CV-S880/CV-S890/CV-T885

INSTRUCTION MANUAL Vacuum Cleaner

РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ Пылесос

J1861_COVER 11/11/03, 10:57 AM1

English

ACCESSORIES (Fig.1)

A Flexible crush proof hose

B Extension pipe

C Curved joint pipe

D Joint pipe

E Cloth bag

F Dusting brush (stored in tool

G Crevice nozzle storage space)

H Rug and oor tool (for CV-S880, CV-T885)

I Rug and oor tool (for CV-S890)

J Rug and oor tool (Y31)

K Rug and oor tool (D321-D)

HOW TO OPERATE

TO ASSEMBLE HOSE (Fig. 2)

The hose and joint pipe are packaged separately. To put them together,

insert the curved joint pipe

and joint pipe

into each end of the

hose

until the claws

of the stopper rings

click into the holes

of the curved joint pipe and joint pipe.

TO ATTACH HOSE (Fig. 3)

Insert the joint pipe

into the suction inlet

of the cleaner. When you

remove the hose

, pull the joint pipe

while pressing the button

TO ATTACH EXTENSION PIPES (Fig. 4)

Fit the extension pipes

, and the selected suction attachment by

twisting together.

TO DETACH EXTENSION PIPES (Fig. 5)

Twist and pull the extension pipe

, upward.

RUG AND FLOOR TOOL (Fig. 6) (for CV-S890)

To clean smooth surfaces, depress the switch " " to in line with

" "

. To clean rugs or carpets depress the switch " " to in line

with " "

RUG AND FLOOR TOOL (Fig. 21)

The tool is tted with a brush at the back which can either be used in

the “withdrawn” or “projected” position. These positions are operated

by the pedal on the tool marked " " (Carpet)

and " " (Floor)

For cleaning rug or carpet, keep the brush in its “withdrawn”

position, i.e., with the pedal marked " " pressed down with your

toe. If you feel the tool is heavy to slide on the carpet, please reduce

the suction power by adjusting the suction control. (Fig. 9)

ON-OFF SWITCH (Fig. 7)

Turn cleaner on or o by pushing downward on the power switch

ELECTRONIC POWER CONTROL (for CV-S890, Fig. 8)

Suction power may be regulated electronically using the dial on the

unit

. For stronger suction (thick carpets or hard oors) rotate the

dial to the right. Rotate it to the left for reduced suction (curtains,

delicate fabrics).

SUCTION CONTROL (Fig. 9)

Suction pressure is reduced by moving the adjustment ring

on the

curved joint pipe

to expose a hole.

The more hole area exposed the lower the suction.

Low suction pressure is recommended for cleaning curtains, blinds,

delicate fabrics etc,.

BAG FULL INDICATOR (Fig. 10)

When the orange sign

appears in the large window continuously,

change the cloth bag.

Check the bag full indicator (with the highest power of electronic power

control for CV-S890) by lifting cleaning head from the surface being

cleaned or removing the crevice nozzle when it has been used.

NOTE: If the cleaner is used in such a condition as the orange sign

appears in the large window, air to the motor will be reduced

and the motor will eventually burn out.

AUTOMATIC CORD REWIND (Fig. 11)

The power cord is stored neatly inside the cleaner using an automatic

cord rewind.

When cleaning is completed unplug from the mains and depress the

rewind pedal

, the cord will automatically rewind.

NOTE: Should the cord not fully rewind, pull out a short length and

press the pedal again.

For smooth rewinding, turn the cord inlet toward the same direction

as the cord pulled out.

TOOL STORAGE SPACE (Fig. 12)

The crevice and brush tools snap into the rear storage rack

for

safekeeping and easy access.

TO USE ATTACHMENTS (Fig. 13,14)

TO STORE ACCESSORIES (Fig. 15)

Hose, extension pipe and rug and floor tool can be attached in

assembled condition to the cleaner by using the nozzle hook

the rug and oor tool.

This combination allows you a space storage.

1. Place the cleaner upright.

2. Slide the nozzle hook

of the rug and oor tool into the hook

supporter

at the rear of the cleaner as shown in Fig. 15.

3. Turn the hose around pipes to make it compact and stable.

NOTE:

Do not hold the hose and the joint pipe to transport the cleaner.

TO DISCONNECT CURVED JOINT PIPE (Fig. 16)

Blockages may be cleared by separating the curved joint pipe

from the hose. To separate the curved joint pipe depress the two

claws

which are located in the holes on both sides of curved joint

pipe

and pull apart.

When needed, the hose collar

can be removed from the hose end

by turning it (left-handed screw).

To re-connect push hose back into curved joint pipe and twist until

two claws

locate with holes

Likewise you can disconnect the hose joint on the other end of the hose.

HOW TO REMOVE DUST

TAKING OUT DUST BAG (Fig. 17)

1. Remove the plug from the electrical outlet. Open the bag

compartment lid

by pulling up the clamp

2. Pull out the dust bag

gently.

3. Slide o the bag clip from the dust bag and dispose of dust in the

dust bag.

SETTING DUST BAG (Fig. 18)

1. Before setting the dust bag, be sure to slide back the bag clip.

2. Place the dust bag by opening its inner lid

3. Position the top edges of the collar to the inner lid concave, and

t the hole at the lower edge to the guide pins

of the case.

NOTE

To avoid using the cleaner without the cloth bag, the clamp system of

your cleaner prevents the bag compartment lid from being clamped

when the cloth bag has not been replaced, or has not been set properly

in place.

CARE OF AIR FILTERS

MOTOR PROTECTION AIR FILTER (Fig. 19)

Once or twice a year, or when it becomes visibly soiled, the motor

protection lter

located behind the cloth bag may need cleaning.

1. Take out the cloth bag, then remove the lter from the cleaner as

shown in Fig. 19 and wash in warm water.

2. After washing the lter, dry thoroughly away from direct sunlight

and t back into the cleaner.

J1861_CV-S880(E) 15/07/2004, 4:07 PM2

NOTE: If the air lter is used when wet, suction is impaired and the

motor may be damaged.

HYGIENIC AIR FILTER (for CV-S890, Fig. 20)

Periodically check the condition of the exhaust air lter. To replace it:

1. Remove the bag compartment lid

2. Pull out the lter by its top tab and discard it

3. Push in a new filter

4. Close the bag compartment lid

HOW TO MAINTAIN CLEANING

EFFICIENCY AND AVOID ACCIDENTS

●The plug of the power supply cord should be removed from the

socket outlet before cleaning the appliance or under-taking

maintenance operations.

●If the supply cord is damaged, it must be replaced by the

manufacturer or its service agent or a similarly qualied person in

order to avoid a hazard.

●Be sure to replace a new cloth bag after disposing of the full one.

There is a device which prevents the bag compartment lid from

being closed when the cloth bag has not been replaced. Do not

tamper with this to use without bags as dust will be sucked directly

into the mechanical parts and may damage the motor.

●Do not use the cleaner to pick up wet dirt, and avoid using the

cleaner in a wet and moist place as moisture may damage the

motor and other mechanical parts.

●Do not pick up sharp objects, eg. nails, to prevent damage to the

vacuum cleaner.

●Do not block the air ow.

Any blockages or obstructions to the suction inlet, rug-and-oor

tool, extension pipe, hose, etc. or the exhaust air outlet can cause

loss of power and motor overheating.

●Do not pick up matches, replace ashes, or smoking material

with cleaner, as a possible re hazard may result.

●To clean the cleaner body and attachments, wipe them with a

soapsuds-soaked cloth, and avoid using spirits.

●Avoid cleaning the switch part with a wet cloth and splashing water

on it as moisture may cause a short circuit.

●The carbon brushes of the motor are of special composition.

When replacing the defaced carbon brushes, it is necessary to

use the Hitachi special carbon brushes for the Hitachi Vacuum

Cleaner.

●Your vacuum cleaner is not a toy. Do not allow children to play

with the cleaner. Do not leave cleaner connected to an electrical

outlet and leave it unattended.

●Warning; Electric shock could occur if used outdoors or on wet

surfaces.

This product conforms with the protection requirements of

council directives 89/336/ECC relating to electromagnetic

compatibility and 73/23/ECC relating to electrical equipment

designed for use within certain voltage limits.

J1861_CV-S880(E) 15/07/2004, 4:07 PM3
