User’s Manual

HL326UPB (HSG1347)

LCD Monitor

OSD[V6.0]

User’s Manual

TABLE OF CONTENTS

SAFETY NOTICE .................................................................................................. 5

PRECAUTIONS................................................................................................. 5

SPECIAL NOTES ON LCD MONITORS...................................................... 6

BEFORE YOU OPERATE THE MONITOR...................................................... 7

FEATURES......................................................................................................... 7

CHECKING THE CONTENTS OF THE PACKAGE .................................. 7

INSTALLATION INSTRUCTIONS................................................................ 8

POWER............................................................................................................... 8

SETTING THE MONITOR ON THE WALL ................................................ 9

MAKING CONNECTIONS............................................................................ 10

OPERATING INSTRUCTIONS ..........................................................................11

INSERTING REMOTE CONTROL BATTERIES.......................................11

REMOTE CONTROL FUNCTION BUTTONS.......................................... 12

HOW TO ADJUST A SETTINGS.................................................................. 13

MEDIA PLAY - USB DEVICE....................................................................... 15

PLUG AND PLAY............................................................................................ 16

TECHNICAL SUPPORT (FAQ) ......................................................................... 17

Q & A FOR GENERAL PROBLEMS........................................................... 17

ERROR MESSAGE & POSSIBLE SOLUTIONS....................................... 19

APPENDIX ............................................................................................................ 21

SPECIFICATIONS.......................................................................................... 21

User’s Manual

Before operating the monitor, please read this manual thoroughly. This manual should be retained for

future reference.

FCC Class B Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy, and if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful interference to radio

or television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

 Reorient or relocate the receiving antenna.

 Increase the separation between the equipment and receiver.

 Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

 Consult the dealer or an experienced radio/TV technician for help.

The device complies with Parts 15 of the FCC Rule. Operation is subject to the following two

conditions﹕ (1) this device may not cause harmful interference﹔ and (2) this device must accept any

interference received, including interference that may cause undesired operations.

CANADA

This Class B digital apparatus meets all requirements of the Canadian Interference-Causing

Equipment Regulation.

【Optional, depend on selected model】

This device complies with requirement of EMC directive 2014/30/EU with regard to

Electromagnetic Compatibility, and 2014/35/EU and 93/68/EEC with regard to Low Voltage

directive.

【Optional, depend on selected model】

Socket-outlet shall be near the equipment and shall be accessible.

Trademark Notice:

HANNspree products incorporate High-Definition Multimedia Interface

(HDMI

TM) technology.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are

trademarks or registered trademarks of HDMI Licensing LLC in the United States and other

countries.

Produkspesifikasjoner

Merke:	Hannspree
Kategori:	skjerm
Modell:	HL326UPB
Årlig energiforbruk:	57 kWh
Energieffektivitetsklasse (gammel):	A
Berøringsskjerm:	Nei
Synsvinkel, horisontal:	178 °
Skjermform:	Flat
Pakkevekt:	6900 g
Antall HDMI-porter:	2
DVI-port:	Nei
Innebygde høyttalere:	Ja
Antall høyttalere:	2
Maksimal oppdateringshastighet:	60 Hz
3D:	Nei
HDMI:	Ja
HDMI-versjon:	1.4b
Skjermteknologi:	LED
Kontrastforhold (dynamisk):	40000000:1
Innebygd kamera:	Nei
Vekt (med stativ):	5200 g
Antall per pakke:	1 stykker
On Screen Display (OSD):	Ja
Antall USB Type-A nedstrømsporter:	2
Innebygd USB-hub:	Ja
Kontrastforhold:	1200:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Energieffektivitetsskala:	A++ til E
Skjermoppløsning:	1920 x 1080 piksler
Strømforbruk (standby):	0.28 W
Høydejustering:	Nei
Produktfarge:	Sort
HD-type:	Full HD
USB-hub-versjon:	2.0
Bredde (uten stativ):	731 mm
Høyde (uten stativ):	436 mm
Vekt (uten stativ):	4900 g
Bredde (med stativ):	731 mm
Dybde (med stativ):	186 mm
Høyde (med stativ):	469 mm
Pakkedybde:	141 mm
Pakkehøyde:	520 mm
Pakkebredde:	792 mm
Skjermdiagonal:	31.5 "
Naturlig sideforhold:	16:9
Hodetelefon ut:	Nei
Støttede grafikkoppløsninger:	1920 x 1080 (HD 1080)
Kabler inkludert:	HDMI
Pakketype:	Boks
Horisontalt frekvensområde:	30 - 82 kHz
Strømforbruk (vanlig bruk):	39 W
Støttede videofunksjoner:	1080p
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
VESA-montering:	Ja
Dybde (uten stativ):	79 mm
Paneltype:	IPS-ADS
Synsvinkel, vertikal:	178 °
Diagonal skjermstørrelse:	80 cm
Av/på-bryter:	Ja
Lysstyrke for skjerm:	300 cd/m²
Oppdateringsresponstid:	8 ms
Pikselbredde:	0.364 x 0.364 mm
Antall OSD språk:	7
Panelmonterbart grensesnitt:	100 x 100 mm
RMS-rangert strøm/utgangseffekt:	16 W
Skjermlysstyrke (typisk):	300 cd/m²
Display antall farger:	16.78 million farger
Størrelseforhold:	16:9
Innebygd TV-mottaker:	Nei
Avtagbart stativ:	Ja
Stativ medfølger:	Ja
Bildestørrelse, horisontal:	698.4 mm
Bildestørrelse, vertikal:	392.85 mm
Vertikal scanningsratio:	55 - 75 Hz
Strømforbruk, av:	0.5 W
Lydkontakter:	Nei
Bezel bredde (bunn):	12.5 mm
Bezel bredde (topp):	8.5 mm
Bezel bredde (side):	3 mm
