Hannspree Hanns.G HE 196 APB Bruksanvisning

Hannspree skjerm Hanns.G HE 196 APB

Les nedenfor 📖 manual på norsk for Hannspree Hanns.G HE 196 APB (20 sider) i kategorien skjerm. Denne guiden var nyttig for 6 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/20

HE196APB (HSG1312)

User’s Manual OSD[V5.9]

Before operating the monitor, please read this manual thoroughly. This manual should be retained for

future reference.

FCC Class B Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy, and if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful interference to radio

or television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

 Reorient or relocate the receiving antenna.

 Increase the separation between the equipment and receiver.

 Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

 Consult the dealer or an experienced radio/TV technician for help.

The device complies with Parts 15 of the FCC Rule. Operation is subject to the following two

conditions﹕ (1) this device may not cause harmful interference﹔ and (2) this device must accept any

interference received, including interference that may cause undesired operations.

CANADA

This Class B digital apparatus meets all requirements of the Canadian Interference-Causing

Equipment Regulation.

【Optional, depend on selected model】

This device complies with requirement of EMC directive 2004/108/EC with regard to

Electromagnetic Compatibility, and 2006/95/EC and 93/68/EEC with regard to Low Voltage

directive.

【Optional, depend on selected model】

Socket-outlet shall be near the equipment and shall be accessible.

User’s Manual

RECYCLING INFORMATION

We, at HANNspree care very much about our environment protection strategy and firmly believe

that it helps us have healthier earth via appropriate treatment and recycling of industrial technology

devices at the end-of-life.

These devices contain recyclable materials, which can be re-decomposed and re-integrated into

brand-new marvels. On the contrary, other material can be classified to hazardous and poisoned

substances. We strongly encourage you to contact the provided information to recycle this product.

For more information, please visit

http://www.hannspree.eu/

Produkspesifikasjoner

Merke:	Hannspree
Kategori:	skjerm
Modell:	Hanns.G HE 196 APB
Farge:	Sort
LED-indikatorer:	Kraft indikator
Bluetooth:	Nei
Berøringsskjerm:	Nei
Wi-Fi:	Nei
Synsvinkel, horisontal:	90 °
Skjermform:	Flat
Pakkevekt:	3400 g
DVI-port:	Nei
Innebygde høyttalere:	Ja
Antall høyttalere:	2
Maksimal oppdateringshastighet:	60 Hz
3D:	Nei
HDMI:	Nei
Skjermteknologi:	LED
Kontrastforhold (dynamisk):	10000000:1
Energieffektivitetsklasse (SDR):	D
Energiforbruk (SDR) per 1000 timer:	11 kWh
Vekt (med stativ):	2500 g
AMD FreeSync:	Nei
NVIDIA G-SYNC:	Nei
Antall per pakke:	1 stykker
On Screen Display (OSD):	Ja
Tynn klient installert:	Nei
Innebygd USB-hub:	Nei
Flimmerfri teknologi:	Ja
Kontrastforhold:	600:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Energieffektivitetsskala:	A til G
Skjermoppløsning:	1366 x 768 piksler
Strømforbruk (standby):	0.33 W
Høydejustering:	Nei
Produktfarge:	Sort
HD-type:	WXGA
Vippevinkelområde:	-5 - 20 °
Bredde (uten stativ):	- mm
Høyde (uten stativ):	- mm
Vekt (uten stativ):	- g
Bredde (med stativ):	442 mm
Dybde (med stativ):	185 mm
Høyde (med stativ):	344 mm
Pakkedybde:	115 mm
Pakkehøyde:	336 mm
Pakkebredde:	515 mm
Skjermdiagonal:	18.5 "
Naturlig sideforhold:	16:9
Hodetelefon ut:	Nei
Støttede grafikkoppløsninger:	1366 x 768
Kabler inkludert:	AC, Audio (3.5mm), VGA
Pakketype:	Boks
Horisontalt frekvensområde:	31 - 61 kHz
Strømforbruk (vanlig bruk):	10.2 W
Antall VGA (D-Sub)-porter:	1
Driftstemperatur (T-T):	5 - 35 °C
Hurtigstartsguide:	Ja
VESA-montering:	Ja
Dybde (uten stativ):	- mm
Paneltype:	TFT
Synsvinkel, vertikal:	65 °
PC-lydinngang:	Ja
Av/på-bryter:	Ja
Ethernet/bredbåndsforbindelse:	Nei
Relativ luftfuktighet under drift (H-H):	20 - 85
Oppdateringsresponstid:	5 ms
Pikselbredde:	0.3 x 0.3 mm
Antall OSD språk:	12
Panelmonterbart grensesnitt:	100 x 100 mm
RMS-rangert strøm/utgangseffekt:	3 W
Skjermlysstyrke (typisk):	200 cd/m²
Display antall farger:	16.78 million farger
Display:	LED
Innebygd TV-mottaker:	Nei
Kabellåsport:	Ja
Fremre ramme:	Sort
Avtagbart stativ:	Ja
Vippjustering:	Ja
Europeisk produktregister for energimerking (EPREL-kode):	403821
Vertikal scanningsratio:	56 - 75 Hz
Kabellåstype:	Kensington
Strømforbruk, av:	0.28 W
Lydkontakter:	Nei
Plugg inn og spill:	Ja
