ELLIPTICAL OWNER’S MANUAL
Read the ELLIPTICAL GUIDE before using this OWNER’S MANUAL.
SYROS
SYROS PRO
2 3
ASSEMBLY
There are several areas during the assembly process that special attention must be paid. It is very important to follow the assembly
instructions correctly and to make sure all parts are firmly tightened. If the assembly instructions are not followed correctly, the
elliptical could have frame parts that are not tightened and will seem loose and may cause irritating noises. To prevent damage to
the elliptical, the assembly instructions must be reviewed and corrective actions should be taken.
Before proceeding, find your elliptical’s serial number located on the front stabilizer tube and enter it in the space provided
below. Also locate the model name which is next to the serial number.
ENTER YOUR SERIAL NUMBER AND MODEL NAME IN THE BOXES BELOW:
SERIAL NUMBER:
MODEL NAME: Horizon elliptical
WarninG
4 5
SYROS PRO
SHOWN
SYROS PRO
UnpacKinG
Unpack the product where you will be using it. Place the elliptical carton on a level flat
surface. It is recommended that you place a protective covering on your floor. Never
open box when it is on its side.
NOTE: During each assembly step, ensure that ALL nuts and bolts are in place and
partially threaded in before completely tightening any ONE bolt.
NOTE: A light application of grease may aid in the installation of hardware. Any grease,
such as lithium bike grease is recommended.
If you have questions or if
there are any missing parts,
contact your local dealer.
neeD Help?
pre ASSEMBLY
toolS inclUDeD:
5mm L Wrench
Flat Wrench
partS pacKinG inclUDeD:
1 Main Frame
1 Front Stabilizer Tube
1 Rear Stabilizer Tube
1 Console
1 Console Mast
1 Console Mast Grommet
2 Upper Handlebars
2 Lower Handlebars
2 Upper Handlebar Covers
2 Pedals
2 Pedal Arms
1 Power Cord
1 Hardware Kit
SYROS
SYROS PRO
UPPER HANDLEBAR
PULSE GRIPS
PEDAL ARM
POWER CORD SOCKET
REAR STABILIZER TUBE
CONSOLE
UPPER HANDLEBAR COVER
CONSOLE MAST
CONSOLE MAST GROMMET
FRONT STABILIZER TUBE
PEDAL ADJUSTMENT KNOB
(SYROS PRO ONLY)
LOWER HANDLEBAR
PROGRAMME
PROGRAMS
KÖRPERFETT
BODY FAT
NULLSTELLUNG
RESET
ERHOLUNG
RECOVERY
START/STOPP
START/
STOP
AUSWAHL
MODE
SENKEN
DOWN
ERHÖHEN
UP
P1
P7
P8
P9
P10
P11
P12
P2
P3
P4
P5
P6
FOOTPAD
CRANK COVER
