje RK62358OR-L (28 sider) i kategorien Kjøleskap. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/28

Instructions for use

Upright refrigerator - freezer

142468

Thank you for your conﬁ dence in buying our appliance and congratulations on the excellent choice.

We hope it will successfully serve its purpose for many years.

Upright refrigerator - freezer (hereinafter: the appliance) is combined from two parts: top part is

refrigerator and bottom part is upright freezer.

Refrigerator is used in households for storage of fresh food at temperatures above 0°C).

Freezer is used in households for freezing fresh food and storage of frozen food for up to one year

(depending on the type of food).

Before ﬁ rst operation .................................................. 3

Appliance description

(equipment may vary with model).............................. 5

Installation and connection ........................................ 7

Reverse door swing .................................................. 9

Control panel - appliance with

electronical regulation .............................................. 10

Control panel - appliance with

mechanical regulation ............................................. 18

Recommended distribution of food ........................ 20

Storing fresh food ................................................... 21

Storage of food in the COOL´N´FRESH ................... 23

Freezing and storage of frozen food ....................... 23

Defrosting the appliance ........................................... 25

Cleaning ..................................................................... 26

Troubleshooting guide .............................................. 27

Noise level .................................................................. 28

142468

• The appliance is manufactured in compliance with all relevant safety standards; however, it is

recommended that persons with impaired physical, motional, or mental abilities, or persons with

inadequate experience and knowledge, do not use the appliance without due supervision. The

same recommendation applies to minors using the appliance.

• Before connecting the appliance read these instructions carefully. They describe the appliance

and provide instructions for its safe and correct use. The instructions are prepared for

different types and models of the appliance so they may contain descriptions of functions and

components your appliance may not have.

Instructions also contain the NO FROST freezer version, with integrated fan and automatic

defrost.

• Remove the wrapping protecting the appliance during transport.

• Door corners are ﬁ tted with protective spacers. Remove the spacers and replace them with the

attached pegs (certain models only).

• Before connecting the appliance to the mains supply, leave it in upright position for about 2

hours. This will reduce possibility of malfunctions in the cooling system resulting from prior

transport and handling.

• The appliance must be connected to the mains supply in accordance with the standing

regulations and local requirements.

• The appliance must not be used in open air or exposed to weather precipitation.

• Always disconnect the appliance from power supply (pull the power cord from wall socket) before

cleaning and before replacing the light bulb.

• If the power supply cord is damaged, in order to avoid hazard it must be replaced by the service

or by qualiﬁ ed personnel.

• In event of long periods without use, switch off the appliance off with the ON/OFF button and

disconnect it from mains supply. Empty the appliance, clean the interior and leave the door ajar.

• For the protection of environment, please contact local Borough or Council for correct disposal

arrangements.

• Wrappings contain environmentally friendly materials which can be recycled, recovered or

disposed without threat to the environment.

• Never let the children play with the appliance.

• Self closing door hinge (certain models only) pulls the door to the cabinet just before closing,

thereby preventing the door to remain ajar. Equally it limits the door opening angle and prevents

damage to adjacent elements.

• Rating plate with basic information is located in the interior of the appliance. If the sticker plate is

not suitable for your language, replace it with the attached one.

• Warning: Ventilation slots on the appliance or built-in element should always be kept clean and

unobstructed.

• Warning: Do not use any mechanical accessories when thawing the refrigerator, except for

those explicitly recommended by the manufacturer.

• Warning: To prevent any pollution be careful not to damage the insulation or refrigeration tubes

at the rear wall during the installation, cleaning and disposal of the appliance.

• Warning: Do not use any electrical devices inside the appliance, except for those explicitly

recommended by the manufacturer.

Before ﬁ rst operation

Produkspesifikasjoner

Merke:	Gorenje
Kategori:	Kjøleskap
Modell:	RK62358OR-L
Innebygd skjerm:	LED
Vekt:	77000 g
Bredde:	600 mm
Dybde:	640 mm
Høyde:	1887 mm
Dørhengsel:	Venstre
Årlig energiforbruk:	301 kWh
Klimaklasse:	SN-T
Støynivå:	42 dB
Energieffektivitetsklasse (gammel):	A+
Frysekapasitet:	10 kg/24t
Avrimingsfunksjon:	Ja
Hurtigfrysingsfunksjon:	Ja
Antall stjerner:	4*
Temperaturalarm:	Ja
Flaskestativ:	Ja
Total bruttokapasitet:	342 l
Hyllemateriale:	Herdet glass
Isbitbrett:	Ja
Termostat:	Ja
Pakkevekt:	85000 g
Frostfritt system:	Nei
AC-inngangsspenning:	220 - 230 V
AC-inngangsfrekvens:	50 - 60 Hz
Produktfarge:	Rød
Pakkedybde:	740 mm
Pakkehøyde:	1970 mm
Pakkebredde:	660 mm
Formfaktor:	Rett opp
Kroppsmateriale:	Metall
Kjøleskap brutto kapasitet:	- l
Number of vegetable drawers:	1
Lagringstid ved strømbrudd:	18 timer
Vendbare dører:	Nei
Plassering av innretning:	Frittstående
Tilkoblet nettbelastning:	- W
Fryser netto kapasitet:	86 l
Antall hyller/bokser i kjøleskap:	4
Kjøleskap netto kapasitet:	229 l
Fresh zone compartment:	Nei
Innvendig lys kjøleskap:	Ja
Justerbare bein:	Ja
Number of compressors:	1
Total netto kapasitet:	315 l
Fryserposisjon:	Bunn-plassert
Fryser brutto kapasitet:	- l
Multi-airflow system:	Nei
