Hannspree HO 550 HTB Bruksanvisning

Hannspree skjerm HO 550 HTB

Les nedenfor 📖 manual på norsk for Hannspree HO 550 HTB (2 sider) i kategorien skjerm. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/2

55“ / 139,7 cm

Part. No..: HO 550 HTB

CONNECTIVITY, IP LEVELSIZE, RESOLUTION VIEWING ANGLE, TOUCH OTHER FEATURES

Technical Specifications >>>

HDMI

VGA

IP 65

Protection

Low Power

Consumption

Stereo

Speakers

• 1920 x 1080 Full HD 1080P Resolution

• 10-Point Touch P-Cap Technology

• 178° °/ 178 Ultra Wide Viewing Angle

• 5000:1 High Contrast Ratio

• Built-in Speakers

• IP65 (front) Rating Level

• Display Protection: Thickness 4mm

• ≥7H Toughened Hard Panel Surface

• Slim Profile with Narrow Edges

• VESA Mount and Multiple Mounting Options

• Orientation: Landscape, Portrait, Face-Up

Open Frame Touch Monitor

HO 550 HTB

55“ / 139,7cm Diagonal

LED Backlight Format 16:9–

55”

Display Size

Full HD

1920 x 1080

HO 550 HTB

55” Open Frame Touch Monitor

178 Ultra-Wide

Viewing Angle

10 Point Touch

PART. NO.:

HO 550 HTB

Display Size

139,7 cm / 55“ Diagonal

Panel Type TFT LED Backlight–

Aspect Ratio 16:9

Resolution (H x V) 1920 x 1080 Full HD

Brightness 350cd/m² Panel / 300 cd/m² Monitor

Contrast (Typ.) 5.000:1 (Typical)

Display Area 1209,6(H) x 680,4(V)

Viewing Angle L/R; U/D 178

H / 178

Response Time 8 msec

Pixel Pitch 0,63 (H) x 0,63 (V) mm

Touch Type

Projected Capacitive Type 10 Point Touch–

Material Glass + Glass

Display Colors 16.7M Colors

Horizontal Frequency

30 ~ 83 kHz

Vertical Frequency 55 ~ 75 Hz

Max Display Frequency 1920 x 1080 @ 60Hz

Input 1 VGA

Input 2 HDMI

Input 3 USB Type B (Touch)

Speakers 2 x 2W, 4 ohm

Power Consumption On: 120W; Stand-by: 0,5W; Off: 0,5W TBC≤ ≤

AC Power Range AC 100 ~ 240 Volt; 50 ~ 60 Hz

Product Dimensions 1289,6 x 72 x 760,4 mm (W x D x H)

Packing Dimensions 139 x 15,5 x 86,5 mm (W x D x H)

Net / Gross Weight 35 Kg / 38 Kg

VESA Mounting

400 x 400 mm

Display Protection Thickness 4

0.3 mm

Hardness / Transmittance 7H Toughened hard panel surface / ≥ ≥85%

IP Rating Level IP 65 (Front), Water and Dust Protection *

Controls Power, Auto, (+), (-), Menu

Accessory

Power supply; HDMI Cable (1.8m); USB Cable for

Touch.

Certifications CE, RoHS

On Screen Display 9 Languages

Orientation Landscape, Portrait, Face-Up

products may differ slightly from those illustrated on this promotion material. Please refer to actual samples for final selection. The products displayed on this promotion

material may not be available for purchase in your particular country or locality. Please check with your local HANNspree aut ized representatives for the availability of hor

specific products in your area. All brand, product, Service names and logos are trademarks and/or registered trademarks of their respective manufactures and Companies.

HO 550 HTB

55” Open Frame Touch Monitor

* IP65: The IP Code classifies how resistant a device is to foreign objects and moisture. IP65 means that the monitor is protected

from total dust ingress and it is protected against low pressure water jets from any direction. Limited ingress permitted.

Produkspesifikasjoner

Merke:	Hannspree
Kategori:	skjerm
Modell:	HO 550 HTB
Vekt:	35000 g
Bredde:	1289.6 mm
Dybde:	72 mm
Høyde:	760.4 mm
Berøringsskjerm:	Ja
Wi-Fi:	Nei
USB-port:	Ja
Synsvinkel, horisontal:	178 °
Pakkevekt:	38000 g
Antall HDMI-porter:	1
DVI-port:	Nei
Innebygde høyttalere:	Nei
Sertifisering:	CE
HDCP:	Nei
Skjermteknologi:	LED
Datasystem:	Nei
On Screen Display (OSD):	Ja
Hardhet:	7H
Markedsføringsnavn dynamisk kontrastforhold:	Høy kontrast
Antall samtidige berøringspunkter:	10
Multi-touch:	Ja
Kontrastforhold:	5000:1
Produktdesign:	Totemdesign
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Skjermoppløsning:	1920 x 1080 piksler
Strømforbruk (standby):	0.5 W
Produktfarge:	Sort
HD-type:	Full HD
Pakkedybde:	155 mm
Pakkehøyde:	865 mm
Pakkebredde:	1390 mm
Skjermdiagonal:	55 "
Berøringsteknologi:	Multi-touch
Naturlig sideforhold:	16:9
Støttede grafikkoppløsninger:	1920 x 1080 (HD 1080)
Kabler inkludert:	HDMI, USB
Horisontalt frekvensområde:	30 - 83 kHz
Strømforbruk (vanlig bruk):	120 W
Bærekraftsertifikater:	RoHS
VESA-montering:	Ja
Paneltype:	TFT
Synsvinkel, vertikal:	178 °
Innebygd prosessor:	Nei
Ekstern strømadapter:	Ja
Internasjonal beskyttelses (IP)-kode:	IP54
Diagonal skjermstørrelse:	139.7 cm
Ethernet/bredbåndsforbindelse:	Nei
Lysstyrke for skjerm:	350 cd/m²
Oppdateringsresponstid:	8 ms
Pikselbredde:	0.63 x 0.63 mm
Panelliv:	30000 timer
Inngangsporter for VGA (D-Sub):	1
Antall OSD språk:	9
Panelmonterbart grensesnitt:	400 x 400 mm
Display antall farger:	16.78 million farger
Innebygd TV-mottaker:	Nei
Vertikal scanningsratio:	55 - 75 Hz
Gjennomsnittstid mellom feil (MTBF):	50000 timer
Strømforbruk, av:	0.5 W
Aktivt skjermområde (B x H):	1209.6 x 680.4 mm
Gjennomsiktighet:	85
