HE247DPB

60cm / 23.6” Diagonal LED Monitor

• LEDBacklightMonitor

• FullHD1080P

• 1920x1080WUXGAResolution

• 40,000,000:1ActiveContrast

• 5msFastResponseTime

• VGA+DVI(HDCP)Inputs

• Built-InStereoSpeakers

• LowPowerConsumption

• Multi-VideoModes:PC/Movie/Game/ECO

• TiltandWall-Mountable(VESA)

• ECOFriendly

US/EU/

CN/TW

BUILT-IN

STEREO SPEAKERS

40,000,000:1

FAST

RESPONSE TIME

5ms

Friendly

DVI

VGA

1920 x 1080

RESOLUTION

LCD Panel Display size 60cm / 23.6” Diagonal Wide LED

Brightness 250cd/m2

Contrast 1,000:1

40,000,000:1(active contrast)

Pixel pitch 0.2715(H) x 0.2715(V) mm

Resolution (H x V) 1920 X 1080

Aspect Ratio 16:9

Response time 5ms

View angles LR,UD H/V 170°/160°

Color WARM,NATURE,COOL, User Mode

Panel surface Anti-Glare

Display colors 16.7M Colors

PC Input Range Horizontal Freq. 24 to 83 KHz

Vertical Freq. 55Hz to 75Hz

Max. display frequency

(Resolution H*V/Fv)

1920 x 1080 /60Hz

Interface Input D-Sub x 1,DVI (W HDCP) x 1,PC Audio x 1

Output Terminal Eaphone NA

Speaker Yes (1.5W x 2)

Power Consumption On: 28 W;

Standby<=0.5W, O<=0.5W

AC Power Range AC 100~240V, 50~60Hz

Power Mode Indicator Light Power on : Green (LED)

Power saving : Amber (LED)

Operating Condition Temperature 5°C ~ 35°C

Humidity 20% ~ 85%, non-condensing

Physical Dimension (W*D*H) 561 x 220 x 399mm

Packing Dimension (W*D*H) 614 x 109 x 465mm

Net weight 4.5 Kg

Gross weight 5.4 Kg

Tilt -5~ +15

Kensington Lock Yes

VESA mounting 100 x 100mm

Controls Front control Menu, Bri (+), Vol(-) Input/Enter, Power

On Screen Display 12 language : EN, TC, DE, FR, ES, IT, PT, NL, SC,

JS, KR, Russian

Preset Mode PC, Movie, Game, ECO Modes

Container Loading 40’ HQ

US:1680

40' Standard US:1344

EU/Other: 1470

20' Standard US:640

EU/Other: 700

Accessories Power Cable(1.5m),VGA Cable(1.5m),Audio Cable(1.5m),User Manual (CD), Quick

Start Guide (Paper) & Warranty

Color Plan Black glossy: front bezel, arm, base

Black texture: back cover

Carton box Brown

Green product

(Jan. 2009)

Yes

Window 7 Yes

HDMI Logo NA

Certication FCC, UL/CUL, CE, CB, GOST, 3C, China energy level 1, BSMI, EnergyStar 5.0

Actual products may dier slightly from those illustrated on this promotion material. Please refer to actual samples for nal selection. The products

displayed on this promotion material may not be available for purchase in your particular country or locality. Please check with your local Hannspree

authorized representatives for the availability of specic products in your area. Hannspree reserves the right to alter design and specications as well as

to change the accessories with equivalents without notice.
