Side 1/32

Instructions for Use

Washing machine

276657

Thank you for your conﬁ dence in purchasing our washing machine, and congratulations on the

excellent choice.

Your new washing machine meets the requirements of modern treatment of laundry. It is rational in

the consumption of energy, water and washing agents.

Our appliances are friendly to the environment. Some of the materials may be recycled, others

deposited or decomposed. To avoid pollution of environment, once your appliance is no longer

useful, take it to your local authorized waste appliance dealer.

The appliance is intended exclusively for use in households. If the appliance is used for

professional purposes, for proﬁ t, or for purposes beyond regular use in a household, or if appliance

is used by a person who is not a consumer, the warranty period equals the shortest warranty period

possible as stipulated by the relevant legislation.

Description of washing machine .................................. 3

Cautions ..........................................................................4

Installation and connection ...........................................5

Operation .........................................................................8

Tips for washing and energy saving .......................... 15

Cleaning and maintenance ..........................................17

Troubleshooting ........................................................... 19

Tables ............................................................................23

276657

1. Front panel

2. Detergent dispenser

3. Door

4. Filter lid

5. Adjustable legs

6. Water outlet hose

7. Water inlet hose

8. Mains power cable

• Max. load: 6 kg

Dimensions (w x d x h):

600 mm x 600 mm x 850 mm

Depth with door open: 105 cm

Weight (net): 72 kg

Nominal voltage: 220 V / 230 V, 50 Hz

(depending on model)

Rated power: 2000 W

Power socket: (220 V / 230 V, 50 Hz, 10 A)

(depending on model)

Water pressure: min. 0,05 MPa, max. 0,8 MPa

Fuse: 10 A

• Max. load: 5,5 kg / 5 kg

Dimensions (w x d x h):

600 mm x 440 mm x 850 mm

Depth with door open: 88 cm

Weight (net): 61 kg

Nominal voltage: 220 V / 230 V, 50 Hz

(depending on model)

Rated power: 2000 W

Power socket: (220 V / 230 V, 50 Hz, 10 A)

(depending on model)

Water pressure: min. 0,05 MPa, max. 0,8 MPa

Fuse: 10 A

Rating plate with basic information is located above the opening of the

machine.

Description of washing machine

Technical information

(depending on model)

Produkspesifikasjoner

Merke:	Gorenje
Kategori:	Vaskemaskin
Modell:	WA612SYW
Innebygd skjerm:	Ja
Vekt:	72000 g
Bredde:	600 mm
Dybde:	600 mm
Høyde:	850 mm
Energieffektivitetsklasse (gammel):	A+
Vannforbruk per syklus:	- l
Støynivå (vask):	59 dB
Selvrensende:	Ja
Antall vaskeprogrammer:	15
Pakkevekt:	74000 g
Nominell kapasitet:	6 kg
Vaskeprogrammer:	Hygiene/anti-allergy, Black
Strømforbruk (standby):	0.1 W
Produktfarge:	Hvit
Pakkedybde:	685 mm
Pakkehøyde:	920 mm
Pakkebredde:	640 mm
Skjermtype:	LED
Kontrolltype:	Buttons, Rotary
Sentrifugeringsklasse:	C
Støynivå (spinn):	74 dB
Lastetype:	Frontmatet
Restfuktighet:	53
Aquastop-funksjon:	Ja
Strøm:	10 A
Plassering av innretning:	Frittstående
Tilkoblet nettbelastning:	2000 W
Dør farge:	Hvit
Døråpeningsvinkel:	180 °
Halvfull maskin:	Ja
Forsinket start timer:	Ja
Trommelvolum:	54 l
Maksimal sentrifugeringshastighet:	1200 RPM
Syklustid (maksimum):	149 min
Justerbar spinnhastighet:	Ja
Overflow beskyttelse:	Ja
Energiforbruk ved vask per syklus:	0.66 kWh
Årlig energiforbruk (vasking):	192 kWh
Årlig vannforbruk (vasking):	9177 l
Ingen skylling:	Ja
Automatisk diagnostikk:	Ja
