Model Circular saw
Modèle Scie circulaire
Modelo Sierra circular
C 7ST
DOUBLE INSULATION
DOUBLE ISOLATION
AISLAMIENTO DOBLE
INSTRUCTIONS DE SECURITE ET MODE D’EMPLOI
AVERTISSEMENT
Une utilisation INCORRECTE OU DANGEREUSE de cet outil motorisé peut entraîner la
mort ou de sérieuses blessures corporelles!
Ce mode d’emploi contient d’importantes informations à propos de la sécurité de ce
produit. Prière de lire et de comprendre ce mode d’emploi AVANT d’utiliser l’outil
motorisé. Garder ce mode d’emploi à la disponibilité des autres utilisateurs et propriétaires
avant qu’ils utilisent l’outil motorisé. Ce mode d’emploi doit être conservé dans un
endroit sûr.
SAFETY INSTRUCTIONS AND INSTRUCTION MANUAL
WARNING
IMPROPER OR UNSAFE use of this power tool can result in death or serious bodily
injury!
This manual contains important information about product safety. Please read and
understand this manual BEFORE operating the power tool. Please keep this manual
available for other users and owners before they use the power tool. This manual should
be stored in safe place.
INSTRUCCIONES DE SEGURIDAD Y MANUAL DE INSTRUCCIONES
ADVERTENCIA
¡La utilización INAPROPIADA O PELIGROSA de esta herramienta eléctrica puede
resultar en lesiones de gravedad o la muerte!
Este manual contiene información importante sobre la seguridad del producto. Lea y
comprenda este manual ANTES de utilizar la herramienta eléctrica. Guarde este manual
para que puedan leerlo otras personas antes de utilizar la herramienta eléctrica. Este
manual debe ser guardado en un lugar seguro.
00Cover_C7ST_US 2/14/11, 11:191
2
CONTENTS
TABLE DES MATIERES
ÍNDICE
Página
MONTAJE Y OPERACIÓN ...................................... 44
APLICACIONES ................................................... 44
ANTES DE LA OPERACIÓN ................................ 44
AJUSTE DE LA SIERRA ANTES DE
UTILIZARLA .................................................. 45
PROCEDIMIENTOS DE CORTE .......................... 47
MONTAJE Y DESMONTAJE DE LA
CUCHILLA DE LA SIERRA ........................... 48
MANTENIMIENTO E INSPECCIÓN ........................ 50
ACCESORIOS ........................................................... 52
ACCESORIOS ESTÁNDAR ................................. 52
ACCESORIOS OPCIONALES .............................. 52
LISTA DE PIEZAS .................................................... 53
Français
Español
English
Page
IMPORTANT SAFETY INFORMATION .............. 3
MEANINGS OF SIGNAL WORDS ...................... 3
MEANINGS OF SYMBOLS ................................. 3
SAFETY .................................................................... 3
GENERAL POWER TOOL SAFETY
WARNINGS .................................................... 3
SPECIFIC SAFETY RULES AND SYMBOLS ....... 4
DOUBLE INSULATION FOR SAFER
OPERATION ................................................... 8
FUNCTIONAL DESCRIPTION .................................... 9
NAME OF PARTS .................................................. 9
SPECIFICATIONS .................................................. 9
Page
ASSEMBLY AND OPERATION ............................... 10
APPLICATIONS ................................................... 10
PRIOR TO OPERATION ....................................... 10
ADJUSTING THE SAW PRIOR TO USE ............. 11
CUTTING PROCEDURES .................................... 13
MOUNTING AND DISMOUNTING THE
SAW BLADE ................................................. 14
MAINTENANCE AND INSPECTION ....................... 16
ACCESSORIES ......................................................... 18
STANDARD ACCESSORIES ............................... 18
OPTIONAL ACCESSORIES ................................. 18
PARTS LIST .............................................................. 53
Page
ASSEMBLAGE ET FONCTIONNEMENT ................ 27
APPLICATIONS ................................................... 27
AVANT L’UTILISATION ...................................... 27
RÉGLAGE DE LA SCIE AVANT
L’UTILISATION ............................................. 28
PROCEDURES DE COUPE .................................. 30
MONTAGE ET DÉMONTAGE DE LA LAME DE
SCIE .............................................................. 31
ENTRETIEN ET INSPECTION .................................. 33
ACCESOIRES ........................................................... 35
ACCESSOIRES STANDARD ............................... 35
ACCESSOIRES EN OPTION ................................ 35
LISTE DES PIECES ................................................... 53
Página
INFORMACIÓN IMPORTANTE SOBRE
SEGURIDAD ................................................. 36
SIGNIFICADO DE LAS PALABRAS DE
SEÑALIZACIÓN ............................................ 36
SIGNIFICADO DE SÍMBOLOS ............................ 36
SEGURIDAD ............................................................. 36
ADVERTENCIAS DE SEGURIDAD GENERAL
DE LA HERRAMIENTA ELÉCTRICA ............ 36
NORMAS Y SÍMBOLOS ESPECÍFICOS DE
SEGURIDAD ................................................. 38
AISLAMIENTO DOBLE PARA OFRECER UNA
OPERACIÓN MÁS SEGURA ........................ 42
DESCRIPCIÓN FUNCIONAL .................................... 43
NOMENCLATURA ............................................... 43
ESPECIFICACIONES ............................................ 43
Page
INFORMATIONS IMPORTANTES
DE SÉCURITÉ ............................................... 19
SIGNIFICATION DES MOTS
D’AVERTISSEMENT .................................... 19
SIGNIFICATION DES SYMBOLES ...................... 19
SECURITE ................................................................ 19
AVERTISSEMENTS DE SÉCURITÉ GÉNÉRAUX
CONCERNANT LES OUTILS ÉLECTRIQUES ..
19
RÈGLES DE SÉCURITÉ SPÉCIFIQUES ET
SYMBOLES .................................................. 21
DOUBLE ISOLATION POUR UN
FONCTIONNEMENT PLUS SUR ................. 25
DESCRIPTION FONCTIONNELLE ........................... 26
NOM DES PARTIES ............................................ 26
SPECIFICATIONS ................................................ 26
00Cover_C7ST_US 2/14/11, 11:192
English
3
IMPORTANT SAFETY INFORMATION
Read and understand all of the safety precautions, warnings and operating instructions in the Instruction Manual
before operating or maintaining this power tool.
Most accidents that result from power tool operation and maintenance are caused by the failure to observe basic
safety rules or precautions. An accident can often be avoided by recognizing a potentially hazardous situation
before it occurs, and by observing appropriate safety procedures.
Basic safety precautions are outlined in the “SAFETY” section of this Instruction Manual and in the sections which
contain the operation and maintenance instructions.
Hazards that must be avoided to prevent bodily injury or machine damage are identified by WARNINGS on the
power tool and in this Instruction Manual.
NEVER use this power tool in a manner that has not been specifically recommended by HITACHI.
MEANINGS OF SIGNAL WORDS
WARNING indicates a potentially hazardous situations which, if ignored, could result in death or serious injury.
CAUTION indicates a potentially hazardous situations which, if not avoided, may result in minor or moderate
injury, or may cause machine damage.
NOTE emphasizes essential information.
MEANINGS OF SYMBOLS
SAFETY
GENERAL POWER TOOL SAFETY WARNINGS
WARNING:
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
Power tools create sparks which may ignite
the dust or fumes.
c) Keep children and bystanders away while
operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools.
Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators.
Symbols
WARNING
The following show symbols used for the machine. Be sure that you understand their meaning before use.
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious
injury.
Always wear eye protection.
Always wear hearing protection.
01Eng_C7ST_US 2/14/11, 11:103
