Gorenje WS53105 Bruksanvisning

Gorenje Vaskemaskin WS53105

Les nedenfor 📖 manual på norsk for Gorenje WS53105 (32 sider) i kategorien Vaskemaskin. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/32

Instructions for Use

Washing machine

311220

Thank you for your conﬁ dence in purchasing our washing machine, and congratulations on the

excellent choice.

Your new washing machine meets the requirements of modern treatment of laundry. It is rational in

the consumption of energy, water and washing agents.

Our appliances are friendly to the environment. Some of the materials may be recycled, others

deposited or decomposed. To avoid pollution of environment, once your appliance is no longer

useful, take it to your local authorized waste appliance dealer.

The appliance is intended exclusively for use in households. If the appliance is used for

professional purposes, for proﬁ t, or for purposes beyond regular use in a household, or if appliance

is used by a person who is not a consumer, the warranty period equals the shortest warranty period

possible as stipulated by the relevant legislation.

Description of washing machine .................................. 3

Cautions ..........................................................................4

Installation and connection ...........................................5

Operation .........................................................................9

Tips for washing and energy saving .......................... 19

Cleaning and maintenance ..........................................20

Troubleshooting ........................................................... 23

Tables ............................................................................27

311220

1. Front panel

2. Detergent dispenser

3. Door

4. Filter lid

5. Adjustable legs

6. Water outlet hose

7. Water inlet hose

8. Mains power cable

• Max. load: 8 kg / 7 kg

Dimensions (w x d x h):

600 mm x 600 mm x 850 mm

Depth with door open: 106 cm

Weight (net): 78 kg / 93 kg

Nominal voltage: 230 V, 50 Hz

Power: 2300 W

Power socket: (230 V, 50 Hz, 10 A)

Water pressure: min. 0,05 MPa, max. 0,8 MPa

Fuse: 10 A

• Max. load: 5,5 kg / 5 kg

Dimensions (w x d x h):

600 mm x 440 mm x 850 mm

Depth with door open: 88 cm

Weight (net): 78 kg / 63 kg

Nominal voltage: 230 V, 50 Hz

Power: 2000 W

Power socket: (230 V, 50 Hz, 10 A)

Water pressure: min. 0,05 MPa, max. 0,8 MPa

Fuse: 10 A

Description of washing machine

Technical information

(depending on model)

Produkspesifikasjoner

Merke:	Gorenje
Kategori:	Vaskemaskin
Modell:	WS53105
Innebygd skjerm:	Ja
Bredde:	600 mm
Dybde:	440 mm
Høyde:	850 mm
Energieffektivitetsklasse (gammel):	A+
Vannforbruk per syklus:	- l
Støynivå (vask):	66 dB
Antall vaskeprogrammer:	19
Nominell kapasitet:	5 kg
Vaskeprogrammer:	Hygiene/anti-allergy, Black, Cotton, Hand/wool, Synthetics
Produktfarge:	Hvit
Skjermtype:	LCD
Sentrifugeringsklasse:	C
Lastetype:	Frontmatet
Aquastop-funksjon:	Ja
Plassering av innretning:	Frittstående
Forsinket start timer:	Ja
Maksimal sentrifugeringshastighet:	1000 RPM
Syklustid (maksimum):	160 min
Overflow beskyttelse:	Ja
Energiforbruk ved vask per syklus:	- kWh
Vaskeklasse:	A
