TREADMILL OWNER’S MANUAL
Read the TREADMILL GUIDE before using this OWNER’S MANUAL.
PARAGON 5S
PARAGON 7S
PARAGON 7E
PARAGON 8E
32
ASSEMBLY
There are several areas during the assembly process that special attention must be paid. It is very important to follow the
assembly instructions correctly and to make sure all parts are firmly tightened. If the assembly instructions are not followed
correctly, the treadmill could have frame parts that are not tightened and will seem loose and may cause irritating noises.
To prevent damage to the treadmill, the assembly instructions must be reviewed and corrective actions should be taken.
Before proceeding, find your treadmill’s serial number located on the front stabilizer tube and enter it in the space provided
below. Also locate the model name which is next to the serial number.
ENTER YOUR SERIAL NUMBER AND MODEL NAME IN THE BOXES BELOW:
WARNING
SERIAL NUMBER:
MODEL NAME: HORIzON TREADMILL
54
TOOLS INCLUDED:
5 mm L-Wrench/Screwdriver
6 mm T-Wrench
Screwdriver (not included)
PARTS INCLUDED:
1 Console Assembly
2 Console Masts
3 Hardware Kit
1 Safety Key
1 Power Cord
1 Base Frame
If you have questions or if there are
any missing parts, contact your local
dealer. Contact information may be
located on the back panel of your
manual or on the warranty card.
NEED HELP?
DO NOT ATTEMPT TO LIFT THE TREADMILL! Do not move or lift treadmill
from packaging until specified to do so in the assembly instructions. You
may remove the plastic wrap from console masts.
WARNING
UNPACKING
Place the treadmill carton on a level flat surface. It is recommended that you place
a protective covering on your floor. Take CAUTION when handling and transporting
this unit. Never open box when it is on its side. Once the banding straps have been
removed, do not lift or transport this unit unless it is fully assembled. Unpack and
assemble the unit where it will be used. Never grab hold of any portion of the incline
frame and attempt to lift or move the treadmill.
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN INJURY!
In case of an emergency, place both hands on the side arm rests to hold
yourself up and place your feed onto the side rail.
WARNING
NOTE: During each assembly step, ensure that ALL nuts and bolts are in place and
partially threaded in before completely tightening any ONE bolt.
NOTE: A light application of grease may aid in the installation of hardware. Any
grease, such as lithium bike grease is recommended.
PRE ASSEMBLY
Paragon 5S
Shown
ALL
MODELS
CONSOLE
ON/OFF SWITCH
CIRCUIT BREAKER
POWER CORD
CONSOLE CONTROLS AND DISPLAY WINDOWS
SAFETY KEY PLACEMENT
ROLLER END CAP
REAR ROLLER TENSION/ADJUSTMENT BOLTS
WATER BOTTLE HOLDER
SPEED/INCLINE TOGGLES
GRIP PULSE HANDRAILS
TRANSPORT WHEEL
READING R ACK
HANDLE BARS
CONSOLE MAST COVER
MOTOR COVER
CONSOLE MAST
SIDE RAIL
RUNNING BELT / RUNNING DECK
